Adaptive Technologies PM-24-6UP-G Pole Mount for 6 Speakers

The UniFrame is a complete mounting solution for outdoor loudspeakers. Its design combines the attributes of the PoleStar® stainless “a-lacarte” version into just two models produced in steel and then galvanized to an outdoor weather rating.

The UniFrame reduces the amount of parts required for the job site and saves installation time by combining the support arm and the pole adapter together into one assembly. In addition, two stainless steel band kits are included, which only require a socket set to assemble.

The support arm is welded together for extra strength and durability. Each arm includes three attach point mounting holes at the end of the arm that allow the installer to select the desired distance between the loudspeaker and the pole.

Standard Features

• Uni-Frame assembly adds strength and reduces installation time.

• Longer pole interface increases structural capacity.

• Rugged outdoor galvanized finish to ASTM A123 and
  ISO1461 specifications.

• Three arm mounting points to accommodate all speaker models.

• Angled brace increases structural stability during severe
  weather conditions.

• Support arm may be oriented up or down for installation flexibility.

• Dual adapter may be secured to the Uni-Frame for a three-way installation.

Specifications

Material: Steel Alloy

Finish: Galvanized

Color: Silver

WLL: 190 lb / 86.4 Kg single speaker

WLL: 500 lb / 227 Kg three equal weight speakers

Design Factor: 10:1 ratio

*WLL = Working Load Limit

Adaptive Technologies SC-188-24-SS Suspension Chain 24" Stainless

Safeties are prefabricated at the factory under exacting conditions to make installations quick, safe and secure. Use these cables to secure wall mounted and ceiling mounted loudspeakers and other installed equipment to structures as a redundant safety backup.

Safety Cable Kits are produced from load-rated aircraft cable and hardware and come in black, zinc and stainless finishes. The proper method for use is to completely bypass the mounted equipment with a safety cable by securing it between the mounted object and a structural member and with as little slack as possible.

CAUTION: DO NOT USE AS A
PRIMARY SUSPENSION DEVICE

Specifications

Material: Stainless Steel

1 pc. 3/16 inch 7X19

Color: Black

2 pc. 1/4 inch Shackle

WLL: 750 lbs./340 kg.

Length: 24/610

Adaptive technologies Group BC3-8-2 3" to 8" Dual Hang Point Beam Clamp

Use the BC3-8-2 channel style beam clamp to provide an offset load rated overhead rigging point from structural I-Beams with flange widths ranging between 3” and 8” (76-203 mm). This beam clamp model provides a fast, easy and safe way to rig direct loads, bridles and hitches. A hand wrench is all that is required to secure the clamp to the beam. Beam flanges must be parallel to the floor to achieve the stated safe working loads.

Features:
For Beam Flanges 3″-8″
Two load-rated suspension points
Clamps quickly / permanently to I-Beams

Specifications:
SPECIFICATIONS                                                PACKAGE CONTENTS
Material: All Steel Components                          2 pcs 5/8” eye nut
Width: (BC3-8) 3” to 8” / 76mm to 203mm      1 pc Channel Clamp
WLL: 2100 lb / 953 Kg WLL (VERTICAL)
Finish: Powder Coat
Color: Black
Design Factor: 4:1
45 DEG. WL: 825 lb / 375 Kg

Adaptive Technologies Group MM-060 MultiMount Indoor Speaker Bottom and Back Wall Mount

The MultiMount MM-060 Indoor Speaker Wall Mount attaches both to the back and bottom panels of loudspeakers and aims them from walls and other vertical structures.
Once secured, the mount offers up to 180 degrees of pan angle adjustments and up to 45 degrees of no-drift tilt adjustments, compliments of a unique screw drive tilt mechanism.
The MultiMount MM-060 Indoor Speaker Wall Mount is exceptionally easy to install and aim most mid-sized loudspeakers.
They are solidly constructed with built in safety features and a load-rating of 7:1 design factor.
The installation sequence makes it easy for the installer.

