QSC K12.2 Two Way 12 Inch Portable PA Active Loudspeaker 2000 Watts

The QSC K.2 Series™ represents the best-inclass loudspeaker for today’s demanding audio professionals. The perfect combination of elegant design, superior audio performance, high functionality, simple and intuitive operation, and genuine QSC reliability, K.2 delivers extraordinary results for users in both portable and installed applications.

The 2000 Watt power module delivers ample burst and continuous power for the loudspeaker’s premium drivers. It has been designed with very low-noise fan cooling, enabling the enclosures to be used in settings where background noise must be kept to a minimum. Carefully tailored, subtle and sophisticated dynamics processing is used to protect the drivers from damage and the performance from distortion.

The user may select from an extensive list of factory preset EQ contours including Live, Dance, Monitor, and many more

Savable and recallable Scenes can store information like user EQ, Delay, and input configuration settings.

A pair of balanced combo XLR/F plus 1/4-inch TRS connectors with independent gain control are provided. The first is equipped with selectable MIC/LINE (Microphone or Line) level input while the second offers selectable HI-Z/LINE (High Impedance or Line) level input, specifically for musical instruments. Both inputs are connected directly to a pair of XLR/M throughput connectors so that the signals may be “daisy-chained” to another audio device. A 3.5 mm TRS input jack with independent gain control is also provided for connection of sources such as smart phones, computers, and MP3 players.

In addition to the two throughput XLRs, a line-level output with the mixed signal from all inputs is also provided. (An optional security cover (K-LOC) may be installed to prevent unauthorized tampering of settings)

Directivity Matched Transition® (DMT) design matches the coverage angle of the woofer at the cross-over frequency with the horn pattern to ensure uniform response across the coverage area. Intrinsic Correction™ techniques are also employed ensuring smooth power response from the loudspeaker. The result is an extremely accurate loudspeaker that behaves well in a wide range of acoustic spaces with little or no equalization.

Each model is housed in a rugged ABS enclosure with a professional yet unobtrusive appearance that is at home in any application. Each model can be utilized in either main PA or floor monitor applications, while ergonomic handles and a heavy-duty steel grille with fabric lining further enhance overall appearance and functionality. The dual pole cups allow a zero or 7.5 degree downward tilt when deployed on a pole. This allows for more even coverage across the listening area and less problems due to rear wall reflections. For suspended applications, integrated M10 fittings with a single pullback are included to accommodate M10 eyebolts. An optional yoke mount accessory is also available for permanent installation to walls and ceilings or for temporary attachment to truss (requires 3rd party hardware). 6-Year Warranty: Robust QSC reliability backed by a global 6-Year Warranty*

Features:
Best in class audio performance
2000 Watt Class-D amplifier module
Intrinsic Correction™ tuning and loudspeaker management
Directivity Matched Transition® (DMT) design provides excellent power response and consistent performance across the listening area
Refined, professional appearance looks great in any application
Rugged ABS enclosure for long life and lasting durability
Deployment in either main PA or floor monitor position
Factory Presets and savable/recallable Scenes for commonly-used application
Multi-function digital display for control and selection of loudspeaker functions including cross-over, EQ, delay and frequency contour
Dual pole cup mounts (standard and 7.5 degree down-tilt)
M10 fittings for flown applications
Optional security panel prevents unauthorized tampering of controls
Complete EASE and CAD information available online
6-Year Warranty (with product registration)

Specifications:
Model: K12.2
Configuration: Multi-purpose, 2-way active loudspeaker
LF Transducer: 305 mm (12-inch), cone
HF Transducer: 35.6 mm (1.4-inch) titanium diaphragm compression driver
Frequency Response (-6 dB): 50 Hz - 20 kHz
Frequency Range (-10 dB): 45 Hz - 20 kHz
Nominal Coverage Angle: 75° Axisymetric
Maximum Rated SPL1: 132 dB @ 1 M, peak 126 dB @ 1 M, continuous
Amplifier: Class D
Peak: 1800 W (LF), 225 W (HF)
Cooling: Low-noise, variable speed fan
Controls
Power
3 × Level
Rotary encoder (push)
2 × selection buttons
Indicators:
Monochrome LCD Display 1.75-inch x 1-inch (45 mm x 25.4 mm)
2 × Power LED (front and rear)
3 × Input Signal LED
Input A Mic selected LED
Input B Hi-Z selected LED
Limiter active LED
Connectors:
2 × locking XLR/F ¼⁻ᶦⁿᶜʰ combo (Mic/Line Input and Hi-Z/Line Input
1 × 3.5 mm TRS (Stereo Input)
2 × XLR/M (Loop-thru Output)
1 × XLR/M (Mix Output)
1 × locking IEC power connector
AC Power Input: Universal power supply 100 – 240 VAC, 50 – 60 Hz
AC Power Consumption 1/8th Power2: 100 VAC, 2.1 A / 120 VAC, 1.9 A / 240 VAC, 1.1 A
AC Power Consumption - Standby: 0.2 A at any voltage
Enclosure Details
Enclosure: Impact Resistant ABS
Attachment Points: 2 × M10 threaded inserts plus Pull-Back
Color: Black (RAL 9011)
Grille: 18 Gauge powered coated steel, internal cloth lining
Speaker Dimensions (HxWxD):
602 × 356 × 350 mm
23.7 × 14 × 13.8 in
Carton Dimensions (HxWxD):
570 × 470 × 464 mm
22.5 × 18.5 × 18.3 in
Net Weight: 17.7 kg / 39 lb
Shipping Weight: 21.6 kg / 47.6 lb
Regulatory: CE, WEEE, UL, China RoHS, RoHS II, FCC Class B
Optional Accessories:
K12 Tote, K12 Outdoor Cover
M10 Kit-C, K.2-LOC LockOut Cover
K12.2 Yoke

QSC CP8 8 Inch Two Way Powered Active PA Loudspeaker 1000 Watts

High performance, superior quality and lasting reliability. These are the hallmarks of the QSC brand and the reason why millions of professionals the world-over have come to trust QSC to help them confidently deliver superior experiences and memorable performances. The CP Series follows in that same tradition while also offering an ultra-compact form factor and class-leading value.

The 1000 Watt (peak) power module delivers ample burst and continuous power for the loudspeaker’s matching transducers. Convection cooling provides heat dissipation, even in extreme climates, while contributing no additional background noise. Carefully tailored, subtle and sophisticated dynamics processing is used to protect the drivers from damage and the performance from distortion. The result is a highly accurate and musical sound that maintains full signal integrity, even when pushed to high SPL.

CP produces a big sound from a small package. Ultra-compact and remarkably light weight, CP is easy to load, carry, lift and deploy in a wide range of portable and installed applications.

CP presents a compact, unobtrusive and stylish appearance that looks great in a wide range of applications. Both models can be utilized as either main PA (with included pole mount), floor monitor or installed via optional quick-connect yoke mount.

CP provides one-touch access to preset contours for the most commonly-used applications including Default (Full-Range), Default with External Subwoofer, Dance, Dance with External Subwoofer, Floor Monitor and Speech.

* 1 year warranty may be extended by an additional 5 years, with QSC Product Registration

Features:
Compact and powerful performance
1000 Watt peak power Class-D amplifier module
Easily selected contours for commonly-used applications
Advanced DSP with Intrinsic Correction™ for superior sound quality and speaker protection
Directivity Matched Transition® (DMT) for consistent frequency response across the entire coverage area
Light weight and highly portable
Professional appearance looks great in any application
Use for main PA, stage monitor, or instrument amplifier
35 mm pole socket
Optional yoke, tote, and outdoor cover accessories
Complete EASE and CAD information available online
6-Year Warranty*

Specifications:
Model: CP8
Configuration: Two-way active loudspeaker
LF Transducer: 203 mm (8 in) , cone
HF Transducer: 35.6 mm (1.4 in) compression driver
Frequency Response (-6 dB): 56 - 20 kHz
Frequency Range (-10 dB): 53 - 20 kHz
Nominal Coverage Angle: 90° Axisymetric
Maximum Rated SPL1: 124 dB
Amplifier:
Class D
Peak: 800 W (LF), 200 W (HF)
Controls:
Power
2 x Gain
Mic Boost Push Switch
6-way Contour Selection Switch
Indicators:
Power LED
2 × Input Signal LED
Input B MIC selected LED
Limiter active LED
Connectors:
2 × locking XLR/F ¼” combo (Line Input and Mic/Line input)
1 × 3.5 mm TRS (Stereo Input)
1 × XLR/M (Mix Output)
1 × IEC power connector
AC Power Input: Universal power supply 100 – 240 VAC, 50 – 60 Hz
AC Power Consumption (1/8th Power): 100 VAC, 0.75A - 240VAC 0.31A
Enclosure Material: Polypropylene
Attachment Points: M8 threaded insert
Color: Black (RAL 9011)
Grille: 18 Gauge powder-coated steel
Speaker Dimensions (H×W×D):
411 × 273 × 256 mm
16.2 × 10.7 × 10.1 in
Carton Dimensions (H×W×D):
360 × 360 × 496 mm
14.2 × 14.2 × 19.5 in
Net Weight: 9.5 kg / 21.0 lb
Shipping Weight: 11.5 kg / 25.4 lb
Regulatory: EMC, UL, CB
Optional Accessories: CP8 Tote, CP8 Outdoor Cover, CP8 Yoke

QSC K8.2 Two Way 8 Inch Portable PA Active Loudspeaker 2000 Watts

The QSC K.2 Series™ represents the best-inclass loudspeaker for today’s demanding audio professionals. The perfect combination of elegant design, superior audio performance, high functionality, simple and intuitive operation, and genuine QSC reliability, K.2 delivers extraordinary results for users in both portable and installed applications.

The 2000 Watt power module delivers ample burst and continuous power for the loudspeaker’s premium drivers. It has been designed with very low-noise fan cooling, enabling the enclosures to be used in settings where background noise must be kept to a minimum. Carefully tailored, subtle and sophisticated dynamics processing is used to protect the drivers from damage and the performance from distortion.

The user may select from an extensive list of factory preset EQ contours including Live, Dance, Monitor, and many more

Savable and recallable Scenes can store information like user EQ, Delay, and input configuration settings.

A pair of balanced combo XLR/F plus 1/4-inch TRS connectors with independent gain control are provided. The first is equipped with selectable MIC/LINE (Microphone or Line) level input while the second offers selectable HI-Z/LINE (High Impedance or Line) level input, specifically for musical instruments. Both inputs are connected directly to a pair of XLR/M throughput connectors so that the signals may be “daisy-chained” to another audio device. A 3.5 mm TRS input jack with independent gain control is also provided for connection of sources such as smart phones, computers, and MP3 players.

In addition to the two throughput XLRs, a line-level output with the mixed signal from all inputs is also provided. (An optional security cover (K-LOC) may be installed to prevent unauthorized tampering of settings)

Directivity Matched Transition® (DMT) design matches the coverage angle of the woofer at the cross-over frequency with the horn pattern to ensure uniform response across the coverage area. Intrinsic Correction™ techniques are also employed ensuring smooth power response from the loudspeaker. The result is an extremely accurate loudspeaker that behaves well in a wide range of acoustic spaces with little or no equalization.

