dB Technologies OPERA 15 2 Way Active Speaker 15 Inch Woofer Loudspeaker DSP

dB Technologies OPERA 15 2 Way Active Speaker 15 Inch Woofer Loudspeaker DSP

Exceptional power and a unique acoustic design combine in order to deliver a vigorous yet accurate audio performance, successfully adaptable to both playback and live music applications.

With the new OPERA series, dBTechnologies succeded once again in packing leading edge DSP processing, advanced design features and user friendliness in an unrivalled cabinet in its price range.

Exceptional power and a unique acoustic design combine in order to deliver a vigorous yet pristine sound, successfully adaptable to both playback and live music applications.

Opera’s asymmetrical horn has been completely redesigned in order to obtain both an asymetrical vertical dispersion and a double horizontal dispersion, ensuring an optimized throw pattern.

The system is equipped with a powerful Class D 600 W amplifier featuring advanced DSP processing where FIR filters allow the systems to deliver a coherent audio performance, uniform and crystal-clear from every listening position.

FEATURES:

• 1200 W PEAK POWER

• 600 W RMS POWER

• NEWLY DESIGNED ASYMMETRICAL HORN

• ADVANCED DSP WITH FIR FILTERS

• 2 INPUT CHANNELS (MIC-LINE/MIC-INSTR)

• SELECTABLE OUTPUT CHANNEL (LINK CH1/MIX CH 1+2)

• 8 EQ PRESETS

• FRESH FULL GRILLE DESIGN

• STAGE MONITOR USE

Specifications:

Technical Data

Speaker Type: 2-Way Active Speaker

Acoustical data

Frequency Response: [-10dB]50 - 20.000 Hz

Frequency Response: [- 3dB]56 - 19.000 Hz

Max SPL: 130 dB

HF: 1" Exit, 1.4 v.c.

Type HF: Compression driver

Horizontal Directivity: 100° (85° up/120° down)

Vertical Directivity: 85° (+ 25°/-60°)

Horn: Asymmetrical Horn

LF: 15", 2" v.c.

Amplifier

Amp Technology: Amp SMPS Power supply dual range

Amp ClassClass: D

RMS Power:600 W

Peak Power:1200 W

Processor

Controller: DSP 56 bit

AD/DA Converter: 24 bit/48 KHz

System Presets: Rotary Encoder (8 Presets)

X-Over Frequency: 1800 Hz

Limiter: Peak, RMS, Thermal

Advanced DSP Functions: Linear Phase FIR Filters

Input

Signal Input: 1xCombo (XLR/Jack 6.3 mm) MIC/Line

1xCombo (XLR/Jack 6.3 mm) MIC/Inst

Signal Output1x XLR Male (CH1 Link/Mix OUT)

Selectable

Mechanics

Housing: Polypropylene with internal frame

Grille: Full grille

Handles: 1 on left Side, 1 on Top

Rigging Points: 2XM10 on Top + 1x M10 on Back

Pole Mount: D36 mm

Angles up: Monitor use 45°

Width: 420 mm (16.54 in)

Height: 722 mm (28.43 in)

Depth: 419 mm (16.50 in)

Weight: 18.3 kg (40.34 lbs)