Features:
Weather resistant for covered outdoor and indoor use
Infinite no-drift tilt adjustments with screw-drive.
Pan angle secured with clutch style lock.
Mounts to walls, studs and optional stud plate.
Wall plate quick install.
Adapts to 4 hole mounting patterns including
2-3/4” x 5” and 2” X 4-1/4”

Specifications:
Material:      Structural Steel
Finish:     Powder Coat
Color:     Black
Tilt Adjustment:    45 degrees
Swivel Adjustment:   180 degrees
WLL:   60 lbs. (27.3 Kg) max.
Design Factor:   7:1 ratio
Net wgt:    6.1 lbs. (2.8 Kg) each
Shipping wgt:    8 lbs. (3.6 Kg) each
Pack Count:    1 units/carton

Adaptive Technologies Group BC7-12-2 7" to 12" Dual Hang Point Beam Clamp

Use the BC7-12-2 channel style beam clamp to provide an offset load rated overhead rigging point from structural I-Beams with flange widths ranging between 7” and 12” (178-305mm). This beam clamp model provides a fast, easy and safe way to rig direct loads, bridles and hitches. A hand wrench is all that is required to secure the clamp to the beam. Beam flanges must be parallel to the floor to achieve the stated safe working loads.

Features:
For Beam Flanges 7″-12″
Two load-rated suspension points
Clamps quickly / permanently to I-Beams

SPECIFICATIONS                                                  PACKAGE CONTENTS
Material: All Steel Components                              2 pcs 5/8” eye nut
Width:(BC7-12) 7” to 12” / 178mm to 305mm        1 pc Channel Clamp
WLL:1600 lb / 726 Kg WLL (VERTICAL)
Finish: Powder Coat
Color: Black
Design Factor: 5:1
45 DEG. WL:944 lb / 428 Kg

Adaptive Technologies Group TCK-018 18” Adjustable Tilt Cable Kit Vertical Orientation

Steerables® Tilt Cable Kits are a general purpose, time saving and complete loudspeaker suspension and aiming solution. This versatile aircraft cable and pulley design allows installers to secure loudspeakers from an overhead grid structure or other suspension device, then quickly and precisely tilt them into position using the adjustable pull back feature (see Wall and ceiling Steerables®, GridLink™ data sheets).

The Steerables® Tilt Cable Kit provides a simple method of suspending and aiming loudspeakers, offering unprecedented ease of installation and aiming. Loudspeakers and other objects can be suspended to the top of the cabinet to achieve just slight down tilt angles or be suspended from the back of the cabinet to achieve a steeper down tilt angle (See illustrations below).

Features:
Infinite tilt and locking adjustment
Available in black or silver finish
Standard and custom assemblies
Close factory cable length tolerances

Specifications;
Materials: See “Package Contents”
Color: Black
Design Factor: 10:1 ratio*
Pack Count: 1 set/package
Fixed Cable Length: 18” Fixed cable kit
*Clutch lock design factor = 5:1
** 4-Point suspension requires additional pair of fixed length cables
WLL = Working Load Limit

Package Contents & Working Load
Qty. Description WLL (lbs/Kg)
2 pcs 3/16” dia. Fixed cable 420/191
1 pc 1/8” dia. Pull back cable 200/91
5 pcs Anchor shackles 600/272
1 pc Clutch lock assembly 220/100*
1 pc Pulley assembly 210/95
5 pc Cable tie wrap N/A

Adaptive Technologies Group MM-016-BT Pan and Tilt 25lb Indoor Speaker Wall Mount

The MultiMount MM-016-BT Indoor Speaker Wall Mount quickly mounts and aims loudspeakers weighing up to 25 lbs./11.4 kg. and attaches them to walls and other vertical structures.

Three separate rotational axes make aiming fast, versatile and permanent. The MultiMount MM-016-BT Indoor Speaker Wall Mount s unique support arm acts as a convenient carrying handle to help lift the speaker into place.

Once inserted, the wall plate supports the weight of the loudspeaker for hands free wiring and aiming. MultiMounts are built from tough alloy metals to assure reliable permanent installations.

The unique speaker adapter plate allows installer to select a horizontal or vertical speaker orientation.