Each model is housed in a rugged ABS enclosure with a professional yet unobtrusive appearance that is at home in any application. Each model can be utilized in either main PA or floor monitor applications, while ergonomic handles and a heavy-duty steel grille with fabric lining further enhance overall appearance and functionality. The dual pole cups allow a zero or 7.5 degree downward tilt when deployed on a pole. This allows for more even coverage across the listening area and less problems due to rear wall reflections. For suspended applications, integrated M10 fittings with a single pullback are included to accommodate M10 eyebolts. An optional yoke mount accessory is also available for permanent installation to walls and ceilings or for temporary attachment to truss (requires 3rd party hardware). 6-Year Warranty: Robust QSC reliability backed by a global 6-Year Warranty*

Features:
Best in class audio performance
2000 Watt Class-D amplifier module
Intrinsic Correction™ tuning and loudspeaker management
Directivity Matched Transition® (DMT) design provides excellent power response and consistent performance across the listening area
Refined, professional appearance looks great in any application
Rugged ABS enclosure for long life and lasting durability
Deployment in either main PA or floor monitor position
Factory Presets and savable/recallable Scenes for commonly-used application
Multi-function digital display for control and selection of loudspeaker functions including cross-over, EQ, delay and frequency contour
Dual pole cup mounts (standard and 7.5 degree down-tilt)
M10 fittings for flown applications
Optional security panel prevents unauthorized tampering of controls
Complete EASE and CAD information available online
6-Year Warranty (with product registration)

Specifications:
Model: K8.2
Configuration: Multi-purpose, 2-way active loudspeaker
LF Transducer: 203 mm (8-inch), cone
HF Transducer: 35.6 mm (1.4-inch) titanium diaphragm compression driver
Frequency Response (-6 dB): 59 Hz - 20 kHz
Frequency Range (-10 dB): 55 Hz - 20 kHz
Nominal Coverage Angle: 105° Axisymetric
Maximum Rated SPL1: 128 dB @1 M, peak 122 dB @ 1 M, continuous
Amplifier: Class D Peak: 1800 W (LF), 225 W (HF)
Cooling: Low-noise, variable speed fan
Controls:
Power
3 × Level
Rotary encoder (push)
2 ×x selection buttons
Indicators:
Monochrome LCD Display 45 mm × 25.4 mm (1.75-inch × 1-inch)
2 × Power LED (front and rear)
3 × Input Signal LED
Input A Mic selected LED
Input B Hi-Z selected LED
Limiter active LED
Connectors:
2 × locking XLR/F ¼⁻ᶦⁿᶜʰ combo (Mic/Line Input and Hi-Z/Line Input
1 × 3.5 mm TRS (Stereo Input)
2 × XLR/M (Loop-thru Output)
1 × XLR/M (Mix Output)
1 × locking IEC power connector
AC Power Input: Universal power supply 100 – 240 VAC, 50 – 60 Hz
AC Power Consumption 1/8th Power2: 100 VAC, 2.1 A / 120 VAC, 1.9 A / 240 VAC, 1.1 A
AC Power Consumption - Standby: 0.2 A at any voltage
Enclosure Details
Enclosure: Impact Resistant ABS
Attachment Points: 2 × M10 threaded inserts plus Pull-Back
Color: Black (RAL 9011)
Grille: 18 Gauge powered coated steel, internal cloth lining
Speaker Dimensions (H×W×D):
449 × 280 × 269 mm
17.7 × 11 × 10.6 in
Carton Dimensions (H×W×D):
500 × 380 × 368 mm
19.7 × 15 × 14.5 in
Net Weight: 12.2 kg / 27 lb
Shipping Weight: 14.4 kg / 31.7 lb
Regulatory: CE, WEEE, UL, China RoHS, RoHS II, FCC Class B
Optional Accessories:
K8 Tote, K8 Outdoor Cover
M10 Kit-C, K.2-LOC Lock Out Cover
K8.2 Yoke

QSC K12 TOTE Active Loudspeaker Soft Padded Carrying Bag Fits K12 Loudspeaker

The QSC K12.2 active loudspeaker tote is a soft, padded transportation bag made with weather resistant, heavy-duty Nylon/Cordura® material for K12.2 active loudspeaker carried by 2 strap handles with an overlapping grip.

Features:
Soft, padded tote made with weather resistant, heavy-duty Nylon/Cordura® material for K12.2 and legacy K12.
Heavy-duty Nylon/Cordura material for K12

QSC K10.2 Two Way 10 Inch Portable PA Active Loudspeaker 2000 Watts

The QSC K.2 Series™ represents the best-inclass loudspeaker for today’s demanding audio professionals. The perfect combination of elegant design, superior audio performance, high functionality, simple and intuitive operation, and genuine QSC reliability, K.2 delivers extraordinary results for users in both portable and installed applications.

The 2000 Watt power module delivers ample burst and continuous power for the loudspeaker’s premium drivers. It has been designed with very low-noise fan cooling, enabling the enclosures to be used in settings where background noise must be kept to a minimum. Carefully tailored, subtle and sophisticated dynamics processing is used to protect the drivers from damage and the performance from distortion.

The user may select from an extensive list of factory preset EQ contours including Live, Dance, Monitor, and many more

Savable and recallable Scenes can store information like user EQ, Delay, and input configuration settings.

A pair of balanced combo XLR/F plus 1/4-inch TRS connectors with independent gain control are provided. The first is equipped with selectable MIC/LINE (Microphone or Line) level input while the second offers selectable HI-Z/LINE (High Impedance or Line) level input, specifically for musical instruments. Both inputs are connected directly to a pair of XLR/M throughput connectors so that the signals may be “daisy-chained” to another audio device. A 3.5 mm TRS input jack with independent gain control is also provided for connection of sources such as smart phones, computers, and MP3 players.

In addition to the two throughput XLRs, a line-level output with the mixed signal from all inputs is also provided. (An optional security cover (K-LOC) may be installed to prevent unauthorized tampering of settings)

Directivity Matched Transition® (DMT) design matches the coverage angle of the woofer at the cross-over frequency with the horn pattern to ensure uniform response across the coverage area. Intrinsic Correction™ techniques are also employed ensuring smooth power response from the loudspeaker. The result is an extremely accurate loudspeaker that behaves well in a wide range of acoustic spaces with little or no equalization.

Each model is housed in a rugged ABS enclosure with a professional yet unobtrusive appearance that is at home in any application. Each model can be utilized in either main PA or floor monitor applications, while ergonomic handles and a heavy-duty steel grille with fabric lining further enhance overall appearance and functionality. The dual pole cups allow a zero or 7.5 degree downward tilt when deployed on a pole. This allows for more even coverage across the listening area and less problems due to rear wall reflections. For suspended applications, integrated M10 fittings with a single pullback are included to accommodate M10 eyebolts. An optional yoke mount accessory is also available for permanent installation to walls and ceilings or for temporary attachment to truss (requires 3rd party hardware). 6-Year Warranty: Robust QSC reliability backed by a global 6-Year Warranty*

Features:
Best in class audio performance
2000 Watt Class-D amplifier module
Intrinsic Correction™ tuning and loudspeaker management
Directivity Matched Transition® (DMT) design provides excellent power response and consistent performance across the listening area
Refined, professional appearance looks great in any application
Rugged ABS enclosure for long life and lasting durability
Deployment in either main PA or floor monitor position
Factory Presets and savable/recallable Scenes for commonly-used application
Multi-function digital display for control and selection of loudspeaker functions including cross-over, EQ, delay and frequency contour
Dual pole cup mounts (standard and 7.5 degree down-tilt)
M10 fittings for flown applications
Optional security panel prevents unauthorized tampering of controls
Complete EASE and CAD information available online
6-Year Warranty (with product registration)

Specifications:
Model: K10.2
Configuration: Multi-purpose, 2-way active loudspeaker
LF Transducer: 254 mm (10-inch), cone
HF Transducer: 35.6 mm (1.4-inch) titanium diaphragm compression driver
Frequency Response (-6 dB): 56 Hz - 20 kHz
Frequency Range (-10 dB): 50 Hz - 20 kHz
Nominal Coverage Angle: 90° Axisymetric
Maximum Rated SPL1: 130 dB @1 M, peak 124 dB @ 1 M, continuous
Amplifier: Class D
Peak: 1800 W (LF), 225 W (HF)
Cooling: Low-noise, variable speed fan
Controls:
Power
3 × Level
Rotary encoder (push)
2 × selection buttons
Indicators:
Monochrome LCD Display 45 mm × 25.4 mm (1.75-inch x 1-inch)
2 × Power LED (front and rear)
3 × Input Signal LED
Input A Mic selected LED
Input B Hi-Z selected LED
Limiter active LED
Connectors:
2 × locking XLR/F ¼⁻ᶦⁿᶜʰ combo (Mic/Line Input and Hi-Z/Line Input
1 × 3.5 mm TRS (Stereo Input)
2 × XLR/M (Loop-thru Output)
1 × XLR/M (Mix Output)
1 × locking IEC power connector
AC Power Input: Universal power supply 100 – 240 VAC, 50 – 60 Hz
AC Power Consumption 1/8th Power2: 100 VAC, 2.1 A / 120 VAC, 1.9 A / 240 VAC, 1.1 A
AC Power Consumption - Standby: 0.2 A at any voltage
Enclosure Details
Enclosure: Impact Resistant ABS
Attachment Points: 2 × M10 threaded inserts plus Pull-Back
Color: Black (RAL 9011)
Grille: 18 Gauge powered coated steel, internal cloth lining
Speaker Dimensions (H×W×D):
519 × 320 × 300 mm
20.4 × 12.6 × 11.8 in
Carton Dimensions (H×W×D):
570 × 440 × 406 mm
22.5 × 17.3 × 16 in
Net Weight: 14.5 kg / 32 lb
Shipping Weight: 17.6 kg / 38.8 lb
Regulatory: CE, WEEE, UL, China RoHS, RoHS II, FCC Class B
Optional Accessories:
K10 Tote, K10 Outdoor Cover
M10 Kit-C, K.2-LOC Lock Out Cove
K10.2 Yoke

QSC KS118 18 Inch Active Powered Subwoofer Loudspeaker 3600 Watts

The KS118 is a very high output active subwoofer producing impressive low frequencies for mobile entertainers, AV production and clubs/venues applications.

The KS118 is a very high output active subwoofer producing impressive low frequencies for mobile entertainment, AV production, clubs and performance venues. Featuring an 18-inch direct radiating driver powered by a 3600 Watt Class D amplifier, the KS118 delivers high sound pressure levels with dynamic and musical sound reproduction of very low frequencies.

On-board DSP optimizes and protects system performance as well as offers advanced capabilities such as the ability to array two units in a cardioid arrangement. Highly transportable, the rugged enclosure features comfortable handles and four low noise casters. An M20 threaded pole receptacle accepts a 35 mm pole for easy vertical deployment with full-range loudspeakers.

Features:
Very high output with impressive low frequency performance
3600 Watt Class D amplifier module
18 inch (460 mm) long excursion direct radiating driver
Omni-directional or cardioid radiation modes (cardioid setup requires min. 2 units)
Selectable DEEP™ mode for extremely low frequency extension
Adjustable crossover and delay
Scenes for commonly-used applications that can be saved/recalled
Refined, professional and elegant appearance in any application
Rugged painted wood enclosure for lasting durability
Vertical or horizontal deployment (M20 threaded pole receiver for vertical setup)
Four low-noise, heavy-duty casters
Optional transport cover, KS-LOC security cover and 35 mm loudspeaker pole accessories available
6-Year Warranty with product registration

Specifications:
Configuration: Direct Radiating
LF Transducer: 460 mm (18 in), Cone
Frequency Response (-6 dB): 41 Hz - 98 Hz
Frequency Range (-10 dB): 35 Hz - 111 Hz
Nominal Coverage Angle: Omni-directional or cardioid radiation modes (cardioid setup requires min. 2 units)
Maximum Rated SPL1: 136 dB @ 1 m (peak)
Amplifier: Class D
3600W (peak)
Cooling: Low-noise, variable speed fan
Controls:
Power On/Off
Gain Control
Rotary encoder
2 × selection buttons
Indicators:
2 × Power LED (front and rear)
Input Signal LED
Limiter active LED
Connectors:
2 × locking XLR/F ¼ inch combo
2 × XLR/M (Loop-thru Output)
1 × locking IEC power connector
AC Power Input Universal power supply 100 – 240 VAC, 50 – 60 Hz
AC Power Consumption (⅛ power) 100 VAC, 3.6 A / 120 VAC, 3.0 A / 240 VAC, 1.7 A
Enclosure Details
Enclosure: 15 mm birch plywood
Color: Black (RAL 9011)
Grille: 16-gauge Black Powder Coated Steel
Speaker Dimensions (H×W×D):
640 × 520 × 785 mm
25.2 × 20.5 × 30.9 in
Carton Dimensions (H×W×D):
572 × 743 × 896 mm
22.5 × 29.3 × 35.3 in
Net Weight: 47 kg / 104 lb (including casters)
Shipping Weight: 56.5 kg / 124.6 lb
Regulatory: CE, WEEE, UL, China RoHS, RoHS II, FCC Class B
Included Accessories: 4 × Low-Noise, Heavy Duty Casters
Optional Accessories:
KS118 CVR Transport Cover, KS-LOC Lock-Out Cover
SP-26 and SP-36 Loudspeaker Poles, SP-16X Extension Pole

QSC ISA300TI 2 Channel 830 Watts Installation Power Amplifier

Designed as a cost-effective solution specifically for sound contractors, the ISA Series features versatile loading options and a comprehensive feature make it a rugged power solution for any permanently installed sound system.