Features:
Weather resistant for covered outdoor and indoor use
Separate pan, tilt and clockwise rotations
Infinite aiming and locking angles
No “memory” or “drift”
Accommodates speakers with 4 hole mounting
patterns, including 2.00” x 4.25” and 2.75” x 5.00”

Specifications:
Material: Steel Alloy 2 pcs. Wall mount plates
Finish: Powder Coat 2 pcs. Speaker adapter assemblies
Color: Black 2 pcs. Socket screw 1/4-20 X 1/2″ long
WLL: 25 lbs. (11.4 Kg.) max 2 pcs. Flat washer 1/4″ diameter
Design Factor: 10:1 ratio 2 pcs. Sound isolation gasket
Net WGT: 1.5 lb. (.7 Kg) each
Shipping WGT: 4 lbs (1.8 Kg)/pair
Pack Count: 2 units/carton

Adaptive Technologies Group TCK-014 14” Adjustable Tilt Cable Kit Vertical Orientation

Steerables® Tilt Cable Kits are a general purpose, time saving and complete loudspeaker suspension and aiming solution. This versatile aircraft cable and pulley design allows installers to secure loudspeakers from an overhead grid structure or other suspension device, then quickly and precisely tilt them into position using the adjustable pull back feature (see Wall and ceiling Steerables®, GridLink™ data sheets).

The Steerables® Tilt Cable Kit provides a simple method of suspending and aiming loudspeakers, offering unprecedented ease of installation and aiming. Loudspeakers and other objects can be suspended to the top of the cabinet to achieve just slight down tilt angles or be suspended from the back of the cabinet to achieve a steeper down tilt angle (See illustrations below).

Features:
Infinite tilt and locking adjustment
Available in black or silver finish
Standard and custom assemblies
Close factory cable length tolerances

Specifications:
Materials: See “Package Contents”
Color: Black
Design Factor: 10:1 ratio*
Pack Count: 1 set/package
Fixed Cable Length: 14” Fixed cable kit
*Clutch lock design factor = 5:1
** 4-Point suspension requires additional pair of fixed length cables
WLL = Working Load Limit

Package Contents & Working Load:
Qty.                Description                                 WLL (lbs/Kg)
2 pcs              3/16” dia. Fixed cable                  420/191
1 pc               1/8” dia. Pull back cable               200/91
5 pcs              Anchor shackles                          600/272
1 pc               Clutch lock assembly                    220/100*
1 pc               Pulley assembly                           210/95
5 pc               Cable tie wrap                             N/A

Adaptive technologies Group BC7-12 Channel Style One Suspension Point Beam Clamp

Standard, pre-engineered channel style beam clamps anchor to a building’s structure and offer a safe and predictable method of rigging grids, clusters, arrays and other objects from overhead. This channel style beam clamp is adjustable and mounts flush underneath the building’s I-Beams flanges. It comes equipped with a centrally located rigging point for suspending objects from wire rope, rigging chain, spansets, etc.

Use one of two channel style beam clamps to provide a load rated overhead rigging point from structural I-Beams with flange widths ranging between 3” 12”(305mm). This beam clamp model provides a fast, easy and safe way to rig direct loads, bridles and hitches from overhead and a hand wrench is all that is required to secure this clamp. The beam flanges must be parallel to the floor to achieve the stated working loads.

Features:
Single load-rated center hang point
Provides safe load-rated hang point to 45° off center.
Two models secure to beam flanges ranging from 7” – 12” / 178mm to 305mm

Specifications:
SPECIFICATIONS                                                       PACKAGE CONTENTS
Material: All Steel Components                                   1 pc Beam Clamp Channel
Width: (BC7-12) 7” to 12” / 178mm to 305mm            1 pc Locking Angle Plate
Finish: Powder Coat                                                   2 pcs Flat Washer, 5/8”
Color: Black                                                              2 pcs Nyloc Nut, 5/8-11
WLL:     1600 lb / 725.7478 Kg (VERTICAL) on metal beams and 300lb / 136kg max on wooden beams
Design Factor:    5:1
45 DEG. WL:    1280 lb / 580.5982 Kg
DO NOT EXCEED 45° off hang points

Adaptive Technologies Group BC7-12-0 7" to 12" Open Hang Point Channel Style Beam Clamp

Use the BC7-12-0 channel style beam clamp to provide a load rated overhead rigging point from structural I-Beams with flange widths ranging between 7” and 12” (178-305mm ). This beam clamp model provides a fast, easy and safe way to rig direct loads from overhead and a hand wrench is all that is required to secure this clamp.