Unique among distributed sound power amplifiers, the "Ti" versions of the ISA series will drive 8 or 4 ohm loads and a distributed system on the same channel simultaneously. This enables a contractor to reduce the number of required amplifier channels by allowing a limited number of distributed speakers to be attached to the same amp as is powering the main sound system.

Housed in a rugged 3-U chassis, all ISA models feature rear panel gain controls for tamper resistant operation with 2 dB detents for quick and repeatable settings. Inputs include both XLR and detachable Euro-style connectors. Outputs feature covered barrier strip connectors for safety agency compliance, and for added versatility, a DataPort V2 (Version 2) terminated with an HD-15 connector is provided for use with DPV2-compatible signal processing accessories such as the XC-3 Crossover, SF-3 Subwoofer Filter, LF-3 Low Frequency Filter and the DSP-3 with external power supply.

Selectable high-pass filters are included to protect speakers and prevent speaker transformer saturation with minimal effect on program material. The ISA Series provide additional protection circuitry including DC, infrasonic, thermal overload, RF and short circuit protection.

Features:
25, 70, 100 volt, and low-impedance outputs available simultaneously
Rear panel gain controls for tamper resistant operation with 2 dB detents for quick and repeatable settings
XLR and detachable Euro style input connectors
DataPort V2 for use with DPV2-compatible signal processing accessories (XC-3, SF-3, LF-3) and DSP-3/DSP-4 (with external power supply)
Independent defeatable clip limiters for reduced distortion
Selectable high-pass filters protect speakers and prevent speaker transformer saturation with minimal effect on program material
Front panel indicators include power, signal, and clip (and protect on ISA 1350)
Covered barrier strip output connectors for safety agency compliance
Automatic variable-speed fan for quiet normal operation with maximum cooling on demand
Rear-to-front air flow keeps equipment racks cool
Stereo, Bridge, or Parallel operating modes

Specifications:
Damping Factor (direct outputs): Greater than 200 at 8 ohms, ISA 1350 greater than 250
Output Regulation (isolated outputs): Less than 1.5 dB
Input Impedance: 10 k ohms unbalanced, 20 k ohms balanced
Input Clipping: 10 Vrms (+22 dBu)
Cooling: Continuously variable speed fan, back-to-front air flow
Connectors, each channel
Input: Active balanced; 3-pin Euro-style detachable terminal block and XLR (pin 2+)
Output: Covered barrier strips
DataPort V2: HD-15 connector
Controls
Front: AC switch
Rear: Ch. 1 and Ch. 2 gain knobs, 10-position DIP switch
Indicators
PWR-ON: Green LED; SIGNAL: Green LED (1 per channel);
CLIP: Red LED (1 per channel)
Dimensions
19" (48.3 cm) rack mounting, 5.25"(13.3cm) tall (3 rack spaces),
15.9" (40 cm) deep (from front mounting rails)
Amplifier Protection: Full short circuit, open circuit, thermal, ultrasonic, and RF protection;
Stable into reactive or mismatched loads
Power Requirements: 120, 230, VAC, 50-60 Hz
Load Protection: On/off muting

QSC AD-S6T-BK 6.5 Inch Two Way Surface Mount Loudspeaker system

The QSC AcousticDesign™ AD-S6T is a surface mounted 70/100V, 6.5" two-way loudspeaker system, ideally suited for a wide variety of foreground and background sound reinforcement applications.

AcousticDesign™ series offers integrators a premium quality installed sound solution where performance, coverage, and aesthetics are paramount. Combined with unprecedented ease-of-installation and high
weather resistance, the AcousticDesign™ Series provides integrators a versitile and confident response.

The AD-S6T features a high quality 6.5" weather treated paper cone woofer on a 1.5” voice coil. A carefully selected 1” silk dome tweeter with a 1” voice coil perfectly matches the sensitivity and performance of
the woofer for outstanding full range reproduction.

Consistent and even 105° axisymmetric (conical) coverage is realized by means of DMT™ (Directivity Matched Transition). This innovation matches the high frequency wavegide to the woofer coverage at the crossover point, resulting in a coherent transducer transition and improved off axis response.

To maintain this frequency response, the AD-S6T utilizes a variable tap 60 watt low saturation and low loss 70/100V transformer with 8Ω bypass, accessible via a rotary selector located on the enclosure back under a weather grommet for improved weather resistance. All AcousticDesign™ Series surface-mount loudspeakers are housed in rugged ABS enclosures for long-term durability. Sealed input panel covers and powder coated
aluminum grilles add weather resistance, exceeding IEC60529 IP-54 for dust and splash resistance.

Installers will appreciate the award winning X-Mount™ system, included with each full range AcousticDesign™ model. This ingenious mounting solution achieves unprecedented ease-of-installation in either horizontal, vertical, wall, or ceiling deployments. Knurled surfaces at the pivot planes ensure the load will not drift or sag over time. Articulation marks allow preconfiguration of the X-Mount™ while on the ground with no special tools required. Once secure, the loudspeaker installs in seconds, allowing the installer to work safer, smarter, and faster with repeatable results. To further enhance performance and speed of install with optimum result, advanced voicing filter sets using QSC Intrinsic Correction™ techniques are obtainable
using the Q-SYS Platform including CXD Series amplifiers for a complete QSC systems solution.

Sensitive to aesthetic demand, the AcousticDesign™ Series feature a stylish appearance free of obtrusive logo adornments. Complimenting adjacent product families, AcousticDesign™ surface loudspeakers are available in QSC standard black (RAL 9011) or white (RAL 9010) and may be painted to match any decor. To assist in successful systems integration, complete EASE, CAD, and BIM files are available for online download at QSC.com.

Features:
6” weather treated woofer; 1” silk dome tweeter
105° Axisymmetric (conical) coverage
80 watt low-saturation and low-loss 70/100V transformer with 8Ω bypass
DMT™ (Directivity Matched Transition) ensures smooth, uniform frequency response over the coverage area
X-Mount™ system enables the loudspeaker to be easily installed and deployed at a variety of angles with no slippage over time
Advanced voicing filter sets using QSC Intrinsic Correction™, available through either Q-Sys processing or CXD amplifier platforms
Lightweight ABS enclosures offer long-term durability and lasting good looks
Sealed input panel cover and powder coated aluminum grilles for added weather resistance
Meets IEC60529 IP-54 for dust and splash resistance
Available in black (RAL 9011)
Complete EASE, CF2, CAD, and BIM information available online

Specifications:
HF transducer: 1” silk dome tweeter / 1” voice-coil horn loaded
LF transducer:
6.5” weather treated paper cone woofer,
1.5” / 38mm voice-coil
Effective frequency range: 1 60 – 20k Hz
Rated noise power / voltage: 2 150 watts / 35 volts (rms)
Broad-band sensitivity: 3 89 dB SPL
Coverage angle (-6 dB): 105°
Directivity factor (Q): 5
Directivity Index: 7 dB
Maximum continuous SPL4: 110 dB
Maximum peak SPL4: 116 dB
Rated impedance: 8 ohms
Recommended amplifier power: 300 watts
Transformer taps:
70 V: 60, 30, 15, 7.5 watts and 8 ohm bypass
100V: 60, 30, 15 watts and 8 ohm bypass
Input connector type: Euroblock connector with parallel output
Enclosure material: Painted ABS polymer
Grille material: Powder coated aluminum
Enclosure Details
Ingress protection: IP-54
Operating environment: Designed for indoor and outdoor use
Testing: The AD Series loudspeakers qualified for outdoor use using the following tests:
Salt fog: MIL-STD-810G Method 509.5 for 100 hrs.
Humidity: MIL-STD-810G Method 507.5, Natural cycle B2, cyclic high RH for 7 days
High and low temperature: tested according to QSC
internal standards between -20° and 50° C
Operating Temperature Range: -20 to 50 °C / -4 to 122 °F
Net weight: 13.6 lbs / 6.2 kg
Product dimensions: 14.4” x 8.5” x 8.5” (365 x 215 x 215mm)
Shipping weight: 33.4 lbs / 15.2 kg (pair packed)
Shipping dimensions: 20 x 12” X 23” (510 x 305 x 585mm) (pair packed)
Included accessories: X-Mount mounting system, euroblock connector,
input panel cover
1 Free-field, -10 dB from on-axis sensitivity
2 IEC60268-1 noise signal for 2 Hrs
3 On-Axis, free-field sensitivity, 2.83V, 1 m
4 Calculated from rated noise voltage and sensitivity

QSC GX3 2 Channel Power Amplifier for Speakers 300 Watts Range

Power levels matched to the most popular speakers. Inputs: XLR, 1/4-inch TRS and phono. Outputs: Speakon® combo and binding posts.

Features:
Power levels matched to the most popular speakers used by entertainers
Optimized for maximum real-world headroom into 4- and 8-ohm speaker systems
Inputs: XLR, 1/4-inch TRS and phono input connectors for compatibility with any source
Outputs: Speakon® combo accepts 1/4-inch (TS) plugs or Speakon 2- and 4-pole plugs (connects 2 poles only). Binding posts support all other speaker wiring systems
Minimum depth chassis (10.1-inch / 257 mm) fits in compact, inexpensive effects racks
Lightweight - GX3 and GX5 less than 26 lb (12.5 kg). GX7 only 15.5 lb (7 kg)*
Detented gain controls for precise setting and matching of sensitivity
GuardRail™ automatically protects the amplifier and loudspeakers from damage due to temperature rise or overdrive without shutting down the show
Front panel LEDs monitor power, signal, and clipping
Subwoofer/satellite crossover built-in
* 230V 16.5 lb (7.5 kg)

Specifications:
Output power per channel
8Ω continous, both channels driven: 300 W
4Ω continous, both channels driven: 425 W
Distortion (1 dB below rated power, 1 kHz):
8 ohms: less than 0.02%
4 ohms: less than 0.05%
Signal to Noise (20 Hz - 20 kHz): 100 dB
Input Sensitivity: 1.2 V rms
Voltage Gain: 32.2 dB
Output Circuitry: Class B
Power Requirements (1/8 power, pink noise at 4 ohms, 120V): 6.3 A
Frequency Response: 20 Hz–20 kHz, +0, -1 dB
Dynamic Headroom (4 ohms): 2 dB
Input Impedance: Greater than 20 kΩ (balanced)
Maximum Input Level: +24 dBu (16 V rms)
Input Connectors (each channel): 3-pin XLR and 1/4-inch TRS, balanced, parallel Phono, unbalanced
Output Connectors (each channel): Speakon®, 1/4-inch, Binding posts
Amplifier and Load Protection: Short circuit, open circuit, thermal, RF protection Load protected against DC faults
Front Panel Controls and Indicators: Gain controls, 21 detents Red CLIP LEDs, proportional, 0.1% THD threshold Green SIGNAL LEDs, threshold 35 dB below clipping Blue POWER LED, AC on
Rear Panel Controls: Full Range / Crossover switch 100 Hz, 3rd order LP (sub), 2nd order HP (top)
Product Dimensions (H×W×D): 89 × 483 × 257 mm 3.5 × 19 × 10.1 in
Carton Dimensions (H×W×D): 610 × 380 × 153 mm 24 × 15 × 6 in
Net Weight: 12.1 kg / 27 lb
Shipping Weight: 13.2 kg / 29.1 lb
Agency Approvals: UL, CE, RoHS/WEEE Compliant
AC Current and Heating, 120 VAC
(multiply current by 0.5 for 230 VAC) GX3
Operating Condition       AC amps             BTU/hour
Idle                                   0.2                  44
8 + 8 ohms, 1/8 power 1    4.1                  904
8 + 8 ohms, 1/3 power 2    6.1                  1160
8 + 8 ohms, full power3     9.75                 1109
4 + 4 ohms, 1/8 power 1    6.3                  1515
4 + 4 ohms, 1/3 power 2    9.4                  2105
4 + 4 ohms, full power3     15.0                 2297

QSC AD-S8T-BK 8 Inch Two Way Surface Mount Loudspeaker System 200 Watts

The QSC AcousticDesign™ AD-S8T is a surface mounted 70/100 V, 8" two-way loudspeaker system, ideally suited for a wide variety of foreground and background sound reinforcement applications.

AcousticDesign™ series offers integrators a premium quality installed sound solution where performance, coverage, and aesthetics are paramount. Combined with unprecedented ease-of-installation and high weather resistance, the AcousticDesign™ series provides integrators a versatile and confident install solution.

The AD-S8T features a high quality 8” weather treated paper cone woofer on a 2” voice coil. A carefully selected 1” exit, 1.4” compression driver perfectly matches the sensitivity and performance of the woofer for outstanding full-range reproduction.

Consistent and even 105° axisymmetric (conical) coverage is achieved through DMT™ (Directivity Matched Transition), a QSC innovation which matches the directivity patterns of the woofer and the highfrequency waveguide at the crossover point. The result is a coherent transition between transducers and improved off-axis response.

The even, accurate frequency response of the AD-S8T is aided by a 60-watt low-loss, low saturation transformer with selectable taps, including an 8 Ω bypass. To enhance weather resistance, the rotary
selector is located on the back of the enclosure, protected by a weather grommet

With rugged ABS enclosures, sealed input panel covers, and powder-coated aluminum grilles for weather resistance, the AcousticDesign™ surface mounted series exceed IEC60529 IP-54 ratings for dust and splash resistance.

Installers will appreciate the award-winning X-Mount™ system included with each full-range AcousticDesign™
model. This ingenious mounting solution achieves unprecedented ease-of-installation in horizontal, vertical, wall, or ceiling deployments. Knurled surfaces at the pivot planes ensure the load will not drift or sag over time. Articulation marks allow preconfiguration of the X-Mount™ while on the ground with no special tools required. Once secure, the loudspeaker installs in seconds, allowing the installer to work safer, smarter, and faster with repeatable results.

The AD-S8T also includes M10 fittings for optional yoke mount (YMS8T) or shoulder eybolt (M10 Kit-C)
accessories for installation versatility.

To further enhance performance and speed of install with optimum result, advanced voicing filter sets using QSC Intrinsic Correction™ techniques are obtainable using Q-SYS networked audio processing platforms, including CX-Q Series network amplifiers for a complete QSC systems solution.

The AcousticDesign™ series feature a stylish appearance free of obtrusive logo adornments for aesthetically sensitive installations. AcousticDesign™ surface loudspeakers are available in QSC standard
black (RAL 9011) or white (RAL 9010) and may be painted to match any decor.

Features:
DMT™ (Directivity Matched Transition) ensures smooth, uniform frequency response over the coverage area
X-Mount™ system enables the loudspeaker to be easily installed and deployed at a variety of angles with no slippage over time
Advanced voicing filter sets using QSC Intrinsic Correction™, available through either Q-SYS processing or QSC DSP amplifier platforms
Low-saturation and low-loss 70/100V transformers with 8 Ω bypass
Lightweight ABS enclosures offer long-term durability and lasting good looks
Sealed input panel cover and powder coated aluminum grilles for added weather resistance
Meets IEC60529 IP-54 for dust and splash resistance
M10 fittings for optional yoke mount or suspended installations
Available in black (RAL 9011)
Complete EASE, CAD & BIM information available online

Specifications:
System Detail
Effective frequency range: 1 55 – 20 k Hz
Rated noise power / voltage: 2 200 W / 40 V (RMS)
Broad-band sensitivity: 3 90 dB SPL
Coverage angle (-6 dB): 105°
Directivity factor (Q): 7
Directivity Index: 9 dB
Maximum continuous SPL4: 113 dB
Maximum peak SPL4: 119 dB
Rated impedance: 8 Ω
Recommended amplifier power: 400 W
Transformer taps:
70 V: 60, 30, 15, 7.5 W and 8 Ω bypass
100 V: 60, 30, 15 W and 8 Ω bypass
HF transducer: 1" exit / 1.4" voice-coil compression driver
LF transducer:
8 in weather resistant paper cone woofer,
2 in / 51 mm voice-coil
Input connector type: Euroblock connector with parallel output
Enclosure material: Painted ABS polymer
Grille material: Powder coated aluminum
X-Mount material: Powder coated aluminum
Enclosure Details
Ingress protection: IP-54
Operating environment: Designed for indoor and outdoor use
Testing: The AD Series loudspeakers qualified for outdoor use using the following tests:
Salt fog: MIL-STD-810G Method 509.5 for100 hrs.
Humidity: MIL-STD-810G Method 507.5, Natural cycle B2, cyclic high RH for 7 days
High and low temperature: tested to QSC internal standards between -20° and 50° C
Operating Temperature Range: -20 to 50 °C / -4 to 122 °F
Net Weight: 24.1 lb / 11 kg
Product dimensions: 17.3 x 10 x 9.9 in (440 x 254 x 251mm)
Shipping weight: 32.1 lb / 14.5 kg
Shipping dimensions: 24.3 x 13.8 X 13.8 in (729 x 351 x 351mm)
Included accessories: X-Mount mounting system, Euroblock connector, input panel cover
Optional accessories: YMS8T yoke mount, M10 Kit-C

QSC K10 TOTE Active Loudspeaker Soft Padded Carrying Bag Fits K10 Loudspeaker

Soft, padded tote made with weather resistant, heavy-duty Nylon/Cordura® material for K10.2 and legacy K10.

Features:
Soft, padded tote made with weather resistant,
Heavy-duty Nylon/Cordura material
For K10 Loudspeaker

QSC CP12 Two Way 12 Inch Powered PA Active Loudspeaker System 1000 Watts

High performance, superior quality and lasting reliability. These are the hallmarks of the QSC brand and the reason why millions of professionals the world-over have come to trust QSC to help them confidently deliver superior experiences and memorable performances. The CP Series follows in that same tradition while also offering an ultra-compact form factor and class-leading value.

The 1000 Watt (peak) power module delivers ample burst and continuous power for the loudspeaker’s matching transducers. Convection cooling provides heat dissipation, even in extreme climates, while contributing no additional background noise. Carefully tailored, subtle and sophisticated dynamics processing is used to protect the drivers from damage and the performance from distortion. The result is a highly accurate and musical sound that maintains full signal integrity, even when pushed to high SPL.

CP produces a big sound from a small package. Ultra-compact and remarkably light weight, CP is easy to load, carry, lift and deploy in a wide range of portable and installed applications.

CP presents a compact, unobtrusive and stylish appearance that looks great in a wide range of applications. Both models can be utilized as either main PA (with included pole mount), floor monitor or installed via optional quick-connect yoke mount.

* 1 year warranty may be extended by an additional 5 years, with QSC Product Registration

Features:
Compact and powerful performance
1000 Watt peak power Class-D amplifier module
Easily selected contours for commonly-used applications
Advanced DSP with Intrinsic Correction™ for superior sound quality and speaker protection
Directivity Matched Transition® (DMT) for consistent frequency response across the entire coverage area
Light weight and highly portable
Professional appearance looks great in any application
Use for main PA, stage monitor, or instrument amplifier
35 mm pole socket
Optional yoke, tote, and outdoor cover accessories
Complete EASE and CAD information available online
6-Year Warranty*

Specifications:
Configuration Two-way active loudspeaker
LF Transducer: 305 mm (12 in), cone
HF Transducer: 35.6 mm (1.4 in) compression driver
Frequency Response (-6 dB): 49 - 20 kHz
Frequency Range (-10 dB): 47 - 20 kHz
Nominal Coverage Angle: 75° Axisymetric
Maximum Rated SPL1: 126 dB
Amplifier:
Class D
Peak: 800 W (LF), 200 W (HF)
Controls:
Power
2 × Gain
Mic Boost Push Switch
6-way Contour Selection Switch
Indicators:
Power LED
2 × Input Signal LED
Input B MIC selected LED
Limiter active LED
Connectors:
2 × locking XLR/F ¼” combo (Line Input and Mic/Line input)
1 × 3.5 mm TRS (Stereo Input)
1 × XLR/M (Mix Output)
1 × IEC power connector
AC Power Input: Universal power supply 100 – 240 VAC, 50 – 60 Hz
AC Power Consumption (1/8th Power): 100 VAC, 0.75A - 240VAC 0.31A
Enclosure Material: Polypropylene
Attachment Points: M8 threaded insert
Color: Black (RAL 9011)
Grille: 18 Gauge powder-coated steel
Speaker Dimensions (H×W×D):
516 × 350 × 323 mm
20.3 × 13.8 × 12.7 in
Carton Dimensions (H×W×D):
430 × 430 × 604 mm
17 × 17 × 23.8 in
Net Weight: 13.7 kg / 30.3 lb
Shipping Weight: 16.5 kg / 36.4 lb
Regulatory: EMC, UL, CB
Optional Accessories: CP12 Tote, CP12 Outdoor Cover, CP12 Yoke

QSC K12.2 YOKE Powder Coated Steel Yoke Mount for K12.2 Loudspeaker

Powder coated steel yoke for mounting the K12.2 vertically or horizontally to walls, beams, or other structures.

Features:
Powder coated steel yoke
Mounting K12.2 loudspeaker
Mount to Walls, Beams, or Structures

QSC E110-BK Two Way 10 Inch PA Passive Loudspeaker Subwoofer 1200 Watts

The E110 is a compact, two-way loudspeaker with a 10-inch, die cast frame woofer with a 2.5-inch voice-coil housed in a multi-purpose enclosure that’s at home in stage monitor or main PA deployment. It incorporates QSC’s Directivity Matched Transition® (DMT) design with a wide 85° coverage. When used as a stage monitor, the E110 is angled up at a 55° angle allowing it to be placed near the performer when used on a crowded stage.

E Series loudspeakers will perform very well with any quality, professional power amplifier – but by taking advantage of the complete E Series Entertainment System, more performance and options are available. Today’s powered loudspeakers rely on finely tuned digital signal processing (DSP) to achieve a higher level of performance. When used with QSC GXD or PLD amplifiers or with a QSC TouchMix digital mixer, E Series loudspeakers can also take advantage of advanced DSP. QSC has developed E Series DSP settings for all three platforms. These settings support a variety of applications including live sound reinforcement (with and without subwoofers), stage monitoring, dance music and karaoke.

Features:
High output, professional quality sound with 300 W continuous power
E Series Entertainment System – Advanced digital signal processing tunings and options using QSC GXD, PLD amplifiers or TouchMix digital mixers.
E Series Entertainment System DSP Tunings are now available for PLD, CXD and GXD processing amplifiers:
- For PLD/CXD visit Amplifier Navigator Software
- For GXD visit the GXD Firmware Updater
Rugged tour-grade textured paint
Foam-lined perforated steel grill
Suitable for main PA and stage monitor
Available U-Style Yoke and M8 rigging kit for permanent installation
Dual angle pole socket

Specifications:
Configuration: 1 × 10-inch, 2-way, non-powered
Frequency Response (-6 dB): 68Hz – 20kHz
Frequency Range (-10 dB): 50Hz - 20kHz
Power capacity²: continuous/peak: 300 W / 1200 W
Sensitivity: 95 dB, 1 W @ 1 m
Coverage Angle: 85° conical DMT™
Output1 (Peak SPL @ 1m): 126 dB
Drivers
LF: 254 mm (10 in) driver with 64 mm (2.5 in) voice coil;
HF: 25 mm (1 in) exit, 45 mm (1.75 in) voice coil, compression driver
Nominal Impedance: 8Ω
Cross-over: Full-range only, 1.8 kHz
Input Connections: 2 × NL4, 1 × barrier strip
Enclosure: Multi-angle plywood, black texture paint finish. One top-mounted handle. Perforated, powder-coated steel grille with foam lining.
Mounting and suspension: 9 × M8 suspension points, dual angle, 35 mm pole-socket
Speaker Dimensions (W×H×D):
330 × 560 × 330 mm
13 × 22 × 13 in
Carton Dimensions (H×W×D):
430 × 430 × 660 mm
17 × 17 × 26 in
Net speaker weight: 20 kg / 44 lb
Shipping weight: 23 kg / 50 lb

QSC K8 TOTE Active Loudspeaker Soft Padded Carrying Bag for K8 Loudspeaker

Soft, padded tote made with weather resistant, heavy-duty Nylon/Cordura® material for K8.2 and legacy K8.