Features:
Single center hang points for 1/2″ to 5/8″ dia. threaded rod.
Provides safe load-rated hang points
Clamps securely to beam flanges ranging from 7″ – 12″

Specifications:
SPECIFICATIONS                               PACKAGE CONTENTS
Material: All Steel Components           1 pc 7”-12” Beam Clamp Channel
Width:(BC7-12-0) 7” to 12”                2 pcs Locking Angle Plate
WLL:1600 lbs / 726 Kg.                      2 pcs Flat Washer, 5/8”
Finish: Powder Coat                            2 pcs Nyloc Nut, 5/8-11
Color: Black
Design Factor: 5:1
Shipping Weight: 5.21 lb / 2.3 Kg

Adaptive Technologies Group MM-018 60lb Pan and Tilt Indoor Speaker Ceiling Mount

The MM-018 is a pan and tilt speaker mount that supports and aims cinema surround speakers that offer the standard four-point mounting pattern of 2-3/4” X 5”.

This mount aims and anchors surround speakers from overhead ceiling grids by way of a variety of tube extensions and adapters. Ceiling surrounds achieve up to 360 degrees of horizontal pan angle adjustments and up to 180 degrees of tilt angle adjustment.

Tilt adjustments are made at the side of the speaker adapter plate. Panning adjustments are made at the intersection of the the tube extension coupler and the speaker mount.

The MM-018’s tube coupler provides a pathway for signal wire and a safety cable to pass up through the tube extension, making for a cosmetically pleasing, safe and predictable method for installing ceiling speakers.

Features:
Weather resistant for covered outdoor and indoor use
Independent pan and tilt controls
Infinite locking adjustments
No memory drift
Single man speaker installations
Safety cables included with extension tubes

Specifications:
Material: Structural Steel Alloy                     1 pc Speaker Adapter Assy
Finish:Powder Coat                                        1 pc Coupler Adapter, 3/4-10 thread and 1/2 NPT
Tilt Rotation: 180 degrees                             2 pcs Set Screw, 1/4-20
Pan Angle: 360 degrees                                 1 pc Hex Bolt, 3/8-16 X 3/4″ Long
Color: Black                                                    1 pc Hex Bolt, Left Hand Thread 3/8-16 X 3/4″ Long
Design Factor: 7:1 ratio                                 2 pcs Star Washer, 3/8
WLL: 60 lbs. (27.2 Kg) max.
Net WGT: 4 lbs. (1.8 Kg.) each
Shipping WGT: 5 lbs. (2.3 Kg.) each
Pack Count: 1 units/carton

Adaptive Technologies Group SBC3-8-CA-20 20" Swivel Arm 3" to 8" Beam Clamp

Swivel Structural Beam Clamps are time-saving rigging solutions that provide a safe and load-rated method of securing loads from overhead Beams. Once anchored to a beam, they provide a simple and reliable method for aiming loudspeakers and other objects. Swivel Beam Clamps secure to a building’s overhead structural beams, steel or wood, for widths ranging from 3” to 12” (76 to 305 mm) wide. It’s lower suspension arm comes in a variety of lengths to suit the needs of the installation and rotates 360 degrees for precise aiming. Swivel Beam Clamps support a variety of rigging and mounting options including the AJ Series adjustable U-Brackets, fixed length wire rope suspensions and the Steerables® adjustable Tilt Cable Kits. These options provide accurate down tilt positioning for desired aiming requirements of any object from overhead.

Features:
Fast easy attachment to I-beams
Suspend and aim objects up to 685 lb.
Available for beam flanges from 3-12”
Two arm lengths for different size objects
Attach to steel & wooden beams

Specifications:
SPECIFICATIONS                              PACKAGE CONTENTS
Material: Structural Steel Alloy         1 pc 20” Cross Arm
Finish: Powder Coat                           1 pc 3”-8” Beam Clamp
Color: Black                                        1 bag Hardware Kit
Pan Rotation: 360 degrees
Tilt Rotation: Choose from below
Working Load: 430 lb / 195.5 Kg.
Design Factor: 7:1 ratio
Pack Count: 1/carton