Features:
Soft, padded tote made with weather resistant
Heavy-duty Nylon/Cordura material
For K8.2 Loudspeaker

QSC AD-S282H-BK Dual Two Way 8 Inch Surface Mount Loudspeaker 900 Watts

The QSC AcousticDesign AD-S282H is a full range, surface mount loudspeaker with a sleek, contemporary styling that fits perfectly into multiple surroundings and applications including hotels, restaurants, convention facilities, and multimedia environments. The speaker incorporates the Advanced Directivity™ rotatable waveguide. Available in black or white, these weather resistant enclosures can be painted to match any specific décor.

The AD-S282H is a 2-way system housed in a ported enclosure made from injection molded, high-impact polystyrene. This enclosure incorporates two 8" weather-resistant, LF transducers with heavy-duty double roll cloth surrounds. These high output versions employ a 1" exit compression HF driver. The HF driver is coupled with QSC's unique Advanced Directivity rotatable waveguide - enabling the loudspeaker to deliver accurately focused sound, regardless of its mounted orientation.

Features:
Contemporary Style, Weather Resistant Enclosure and Components - ideal for a wide range of applications
Dual 8-Inch, 2-Way System - in a lightweight, multipurpose enclosure featuring a heavy duty, powder coated aluminum grill
Versatile Mounting Options - The included yoke mount bracket can be used for mounting and aiming the system in vertical or horizontal orientations. Provision for optional Omni-mount™ bracket is built in.
Advanced Directivity™ Rotatable Waveguide - (90° x 60°) enables the loudspeaker to deliver accurately focused sound, regardless of the enclosure's mounted orientation
Yoke mount included

Specifications AD-S282H
Configuration: Compact 2-way, ported enclosure
Transducers
Low-frequency Transducers: Dual 8" high power, treated paper cone, 2" voice coil, neodymium magnet
High-frequency Transducer : 1" high output compression driver
Frequency Range1:
Frequency Response (-6 dB): 80 Hz - 27.7 kHz
Useable Frequency Range (-10 dB): 60 Hz - 29.5 kHz
Maximum Output2
Calculated Peak Output: 125 dB SPL
Calculated Continuous Output: 119 dB SPL
Nominal Impedance: 8Ω nominal (5.25Ω minimum, 17.6 kHz, 64.22Ω maximum, 2.56 kHz
Power Rating:
RMS Power Handling: 3 450 W (8 hours IEC)
Recommended Max Amp Power: 900 W RMS
Sensitivity: 93 dB, 1 m, free field
Nominal Coverage (HV): 90° x 60° (-6 dB) rotatable to 60° x 90°
Bass Loading: Ported, tuned to 60 Hz
Transformers
Type: Custom low distortion laminated core, wide bandwidth design
Taps: 70 V: 200, 100, 50, 25 W | 100 V: 200, 100, 50 W
Bypass: 8Ω bypass on AD-S282HT
Enclosure
Material: Injection molded, weather resistant, high impact polystyrene
Finish: White or black (paintable)
Weather Resistant: Yes
Grille: Heavy duty powder coated aluminum
Connectors: Barrier strip (switchable: passive/active on AD-S282H)
Mounting Hardware: Yoke mount included
Weight - Net / Shipping: 27.7 lb (12.6 kg) / 35.6 lb (16.1 kg)

QSC KS118-CVR Transport Soft Cover Bag for KS118 18" Subwoofer Loudspeaker

QSC KS118-CVR Soft cover made with heavy-duty Nylon/Cordura® material intended to protect your KS118 18" subwoofer during transport.
Features:
For the KS118 with grille guard.
Soft cover made with heavy-duty Nylon/Cordura® material

QSC KLA12-BK Two Way 12 Inch Active Line Array Loudspeaker System

The KLA Series brings the power and sophistication of a line array system into an easy-to-use product significantly redefining the line array product category. With its simple Lift, Click and Play approach, KLA can be deployed in a fraction of the time required by comparable line array products.

This fixed arcuate, active line array system is ideal for a wide range of portable and permanently installed applications ranging from live entertainment to houses of worship or other venues where a line array system is desired.

KLA Power Module
The KLA Series is comprised of two models, the KLA12 12-inch, 2-way loudspeaker and the KLA181 18-inch subwoofer. The KLA12 features a highly efficient 500 watt by 500 watt power amp module and the KLA181 offers the same highly efficient power amp module in a 1,000 watt configuration. This efficient design enables up to five KLA models (any combination of KLA12 and KLA181) to be driven off of a single 15 amp, 120 volt electrical circuit.

KLA loudspeakers incorporate QSC's DEEP™ DSP algorithm - providing extended bass response by actively managing potentially damaging low-frequency transients - and GuardRail™ circuitry protection which prevents the amplifier module from unnatural and destructive clipping.

As an energy saving feature, the Auto Standby mode automatically engages after five minutes of inactivity but upon resumption of audio signal, the power module on the KLA will awaken instantly for immediate output.

In an installed application, multiple KLA Series loudspeakers can be "daisy-chained" for total gain control from a single remote pot wired to the on-board Phoenix-style connector. Additional power module characteristics on KLA include a balanced, line-level XLR input in parallel with an XLR "Thru" connector, PowerCon™ In and Thru connectors, Attenuation Control and LED indicators for Signal, Limit, Power and Standby status.

KLA12
Housed in a rugged ABS enclosure that results in both light weight and long-term durability, the KLA12 features a 12-inch low frequency transducer coupled with a 1.75-inch compression driver. Designed to be used exclusively as a fixed arcuate line array, each KLA12 is set at a 90° horizontal by 18° vertical splay angle, allowing 90° vertical coverage arrays to be configured using only five boxes (most other solutions require six).

KLA's unique self-contained SOLO™ (Single-Operator Logistics) Rigging System enables users to quickly assemble (and disassemble) the line array in a fraction of the time without the need for special tools or external hardware.

Features:
500 W + 500 W power module
Rugged, ABS enclosure delivers light-weight durability
SOLO™ Rigging System supports deployment without tools or external hardware
Ar-Q™ Array Equalization quickly tunes the array with the click of a dial, adjusting for the appropriate number of boxes
10:1 design factor supports arrays of up to 480 lbs. (218 kg) 5 × KLA12 and 2 × KLA181
90° × 18° nominal coverage (requires only five boxes to configure a 90° x 90° array)
High power, 12-inch low frequency driver provides extension down to 44Hz without subwoofers
Extensive DSP further enhances and protects performance
1.75-inch diaphragm compression driver delivers clear and powerful high-frequency reproduction
powerCON® Input and Thru connections
Tilt-Direct™ pole mount assists directivity in single-unit applications

Specifications:
Configuration: Multipurpose 2-way
Transducers
High Frequency:1.75-inch diaphragm compression driver
Low Frequency: 12-inch cone transducer
Frequency Response (-6 dB): 49 Hz - 18 kHz
Frequency Range (-10 dB): 44 Hz - 20 kHz
Nominal Coverage: 90° H × 18° V
Maximum SPL (1 meter): 131 dB peak
Amplifiers
Power Output:
HF: 500 W Class D continuous
LF: 500 W Class D continuous
Input Impedance XLR: 40 kΩ balanced / 20 kΩ unbalanced
Controls: Power, Attenuation, LF Setting (External Sub/Normal/DEEP™), Array Size (1-5), Front LED (Pwr/Limit/Off)
Indicators: Power, Signal, Standby, Limit
Connectors: Balanced female XLR line level input, Balanced male XLR full range line level out, Remote attenuation control, Locking powerCON power connector AC In, Locking powerCON® power connector AC Out
Cooling: On demand, 50 mm variable speed fan
Amplifier Protection: Thermal limiting, output overcurrent, overtemperature muting, GuardRail™
Transducer Protection: Thermal limiting, excursion limiting
AC Power Input: Universal power supply 100–240 VAC, 50 to 60 Hz
AC Power Consumption (1/8 Power):
100 VAC, 2.3 A
120 VAC, 2.01 A
230 VAC, 1.13 A
Enclosure
Material: Impact resistant ABS
Finish: Black
Grille: Rugged powder coated steel grille
Speaker Dimensions (H×W×D):
382 × 594 × 422 mm
15.0 × 23.4 × 16.6 in
Carton Dimensions (H×W×D):
690 × 430 × 534 mm
27.2 × 16.9 × 21 in
Net Weight: 25 kg / 55 lb
Shipping Weight: 30.8 kg / 67.9 lb

QSC E112 Trapezoidal Two Way 12 Inch Passive Loudspeaker System 1600 Watts

The E112 is a trapezoidal, two-way loudspeaker using a 12-inch die cast aluminum woofer with a 3-inch voice-coil. The 15mm, 11-ply enclosure provides enough volume to deliver solid low-frequency extension down to 65 Hz making it an excellent choice for applications in which space or budget preclude the use of a subwoofer. The DMT coverage angle of 85° is ideal for most medium and medium-long throw applications.

E Series loudspeakers will perform very well with any quality, professional power amplifier – but by taking advantage of the complete E Series Entertainment System, more performance and options are available. Today’s powered loudspeakers rely on finely tuned digital signal processing (DSP) to achieve a higher level of performance. When used with QSC GXD or PLD amplifiers or with a QSC TouchMix digital mixer, E Series loudspeakers can also take advantage of advanced DSP. QSC has developed E Series DSP settings for all three platforms. These settings support a variety of applications including live sound reinforcement (with and without subwoofers), stage monitoring, dance music and karaoke.

Features:
High output, professional quality sound with 400 W continuous power
E Series Entertainment System – Advanced digital signal processing tunings and options using QSC GXD, PLD amplifiers or TouchMix digital mixers.
E Series Entertainment System DSP Tunings are now available for PLD, CXD and GXD processing amplifiers:
For PLD/CXD visit Amplifier Navigator Software
For GXD visit the GXD Firmware Updater
Rugged tour-grade textured paint
Foam-lined perforated steel grill
Available U-Style Yoke and M10 rigging kit for permanent installation
Dual angle pole socket

Specifications:
Configuration: 1 × 12-inch, 2-way, non-powered
Frequency Response (-6 dB): 64 Hz – 20 kHz
Frequency Range (-10 dB): 46 Hz – 20 kHz
Power capacity1: continuous/peak: 400 W / 1600 W
Sensitivity: 96 dB, 1 W @ 1 m
Coverage Angle: 85° conical DMT™
Output2 (peak SPL @ 1m): 128 dB
Drivers:
LF: 305 mm (12 in) driver with 76 mm (3 in) voice coil
HF: 25 mm (1 in) exit, 45 mm (1.75 in) voice coil, compression driver
Nominal Impedance: 8Ω
Cross-over: Full range only, 1.8 kHz
Input Connections: 2 × NL4, 1 × barrier strip
Enclosure: Trapezoidal, plywood, black texture paint finish. Two side-mounted handles. Perforated, powder-coated steel grille with foam lining.
Speaker Dimensions:
(W×H×D) 360 × 616 × 371 mm
14.2 × 24.2 × 14.6 in
Carton Dimensions (W×H×D):
460 × 460 × 712 mm
18 × 18 × 28 in
Net Speaker Weight: 23 kg / 51 lb
Shipping Weight: 25.4 kg / 56 lb

QSC TOUCHMIX-16 16 Channel Compact Digital Mixer USB Touchscreen

TouchMix® is quite simply the most powerful, compact mixer ever created. It offers the features, capabilities and sound quality of the world's most esteemed large format consoles in a highly compact and portable package that’s small enough to be carry-on luggage. Perfect for musicians, bands, AV production professionals and small performance venues, the TouchMix-16 goes "Beyond Mixing" by offering Wizards, Presets and other beneficial tools that help both seasoned audio professionals and novices alike get great results quickly and easily.

Its 22 mixing channels (16 Mic/Line, 4 Line, Stereo USB) and 12 outputs offer ample signal management flexibility while advanced features such as class-A microphone preamps, Anti-Feedback and Room Tuning Wizards, real-time analyzer (RTA) and 20-channel direct-to-external-drive recording make it equally competent as both a professional live sound or recording tool.

The touch-and-turn interface of TouchMix allows for tactile control over fader and mixer parameters while also providing a hardware connection to the mixer. Mixer functions and displays are duplicated via iOS® or Android® devices over Wi-Fi, providing both portable, wireless connectivity as well as additional control of mixer functionality.

The TouchMix-16 comes complete with USB Wi-Fi adapter and carrying case.

Features:
Capacitive touchscreen offers a wealth of on-screen information while also providing confident hands-on control
120 presets provide real-world live sound settings for commonly-used instruments and microphones (see Presets Listing under Resources / Support)
Simple and Advanced modes offer either basic or comprehensive controls
Anti-Feedback and Room Tuning Wizards simplify complex equalization tasks
Real-time analyzer (RTA) provides instantaneous display of channel tonal balance and room response
10 Aux mixes provide superior monitor configuration capabilities
22-channel direct-to-hard drive record/playback — capture and recall performances without the need for an external computer
MP3 playback direct from USB
On-board multi-language user guide
Download future upgrades directly from the Internet

Specifications:
178 mm (7 in) diagonal color TFT, capacitive touch sensing
Total: 22
Mic/Line: 16 (12 XLR, 4 XLR combo)
Line: 2 Stereo (1/4" TRS)
Stereo USB: Stereo USB / MP3 playback
Talkback: 1 (XLR)
Input Channel Processing
EQ: 4-band Parametric EQ with Hi/Low Shelving option, variable 24 db/octave HPF and LPF
Dynamics: Gate, Compressor
Delay: Delay (100 msec max)
Automatic Microphone Mixer: Gain Sharing, 24 channels, two instances (requires firmware 1.3 or higher)
Mic & Line Input Channel Processing: 4-band parametric EQ with Hi/Low shelving option • variable 24db/octave Low-cut & High-cut filters • Gate • Compressor
2-Track (USB) & FX Return Processing: 2-band shelving EQ • variable 24db/octave Low-cut • Gate • Compressor
Output Channel Processing: Main outputs and auxes 1–6: 1/3 octave GEQ • Limiter • 4 full-frequency notch filters • Variable 18dB/oct Low-cut and High-cut filters
Auxes 7/8 & 9/10 (TM-16 only): 4-band PEQ, Limiter • Additional variable 18dB/oct Low-cut and High-cut filters
Recording: 1 14 tracks, requires USB 3.0 HD • FAT32 format • minimum 7800 RPM 22 tracks, requires USB 3.0 HD • FAT32 format • minimum 7800 RPM
Groups: 8 DCA groups (with mutes) • 8 Mute groups
Cue: Selectable AFL or PFL
Effects: 4 professional effects engines configurable as reverb (2 types) • pitch shift • mono delay • stereo delay • chorus.
1 Pitch Correct (assignable to any mono input channel)
Scene and Preset Memory: Scenes: 130 user-defined scenes, including all mixer parameters may be stored internally or on FAT32 formatted USB
Channel and FX Presets: 130 user-defined channel presets and 130 FX presets may be stored internally or on FAT32 formatted USB
External Control: 2 iOS TouchMix app for iPad, iPad mini, iPad Air. Control via Wi-Fi provides access to all mixer functions. Requires iOS 6 or higher.
Wi-Fi: 3 USB Wi-Fi adapter included
Dimensions (HWD):
58 mm x 360 mm x 291 mm
2.3” x 14.2” x 11.5”
Weight: 5.9 lb (2.98 kg)
Line Voltage Requirements: 100 - 240 VAC, 50 - 60 Hz
Sampling Frequency Selectable: 44.1kHz or 48kHz
Internal Processing: 32-bit floating point
Latency: <1.6msec, any input to any output
THD: <0.005%, +4 dBu, 20 Hz - 20 kHz, unity gain, any input to any output
Frequency Response: 20 Hz - 20 kHz +/-0.5 dB, any input to any output
Dynamic Range: 105 dB
Equivalent Input Noise: -126 dBu
Residual Output Noise: -86 dBu
Crosstalk: -80 dB
S/N Ratio: -94 dB
Maximum Input Level: +16 dBu (Mic/Line inputs, XLR), +26 dBu (Mic/Line inputs, TRS), +22 dBu (Stereo inputs)
Phantom Power: 48V, individually switchable per channel
Included Accessories: USB WiFI adapter, Soft Carrying Case, Power Supply

QSC GXD8 2 Channel Processing Power Amplifier Stereo DSP 4500 Watts

GXD Series amplifiers are ideal for entertainment and production applications requiring performance and the convenience of integral signal processing. The hallmarks of the QSC brand – professional audio quality, engineering and manufacturing focused on long-term reliability - are all intrinsic to GXD.
Add contemporary styling, multiple routing options, light weight, digital signal processing and advanced protection circuitry, and the GXD Series clearly represents real value – something everyone can use.

The GXD series is optimized for use with 8 ohm loudspeaker loads. GXD amplifiers deliver just the right amount of power to the most popular speakers used by entertainers and production professionals.

The Right Power
There’s a GXD amplifier within 1dB of the ideal power for your speaker system. Best practice is to use an amplifier capable of delivering approximately twice the loudspeaker’s rated power capacity. Too little amplifier and the speakers won’t deliver everything they’re capable of and the risk of destructive amplifier clipping is increased. Too much power probably means unnecessary amplifier expense. To determine the power points for the GXD series, QSC examined the loudspeakers most widely used for sound reinforcement by musicians, DJs and production professionals. Overall, these speakers are equipped with
woofers that fall into a couple of categories of continuous power capacity - low-power drivers
that can handle 150 - 250 watts, and mid to high-power drivers rated around 250-400 watts. Single woofer loudspeaker systems using these drivers will typically have an impedance of 8Ω. Dual woofer loudspeakers will, of course, have power ratings that are two times that of the single woofer model and an impedance that is half that of single-woofer models.

Digital Signal Processing
The GXD amplifiers are unlike other amps in this category that provide little more than a front panel screen to control the same functions that have been under rear-panel, DIP switch control for decades. The GXD amps bring full-function loudspeaker processing capability to a new price point with all the processing necessary to get the most from a loudspeaker system. The DSP section includes High and Low-Pass filters (24dB LR), 4-band parametric equalizer, signal alignment delay, and RMS/Peak speaker protection limiting. Twenty presets for selected typical systems are provided as generic “starting points” are included.

Digital Limiting
The most common cause of loudspeaker failure is amplifier clipping. The digital limiter used in the GXD amplifiers is set to prevent the amplifier from being driven into clipping while delivering the maximum usable output. In addition to amplifier limiting it also provides smart speaker protection by simply
setting the loudspeaker’s continuous power and impedance (4Ω and 8Ω), and selecting whether Mild, Medium or Agressive protection is desired.

Features:
High peak output power with up to 4500 Watts from the GXD 8.
Power levels matched to the most popular loudspeakers and optimized for maximum real-world headroom into 8Ω speaker systems.
Class D output stage with a universal power supply for high performance and efficiency.
Extensive and powerful loudspeaker processing built in. Includes high and low-pass filters, 4-band parameteric EQ, limiting, and delay.
E Series Entertainment System DSP Tunings are now available for GXD processing amplifiers:
Visit the GXD Firmware Updater to download and update
Large LCD display simplifies amplifier setup and indicates amp status.
Inputs: Parallel XLR and 1/4-inch TRS connectors for compatibility with any source while providing convenient loop-thru capability.
Precision rotary encoders for gain and DSP parameter control.
Outputs: Professional binding post and NL4 connectors (compatible with NL2) provide for mono and bi-amp speaker connections.
Digital limiting automatically protects the amplifier from damage due to temperature rise or overdrive.
Adjustable speaker protection to match your loudspeaker’s power and impedance.
Front panel LEDs indicate signal presence, input overload, and amplifier clipping.

Specifications:
Output power per channel
8Ω dynamic, both channels driven: 1500 W
4Ω dynamic, both channels driven: 2250 W
8Ω continuous, both channels driven: 800 W
4Ω continuous, both channels driven: 1200 W
Distortion (typical) 1 kHz at full rated power: < 1% THD
Signal to Noise
(A weighted, 20 Hz–20 kHz) 100 dB
Input Sensitivity 1.2 Vrms, 3.9 Vrms
Maximum Voltage Gain: 36.5 dB
Output Circuitry: Class D
Power Requirements: 1/8 power at 4Ω
- 100 V AC: 6.2 A
- 120 V AC: 5.6 A
- 230 V AC: 3.2 A
Frequency Response (20 Hz–20 kHz): +0.7 dB, -0.8 dB
Dynamic Headroom (4Ω): 2.73 dB
Damping Factor (8Ω): 100
Input Impedance: 20 kΩ (balanced), 10 kΩ (unbalanced)
Maximum Input Level: +23.5 dBu
Input Connectors (each channel): 3-pin XLR/F / 1/4-inch TRS, balanced
Output Connectors (each channel):
NL4, binding posts
NL4 pinout:
• Channel A on 1+, 1-; Channel B on 2+, 2-
• Channel B on 1+, 1-
Amplifier and Load Protection: Short circuit, open circuit, thermal, RF protection Load protected against DC faults
Front Panel Controls and Indicators:
2 × Rotary Encoders
3 × Operational buttons (HOME, ENTER, EXIT)
2 × Green Signal LEDs indicate signal presence
2 × Red A/D Clip LEDs indicate input over-drive and/or amplifier current clipping
Blue Power LED ring indicates AC on
2.12-inch × 1.0-inch, 256 × 128 pixel LCD
DSP Functions:
High-pass filter, 4th-order Linkwitz-Riley,
adjustable frequency 20 Hz to 4 kHz
Low-pass filter, 4th-order Linkwitz-Riley,
adjustable frequency 60 Hz to 4 kHz
4-band parametric EQ with variable frequency, gain, and bandwidth
Peak limiter with power, agressiveness, and impedance selection
Delay 50 msec max.
Product Dimensions (H×W×D):
89 × 483 × 259 mm
3.5 (2 RU) × 19 × 10.2 in
Carton Dimensions (H×W×D):
600 × 370 × 153 mm
23.6 × 14.6 × 6 in
Net Weight: 6 kg / 13.2 lb
Shipping Weight : 7.9 kg / 17.4 lb
Agency Approvals: UL, CE, RoHS/WEEE compliant
Carton and Contents: Power cable and quick start guide

QSC K8.2 YOKE Powder Coated Steel Yoke Mount for K8.2 Loudspeaker

K8.2 Yoke Mount is a powder-coated steel yoke designed for mounting a QSC K8.2 powered loudspeaker vertically or horizontally to a wall, beam, or other structure.

Features:
Powder coated steel yoke
Mounting the K8.2 Loudspeaker
Vertically or horizontally to walls, beams, or other structures.

QSC K12 OUTDOOR COVER K12 Active Loudspeaker System Outdoor Cover

K12 OUTDOOR COVER Nylon fabric and mesh cover for temporary outdoor use of K12.2 and legacy K12 in adverse weather. Removable amplifier panel allows access to connectors and controls. Vented panel maintains airflow for proper heat management. Not intended for permanent outdoor installations.

Features:
Nylon fabric and mesh cover for temporary outdoor
Use of K12 in adverse weather. Removable
Amplifier panel allows access to connectors and controls
For K12 Loudspeaker system

QSC AD-S10T-WH Two Way 10 Inch Surface Mount Loudspeaker System 250 Watts

QSC’s AcousticDesign™ S10T surface mount loudspeakers are professional, 70/100V, 10-inch, two-way, full-range systems ideal for a wide variety of foreground and background sound reinforcement applications. Ease-of-installation is the driving principle behind QSC’s next generation of small format, surface mount loudspeakers. Innovations found on AD-S loudspeakers enable designers and integrators to quickly and easily specify and install a system. AD-S loudspeakers are also a perfect solution to serve ancillary loudspeaker needs as part of a larger installed sound system.