Adaptive Technologies Group SBC3-8-CA-30 30" Swivel Arm 3" to 8" Beam Clamp

Swivel Structural Beam Clamps are time-saving rigging solutions that provide a safe and load-rated method of securing loads from overhead Beams. Once anchored to a beam, they provide a simple and reliable method for aiming loudspeakers and other objects. Swivel Beam Clamps secure to a building’s overhead structural beams, steel or wood, for widths ranging from 3” to 12” (76 to 305 mm) wide. It’s lower suspension arm comes in a variety of lengths to suit the needs of the installation and rotates 360 degrees for precise aiming. Swivel Beam Clamps support a variety of rigging and mounting options including the AJ Series adjustable U-Brackets, fixed length wire rope suspensions and the Steerables® adjustable Tilt Cable Kits. These options provide accurate down tilt positioning for desired aiming requirements of any object from overhead.

Features:
Fast easy attachment to I-beams
Suspend and aim objects up to 685 lb.
Available for beam flanges from 3-12”
Two arm lengths for different size objects
Attach to steel & wooden beams

Specifications:
SPECIFICATIONS                              PACKAGE CONTENTS
Material: Structural Steel Alloy           1 pc 30” Cross Arm
Finish: Powder Coat                             1 pc 3”-8” Beam Clamp
Color: Black                                          1 bag Hardware Kit
Pan Rotation: 360 degrees
Tilt Rotation: Choose from below
Working Load: 430 lb / 195.5 Kg.
Design Factor: 7:1 ratio
Pack Count: 1/carton

Adaptive Technologies Group SBC7-12-CA-20 20" Swivel Arm 7" to 12" Beam Clamp

Swivel Structural Beam Clamps are time-saving rigging solutions that provide a safe and load-rated method of securing loads from overhead Beams. Once anchored to a beam, they provide a simple and reliable method for aiming loudspeakers and other objects. Swivel Beam Clamps secure to a building’s overhead structural beams, steel or wood, for widths ranging from 3” to 12” (76 to 305 mm) wide. It’s lower suspension arm comes in a variety of lengths to suit the needs of the installation and rotates 360 degrees for precise aiming. Swivel Beam Clamps support a variety of rigging and mounting options including the AJ Series adjustable U-Brackets, fixed length wire rope suspensions and the Steerables® adjustable Tilt Cable Kits. These options provide accurate down tilt positioning for desired aiming requirements of any object from overhead.

Features:
Fast easy attachment to I-beams
Suspend and aim objects up to 685 lb.
Available for beam flanges from 3-12”
Two arm lengths for different size objects
Attach to steel & wooden beams

Specifications:
SPECIFICATIONS                              PACKAGE CONTENTS
Material: Structural Steel Alloy       1 pc 20” Cross Arm
Finish: Powder Coat                         1 pc 7”-12” Beam Clamp
Color: Black                                      1 bag Hardware Kit
Pan Rotation:   360 degrees
Tilt Rotation:   Choose from below
Working Load:   430 lb / 195.5 Kg.
Design Factor:   7:1 ratio
Pack Count:   1/carton

Adaptive Technologies Group SBC7-12-CA-30 30" Swivel Arm 7" to 12" Beam Clamp

Swivel Structural Beam Clamps are time-saving rigging solutions that provide a safe and load-rated method of securing loads from overhead Beams. Once anchored to a beam, they provide a simple and reliable method for aiming loudspeakers and other objects. Swivel Beam Clamps secure to a building’s overhead structural beams, steel or wood, for widths ranging from 3” to 12” (76 to 305 mm) wide. It’s lower suspension arm comes in a variety of lengths to suit the needs of the installation and rotates 360 degrees for precise aiming. Swivel Beam Clamps support a variety of rigging and mounting options including the AJ Series adjustable U-Brackets, fixed length wire rope suspensions and the Steerables® adjustable Tilt Cable Kits. These options provide accurate down tilt positioning for desired aiming requirements of any object from overhead.