Housed in rugged ABS enclosures for long-term durability, S10T loudspeakers employ DMT™ (Directivity Matched Transition) which matches the LF and HF coverage at the crossover point. This ensures even coverage across the listening plane for smooth, coherent audio reproduction. The 1.4in diaphragm, 1-in exit compression driver on the S10T delivers crisp, detailed high-frequency reproduction and when combined with the matched woofers, provides full bandwidth reproduction. To further enhance performance, tunings using QSC Intrinsic Correction techniques are available for Q-Sys and future QSC amplifiers. Moreover, the low saturation transformers offer premium performance on 70/100V distributed audio lines.

Installers will appreciate flexible mounting options. Euroblock connectors allow pre-wiring of the system and the included

X-Mount hardware enables the installer to mount the bracket and then simply lift the loudspeaker onto the mount and lock it into place. Moreover, the loudspeaker can attach to its mount on any plane to facilitate multiple deployment configurations.

AD-S loudspeakers can easily be mounted to any weight bearing, flat surface. Knurled surfaces on the mount’s pivot points ensure that the loudspeaker deployment angle stays fixed and will not slip over time. No special tools are required to install or adjust the loudspeaker angle. S10T models also feature M10 installation points for suspending the loudspeaker via eye-bolts as well as mounting points for an optional yoke bracket.

Features:
DMT™ (Directivity Matched Transition) ensures smooth, uniform frequency response over the coverage area
Patent pending X-Mount™ enables the loudspeaker to be easily installed and deployed at a variety of angles without slipping over time
Optional yoke mount and M10 Kit-C eyebolt kit offers additional loudspeaker deployment options
Euroblock connectors allows pre-wiring of the system
Low saturation 70/100V transformer with 8 ohm bypass
Lightweight ABS enclosures offer long-term durability and lasting good looks
Sealed input panel cover and powder coated aluminum grilles for added weather resistance
Meets IEC60529 IP-54 for dust and splash resistance
Complete EASE, CAD & BIM information available online
Can also be used as a Cinema surround loudspeaker

Specifications:
Effective frequency range: 1 50 Hz – 19 kHz
Rated noise power / voltage2: 250 watts / 45 volts (rms)
Broad-band sensitivity3: 92 dB SPL
Coverage angle (-6 dB): 90°
Directivity factor (Q): 10
Directivity Index: 10 dB
Maximum continuous SPL4: 116 dB
Maximum peak SPL4: 122 dB
Rated impedance: 8 ohms
Recommended amplifier: 500 watts
Transformer taps:
70 V: 100, 50, 25, 12.5 watts and 8 ohm bypass
100V: 100, 50, 25 watts and 8 ohm bypass
HF transducer: 1” exit / 1.4” voice-coil compression driver
LF transducer: 10” weather resistant paper cone woofer, 2.5” / 64 mm voice-coil
Input connector type: Euroblock connector with parallel output
Enclosure material: Painted ABS polymer
Grille material: Powder coated aluminum
X-Mount material: Powder coated aluminum
Enclosure Details
Ingress protection: IP-54
Operating environment: Designed for indoor and outdoor use
Testing: The AD Series loudspeakers qualified for outdoor use using the following tests:
Salt fog: MIL-STD-810G Method 509.5 for 100 hrs.
Humidity: MIL-STD-810G Method 507.5, Natural cycle B2, cyclic high RH for 7 days
High and low temperature: tested to QSC internal standards between -20° and 50° C
Operating Temperature Range: -20 to 50° C / -4 to 122° F
Net weight: 31 lb / 15 kg
Product dimensions: 20.3” x 12.5” x 11.7” (516 x 318 x 298 mm)
Shipping weight: 40.6 lb / 18.45 kg
Shipping dimensions: 31.7” x 16.1” X 16.1” (805 x 409 x 409 mm)
Included accessories: X-Mount mounting system, euroblock connector, input panel cover
Optional accessories: YMS10T yoke mount, M10 Kit-C

QSC SPA2-200 2 Channel Energy Star Power Amplifier 200 Watts Rackmount

QSC SPA2-200 2-Channel Power Amplifier is an advanced Class-D amplifier with Energy Star rated efficiency well suited for smaller installations including meeting rooms or BGM zones. The convection cooled amplifier is designed to conserve energy. An auto-ramp circuit ensures quiet and fast power up from standby when a signal is present and seamless power-down following 25 minutes of inactivity, dramatically reducing power consumption.

The rear panel utilizes Euroblock connectors for inputs and outputs as well as remote inputs. Each channel of the SPA2 provides 200W of power, while the bridge mode provides 400W into 4 or 8 ohms and 350W into 70/100V.

For higher power the SPA2-200 two channel amplifier delivers up to 200 watts rms per channel into 4 or 8 ohms; the two channels can also be bridged providing up to 400 watts rms into 4 or 8 ohms. When the channels are bridged they can be switched into 70V or 100V direct drive mode providing up to 350 watts rms into a mono 70V or 100V output. Like the other SPA models, an 80Hz highpass filter is engaged when in 70V or 100V mode.

Features:
Up to 200 watts per channel into 4 and 8 ohms: the outputs of the SPA2-200 model are designed to provide up to 200 watts per channel into Low-Z loads.
ENERGY STAR® qualified amplifier: The ENERGY STAR qualified SPA amplifiers employ an efficient class-D design to conserve energy and reduce operational cost.
Bridgeable outputs for higher power: Bridging the outputs of the SPA2-200 will deliver up to 350 watts into 70V or 100V when bridged.
Auto-Ramp provides quiet startup and power-down: The ENERGY STAR auto-ramp circuitry ensures quiet and fast power up from standby and seamless power: down following 25 minutes of inactivity, dramatically reducing power consumption.
Rack-mountable 1U, half rack width enclosure: The SPA amplifers can be mounted in 1 RU, 1/2 rack space, and their clever joining brackets enable easy under-table and wall-mounting

Features:
Channels 2 4 2 4
Stereo Mode (all channels driven)
8 Ω: 200 W
4 Ω: 200 W
Bridged Outputs (all channels driven)
8 Ω & 4 Ω: 400 W
70 V: 350 W
100 V:350 W
Frequency response (4 Ω and 8 Ω): 20 Hz - 20 KHz +/- 0.1 dB
Signal to noise (20 Hz - 20 KHz): >100 dB
Input sensitivity: 1.23 V (+4 dBu)
Gain at 8 Ω: 25.0 dB
Output circuitry: Class D
Input impedance: >10k, balanced or unbalanced
Maximum input level: 12.3 V (+24 dBu)
Cooling: Convection
Input connectors: 3.5 mm Euro, 5 position (green) 3.5 mm Euro, 10 position (green)
Remote connectors: 3.5 mm Euro, 5 position (black) 3.5 mm Euro, 10 position (black)
Output connectors: 5 mm Euro, 4 position (green)
Front panel indicators: Power, per channel Signal, per channel Protect/Limit
Rear panel indicators: Bi-Color LED Signal/Protect/Limit per channel
Controls: 4 Ω/8 Ω/70 V Bridged Highpass On/100 V Bridged Highpass (per channel pair)
General purpose inputs: Remote volume, remote standby, on 3.5 mm connectors (10k potentiometer is not included)
Highpass filter: 80 Hz in Bridged 70 V & 100 V
Dimensions: 1.7” x 8.7” x 9.5” (43 mm x 220 mm x 241 mm)
Net weight: 3.5 lb (1.1 kg) 4.0 lb (1.4 kg)
Shipping weight: 6 lb (2.3 kg) 6.5 lb (2.5 kg)
Power requirements: Universal Power Supply 100 - 240 VAC, 50 - 60 Hz with active power factor correction
Agency approvals: UL, CE, Energy Star, RoHS/WEEE compliant, FCC Class B (Conducted and Radiated emissions), UL 2043 with plenum kit accessory
Carton contents: IEC Cable, quick start guide, connector pack, rack mount ears, mounting brackets

QSC AD-YMS8-BK Steel Yoke Mount for Acoustic Design AD-S8T Loudspeaker

Yoke mount for the AcousticDesign AD-S8T loudspeaker.

Features:
Steel yoke mount black
For the AD-S8T loudspeaker

QSC RMX2450A 2 Channel Power Amplifier 800 Watts Rackmount

The 750 watts per channel at 4Ω QSC RMX2450a Low-Z Power Amplifier is a 2RU rack mountable amplifier designed for live sound reinforcement applications. The amplifier features two 2-tier Class H output channels that can operate in either stereo or mono bridge mode. The unit operates on a standard 15 amp plug and utilizes high-current toroidal transformers for less noise and better performance when pushing a 2 ohm load. To reduce distortion, the amplifier utilizes independent user-defeatable clip limiters and includes LED indicator lights to show the presence of the signal and when the signal is clipping.

The chassis of the amplifier is designed with front to rear cooling vents and includes selectable low-frequency filters at 30 Hz and 50 Hz to protect speakers from bottoming out and improve headroom when driving mid and high frequencies. The front panel of the unit features two gain control knobs for easy access and each channel is protected by a dedicated DC and thermal overload protection circuit. For inputs, the back of the unit accepts both balanced 1/4" and XLR inputs. For outputs, the unit features both Neutrik Speakon and touch-proof binding post connections.

Features:
Compact size — up to 2500 watts in two rack spaces, or 5000 watts in three rack spaces
High-current toroidal transformers, for greater 2-ohm power and low noise
Independent user-defeatable clip limiters reduce distortion
Selectable low-frequency filters (30 Hz or 50 Hz) protect speakers and increase headroom
The RMX2450a's particularly exceptional combination of cooling capacity and electrical efficiency provides robust thermal performance suitable for high continuous power in 2-ohm stereo or 4-ohm bridged applications.
Balanced 1/4-inch (6.3 mm) TRS, XLR, and barrier strip inputs
Touch-proof binding post and Neutrik Speakon® outputs
Front mounted gain controls for easy access
Signal and clip LED indicators for monitoring performance
Independent DC and thermal overload protection on each channel automatically protects amplifier and speakers
3-year warranty plus optional 3-year extended service contract

Specifications:
8Ω, FTC 20 Hz–20 kHz, 0.1% THD: 450 W
8Ω, EIA 1 kHz, 0.1% THD: 450 W
4Ω, FTC 20 Hz–20 kHz, 0.1% THD: 650 W
4Ω, EIA 1 kHz, 0.1% THD: 800 W
2Ω, FTC 20 Hz–20 kHz, 1% THD: 1200 W
Power, Bridge-Mono Mode:
8Ω, FTC 20 Hz–20 kHz, 0.1% THD: 1300 W
8Ω, EIA 1 kHz, 0.1% THD: 1500 W
4Ω, EIA 1 kHz, 1% THD: 2400 W
100 V Direct Drive, EIA 1 kHz, 1% THD: 1500W
Signal to Noise (20 Hz–20 kHz): 2400W
Distortion (SMPTE-IM): < 0.02%
Input Sensitivity at 8Ω: 1.23V (+4.0 dBu)
Voltage Gain: 50x (34 dB)
Output Circuitry: 2-tier Class H
Current Draw (120 V AC):
Typical, 1/8 power pink noise at 4Ω*: 6.3 A
Severe, 1/3 power pink noise at 4Ω*: 15.6 A
AC Mains Plug: NEMA 5-15
100/120V: CEE7/7
Distortion (typical):
20 Hz–20 kHz, 10 dB below rated power: < 0.03% tdD, 4Ω and 8Ω
1 kHz and below, full rated power: < 0.03% tdD, 4Ω and 8Ω
Frequency Response: 20 Hz–20 kHz: +0/-1 dB -3 dB points: 5 Hz and 50 kHz (LF filter bybassed, 8Ω)
Damping Factor (1 kHz and below): > 300 at 8Ω
Input Impedance: 10 kΩ unbalanced; 20 kΩ balanced
Input Stage Clipping: 10 V rms (+22 dBu)
Cooling: Continuously variable speed fan, back-to-front air flow
Connectors (each channel): Input: Active balanced; 3-pin Euro-style detachable terminal block and XLR (pin 2+) Output: Touch-proof binding posts; Neutrik Speakon®
Controls:
Front: AC switch; Channel 1 & 2 gain knobs
Rear: 10-position DIP switch
LED Indicators: Power on: Green; Signal: Yellow (1 per channel); Clip/Protect: Red (1 per channel)
Amplifier Protection: Full short circuit, open circuit, tdermal, ultrasonic, RF protection. Stable into reactive or mismatched loads
Load Protection: Turn-on/off muting; AC coupling (850, 1450); Triac crowbar (1850HD, 2450, 4050HD, 5050) on each channel
Product Dimensions (H×W×D):
89 (2 RU) × 482 × 404 mm
3.5 (2 RU) × 19 × 15.9 in
Carton Dimensions (H×W×D):
610 × 560 × 153 mm
24 × 22 × 6 in
Net Weight:
Shipping Weight:
Power Requirements: 100, 120, 230 V AC (factory configured), 50–60 Hz

QSC KS112 Powered 12 Inch Active Subwoofer Loudspeaker 2000 Watts

The KS112 is an ultra-compact active subwoofer for installation and highly portable entertainment applications. The KS112 is a highly portable, single 12-inch bandpass design subwoofer, powered by a 2000 Watt peak power Class D amplifier module. The cabinet is constructed of premium birch and includes high-quality, low noise casters.