Features;
Fast easy attachment to I-beams
Suspend and aim objects up to 685 lb.
Available for beam flanges from 3-12”
Two arm lengths for different size objects
Attach to steel & wooden beams

Specifications:
SPECIFICATIONS                                   PACKAGE CONTENTS
Material: Structural Steel Alloy             1 pc 30” Cross Arm
Finish: Powder Coat                               1 pc 7”-12” Beam Clamp
Color: Black                                            1 bag Hardware Kit
Pan Rotation: 360 degrees
Tilt Rotation: Choose from below
Working Load: 430 lb / 195.5 Kg.
Design Factor: 7:1 ratio
Pack Count: 1/carton

Adaptive Technologies Group SAS-1WA-20 One Way Array 20" Steerable Speaker Cross Arm

Save time and reduce clutter. The One-Way-Array™ is an easy use load-rated and off-the-shelf loudspeaker rigging and aiming system for single loudspeakers. It is ideal for aiming sound for left and right of house configurations and provides side & back fill coverage where speakers cannot be wall mounted.

The top section of the One-Way-Array rigs from two overhead suspension points such as along a beam. The lower section supports the loudspeaker but rotates relative to the upper section, up to 360° horizontally. This gives the installer precise horizontal aiming of the loudspeaker.

For precise vertical tilting, select from a variety of U-Brackets or Steerables® Adjustable Tilt Cable Kit systems. Load rated shackles and wire ropes are included in these kits.

Features:
Steer Speakers up to 360° pan angle
Supports loads up to 300lb
Includes suspension hardware & decorative end caps
Load rated steel alloy components
Tough enamel powder coat

Specifications:
Material:   Alloy structural steel tube powder
Finish:   coat paint
Color:   Black
WLL:   300 lbs/136 Kg
Design Factor:   10:1 ratio
Pack Count:   1/carton
* Includes eyebolts & hardware kit

Adaptive Technologies Group SAS-100-CM 100lb Steerable Indoor Ceiling Speaker Mount

The Steerables® Ceiling Mount, SAS-100-CM, suspends and aims loudspeakers and other objects weighing up to 100 lbs/45 Kg up close to ceiling and other overhead surfaces.

This design is ideal for applications where cabinets equipped with suspension points need to be suspended and aimed, close but out of reach of the audience. Typical applications include churches, schools, gymnasiums, auditoriums, theme parks, nightclubs, bars and restaurants.

Loudspeaker cabinets equipped with suspension or mounting points can be easily mounted and aimed from ceilings and other structurally secure overhead structures with unprecedented ease of installation and precise adjustments.

Features:
Suspends and aims flyable and mountable loudspeakers
Secures to ceiling and other overhead structures using standard schedule 40, 1-1/2″ diameter pipe.
More headroom keeps cabinets out of reach
Unique cross arm steering mechanism offers 360° of pan control
Significant reductions in installation and planning time
Adapts to standard Adaptive U-Series mounts and Steerables® Tilt Cable Kits

Specifications:
Material: Structural Steel Alloy        1 pc. Ceiling Plate
Finish: Powder Coat                          1 pc. 1-1/2″ Connector Tube
Color: Black                                       1 pc. Cross Arm
Pan Rotation: 360° horizontal swivel max.       1 pc. Hardware Kit
Working Load Limit: 100 lbs./45 kg.
Design Factor: 10:1 ratio based on ultimate yield point
Net Weight: 11.5 lbs./5.2 Kg.
Shipping Weight: 12.5 lbs./5.7 Kg
Pack Count: 1/carton
Hardware for mounting to the ceiling structure is not included.
Tilt mechanism is ordered separately.

Adaptive Technologies Group SAS-100-WM 100lb Indoor Wall Arm Speaker Mount

The Steerables® SAS-100-WM suspends and aims loudspeakers from
walls and other vertical structures.

Loudspeaker cabinets equipped with rigging points can be suspended
and aimed with unprecedented ease and precision. Pan and tilt adjustments
can be made or remade within seconds.

Ideal applications include permanently installed loudspeakers in churches,
schools, gymnasiums, auditoriums, theme parks nightclubs, bars and
restaurants.

The Steerables® unique Cross-Arm steering mechanism provides up to
360 degrees of pan control while tilting is achieved either through the
addition of a standard Allen Products U-Series bracket or Steerables®
Tilt Cable Kit (see respective data sheets for more details).