Two M20 threaded pole receptacles are available for a positive, wobble-free connection to a threaded speaker pole in either vertical or horizontal deployment (pole not included).

Features:
High Output in an ultra-compact form factor
2000 Watt Class D amplifier module
12-inch, long-excursion driver; 6th order bandpass design
Intrinsic Correction™tuning and loudspeaker management
Refined, professional appearance looks great in any application
Rugged painted wood enclosure for long life and lasting durability
Deployment in either vertical or horizontal positions with dual M20 speaker pole fittings
Optional KS-LOC security cover prevents unauthorized tampering of controls
Complete EASE & CAD information available online
6-Year Warranty*

Specifications:
Configuration: 6th-Order Bandpass Subwoofer
LF Transducer: 305 mm (12 in), Cone
Frequency Response (-6 dB): 41 Hz - 108 Hz
Frequency Range (-10 dB): 38 Hz - 121 Hz
Maximum Rated SPL1: 128 dB @ 1 m (peak)
Amplifier: Class D 2000W (peak)
Cooling: Low-noise, variable speed fan
Controls:
Power On/Off
Gain Control
Rotary encoder
2 × selection buttons
Indicators:
2 × Power LED (front and rear)
Input Signal LED
Limiter Active LED
Connectors:
2 × locking XLR/F 1/4-inch combo
2 × XLR/M (Loop-thru Output)
1 × locking IEC power connector
AC Power Input Universal power supply 100 - 240 VAC, 50 - 60 Hz
AC Power Consumption: 100 VAC, 2.4 A / 120 VAC, 2.0 A / 240 VAC, 1.3 A
Enclosure Details
Enclosure: 15 mm Birch Plywood
Color: Black (RAL 9011)
Grille: Internal woofer cover
Speaker Dimensions (H×W×D):
622 × 394 × 616 mm
24.5 × 15.5 × 24.25 in
Carton Dimensions (H×W×D):
740 × 500 × 673 mm
29 × 19.7 × 26.5 in
Net Weight: 28.4 kg / 62.6 lb
Shipping Weight: 35 kg / 77.2 lb
Regulatory: CE, WEEE, UL, China RoHS, RoHS II, FCC Class B
Included Accessories: 4 × Low-Noise, Heavy Duty Casters
Optional Accessories:
KS112 CVR Transport Cover, KS-LOC Lock-Out Cover
SP-26 and SP-36 Loudspeaker Poles, SP-16X Extension Pole

QSC AD-S6T-WH Two Way 6.5 Inch Surface Mount Loudspeaker System 150 Watts

The AcousticDesign Series QSC AD-S6T is a pair of transformer-equipped 6.5" surface-mount loudspeakers supplied with award-winning X-Mount systems, making them suitable for 70/100V or 8-ohm operation in a variety of foreground and background music applications, whether installed in horizontal, vertical, wall, or ceiling deployments.

Outfitted with a 6.5" weather-treated woofer and a 1" silk dome tweeter on a DMT waveguide, the AD-S6T offers even 105° conical coverage and improved off-axis response while providing a frequency range of 60 Hz to 20 kHz (-10 dB). The speaker is capable of handling 150W RMS and producing a peak maximum SPL of 116 dB.

The AD-S6T utilizes a 4-pole Euroblock connector under a sealed input cover for easy wiring and protection from moisture. Featuring a rugged ABS enclosure and a powder coated aluminum grille, the AD-S6T boasts dust and splash resistance beyond IP54 ratings for worry-free operation indoors or outside.

Features:
DMT™ (Directivity Matched Transition) ensures smooth, uniform frequency response over the coverage area
X-Mount™ system enables the loudspeaker to be easily installed and deployed at a variety of angles without slipping over time
Advanced voicing filter sets using QSC Intrinsic Correction™ available through either Q-SYS processing or CXD Series amplifier platforms
Low saturation and low loss 70/100V transformers with 8Ω bypass
Lightweight ABS enclosures offer long-term durability and lasting good looks
Sealed input panel cover and powder coated aluminum grilles for added weather resistance
Meets IEC60529 IP-54 for dust and splash resistance
Available in black (RAL 9011) or white (RAL 9010)
Complete EASE, CAD & BIM information available online

Specifications:
HF transducer: 1” silk dome tweeter / 1” voice-coil horn loaded
LF transducer:
6.5” weather treated paper cone woofer,
1.5” / 38mm voice-coil
Effective frequency range1: 60 – 20k Hz
Rated noise power / voltage2: 150 watts / 35 volts (rms)
Broad-band sensitivity3: 89 dB SPL
Coverage angle (-6 dB): 105°
Directivity factor (Q): 5
Directivity Index: 7 dB
Maximum continuous SPL4: 110 dB
Maximum peak SPL4: 116 dB
Rated impedance: 8 ohms
Recommended amplifier power: 300 watts
Transformer taps:
70 V: 60, 30, 15, 7.5 watts and 8 ohm bypass
100V: 60, 30, 15 watts and 8 ohm bypass
Input connector type: Euroblock connector with parallel output
Enclosure material: Painted ABS polymer
Grille material: Powder coated aluminum
Enclosure Details
Ingress protection: IP-54
Operating environment: Designed for indoor and outdoor use Testing The AD Series loudspeakers qualified for outdoor use using the following tests:
Salt fog: MIL-STD-810G Method 509.5 for 100 hrs.
Humidity: MIL-STD-810G Method 507.5, Natural cycle B2, cyclic high RH for 7 days
High and low temperature: tested according to QSC internal standards between -20° and 50° C
Operating Temperature Range: -20 to 50 °C / -4 to 122 °F
Net weight: 13.6 lbs / 6.2 kg
Product dimensions: 14.4” x 8.5” x 8.5” (365 x 215 x 215mm)
Shipping weight: 33.4 lbs / 15.2 kg (pair packed)
Shipping dimensions: 20 x 12” X 23” (510 x 305 x 585mm) (pair packed)
Included accessories: X-Mount mounting system, euroblock connector, input panel cover

QSC AD-C6T-WH 6.5 Inch Two Way Surface Ceiling Mount Loudspeaker 60 Watts

The QSC AcousticDesign™ AD-C6T is a 6.5" two-way ceiling loudspeaker ideally suited for a wide variety of foreground and background sound reinforcement applications which utilize 70/100V or 16Ω bypass configurations.

The AcousticDesign™ Series offers integrators a premium quality installed sound solution where performance, consistent coverage, and aesthetics are paramount. Specifically designed to maintain a consistent tonal characteristic across the entire family in ceiling, surface, and pendant applications, the AcousticDesign series allows integrators seamless transitions within blended installations.

The AD-C6T features a high quality 6.5" weather treated paper cone woofer with a 1" voice coil and a .75" aluminum dome tweeter which is positioned on a DMT waveguide.

DMT (Directivity Matched Transition™) is QSC’s design philosophy where the high frequency waveguide is matched to the natural conical behavior of the woofer at the crossover point. The result is a coherent
transition between transducers with improved off-axis power response for consistent 135° conical DMT coverage.

The accurate frequency response of the AD-C6T is maintained even in 70/100V applications by use of a low-loss, lowsaturation 60-watt transformer with selectable taps, including 16Ω bypass, using a rotary selector located under the snap-fit magnetically attached powder coat steel grille.

To retain lasting good looks, the rugged ABS baffle is further protected by using UV inhibitors that prevent discoloration and by a powder coated steel back can. The magnetic grille features a stick-on logo that can be removed blemish-free for installations where branding is not permitted.

Installers will appreciate the 3x double stepped, long travel dog-ear blind mounting system, which captures from 0" - 2.25" of ceiling thickness. The conduit cover plate can be easily removed by losening the single captive Phillips screw allowing access to the locking 4-pole Euro-block connector which can accept up to four 18AWG pairs, eliminating the hassles of star topology wiring designs.

Intrinsic Correction™ voicings that optimize performance and speed the install process are easily deployed via the Q-SYS Platforms, including CXD-Q Series amplifiers, as part of a complete QSC systems solution.

The AD-C6T is available in QSC standard black (RAL 9011) or white (RAL 9010) and may be painted to match any decor.

For your system integration needs, complete EASE, CF2, CAD, and BIM files are available for download at QSC.com.

Features:
Consistent tonal characteristics across the entire AcousticDesign family for surface, ceiling, and pendant applications
DMT (Directivity Matched Transition™) waveguide ensures smooth, uniform frequency response over the coverage area
Snap-fit magnetic grille
3x double stepped, long travel dog-ear blind mount system
Intrinsic Correction™ voicings available via Q-SYS Platform including CXD-Q Series amplifiers
Low-saturation and low-loss 70/100V transformers with 16Ω bypass
Blemish-free removable logo
Removable conduit cover plate, also available as accessory for preinstall wiring
UL1480 and UL2043 certified
Available in white (RAL 9010)
Complete EASE, CF2, CAD, & BIM information available online

Specifications:
Effective frequency range 1: 65 Hz – 20 kHz
Rated noise power / voltage 2: 60 watts / 31 volts (rms)
Sensitivity [dB] 3: 88
Sensitivity at 4m, 100V maximum tap: TBD
Rated coverage (-6 dB) 4: 135° conical DMT
One-third octave frequency band contribution at full power using 100V maximum tap at 4m. (Hz / dB):
500 / TBD; 630 / TBD; 800 / TBD
1000 / TBD; 1250 / TBD; 1600 / TBD
2000 / TBD; 2500 / TBD; 3150 / TBD
4000 / TBD
Directivity factor 4: 6.5
Directivity index [dB] 4-: 8
Maximum continuous SPL [dB] 5: 106
Maximum peak SPL [dB] 5: 112
Nominal impedance [ohms]: 16
Recommended amplifier: 120 watts
Transformer taps / impedance:
16Ω (in bypass setting)
7.5W (70V); 15W (100V) Tap: 667Ω
15W (70V); 30W (100V) Tap: 333Ω
30W (70V); 60W (100V) Tap: 167Ω
60W (70V); N/A (100V) Tap: 83Ω
LF transducer: 165 mm [6.5 in] weather treated paper cone woofer
HF transducer: 19 mm [.75 in] aluminum dome tweeter
Input connector type: Euroblock connector with parallel output
Enclosure material: ABS baffle on powder coated steel back can
Grille material: Powder coated steel
Ingress protection: IP-34
Operating environment: Designed for indoor use
Operating temperature range: -20 to 50° C [-4 to 122° F]
Cutout dimension: Ø 245 mm [Ø 9.65 in]
Net weight: 4.3 kg [9.5 lb]
Product dimensions (Diameter x Height): Ø 280 x 237 mm [Ø 11.02 x 9.32 in.]
Shipping dimensions (H x W x D): 330 x 737 x 381 mm [13 x 29 x 15 in] (pair packed)
Included accessories: C-ring and tile rails, rail screws, euroblock connector, cut-out template, tether grille
Optional accessories:
AD-MR6 (pre-install mud ring)
AD-CC6 (pre-install conduit cover)
Safety Agency: EN54-24: 2008 type A (No. pending) UL1480, UL2043, NFPA90, NFPA70 suitable for use in air handling spaces. Transformer UL registered per UL1876, ROHS, C-Tick (pending), CE compliant. Baffle meets UL94-V0 and UL94-5VB flamibility rating; in accordance with IEC60849 / EN60849 systems