Features:
Suspends riggable loudspeakers from walls and Suspends riggable loudspeakers from walls and other vertical surfaces
Unique cross arm steering mechanism offers 360°Unique cross arm steering mechanism offers 360° of pan control
Significant reductions in installation and planning time
Accommodates standard Allen Products U-Series bracketsAccommodates standard Allen Products U-Series brackets and Steerables® Tilt Cable Kits
Minimal mounting surface area required

Specifications:
Material: Structural steel alloy tube and plate               1 pc. Suspension Arm
Finish: Powder Coat                                                         1 pc. Cross Arm
Color: Textured black                                                       1 pc. Hardware Kit
Pan Rotation: 360° horizontal swivel max
WLL: 100 lbs./45 kg.
Design Factor: 10:1 ratio based on10:1 ratio based on ultimate yield point
Shipping Weight: 17 lbs./7.7 kg.
Pack Count: 1 unit/carton

Adaptive PM-24-6UP-G Standard Outdoor Loudspeaker Pole Mount w/ 90" Band Kit

The UniFrame is a complete mounting solution for outdoor loudspeakers. Its design combines the attributes of the PoleStar® stainless “a-lacarte” version into just two models produced in steel and then galvanized to an outdoor weather rating.

The UniFrame reduces the amount of parts required for the job site and saves installation time by combining the support arm and the pole adapter together into one assembly. In addition, two stainless steel band kits are included, which only require a socket set to assemble.

The support arm is welded together for extra strength and durability. Each arm includes three attach point mounting holes at the end of the arm that allow the installer to select the desired distance between the loudspeaker and the pole.

Features:

• Uni-Frame assembly adds strength and reduces installation time.

• Longer pole interface increases structural capacity.

• Rugged outdoor galvanized finish to ASTM A123 and

• ISO1461 specifications.

• Three arm mounting points to accommodate all speaker models.

• Angled brace increases structural stability during severe

• weather conditions.

• Support arm may be oriented up or down for installation flexibility.

• Dual adapter may be secured to the Uni-Frame for a three-way installation.

Specifications:
Material: Steel Alloy
Finish: Galvanized
Color: Silver
WLL: 190 lb / 86.4 Kg single speaker
WLL: 500 lb / 227 Kg three equal weight speakers
Design Factor: 10:1 ratio
*WLL = Working Load Limit

Adaptive Technologies SB-18 18" Speaker and Line Array Rigging Swivel Beam

The SwivelBeam is an easy to use load-rated and off the shelf loudspeaker rigging and aiming system from single loudspeakers to full line arrays. It is ideal for aiming sound in left and right of house configurations and provides side and backfills where speakers cannot be wall mounted. The upper cross arm of the SwivelBeam rigs from two overhead suspension points. The lower cross arm supports the loudspeaker and rotates relative to the upper section, horizontally, up to 360°.

This gives the installer precise horizontal aiming of sound. For precise vertical aiming, a self-contained cabinet located behind the lower cross arm. Typical venues include theatres, churches, school auditoriums, gymnasiums, sport arenas, meeting halls and theme park attractions.

Features:

• Central pivot for steering

• Rear pull back point for tilting

• Rugged Steel Construction

• Powder Coat Finish

Specifications:
Material: Alloy Structural Steel Tube
Finish: Powder Coat Paint
Color: Black
WLL: 685 lb / 311 Kg
Design Factor: 7:1
Pack Count: 1/carton
1 pc Swivel Beam

Adaptive Technologies AJ-2336-BT Adjustable Width Wall & Ceiling Speaker Mount

Adjustable Loudspeaker Mounting Kits support most of the mountable loudspeakers in the 85 lbs./38 kg. range, or less and its open side arm slots allow a single installer to easily mount loudspeakers in this weight range. Loudspeakers can be rotated within the arms to acquire the desired tilt angle. Separate side holes permit the angle of the speaker to be locked permanently using lag bolts. Since there are only two sizes, inventory requirements are minimal.

Fully captive arm holes permit safe, secure mounting of loudspeakers under balconies, overhangs and from ceilings. The brackets’ base gives installers multiple options for placing speakers over irregular and unpredictable mounting surfaces because of its unique mounting slot pattern.

Features:

• Packed in pairs

• Two models support most loudspeakers, weighs 85 lbs/36 kg. or less

• Compatible with EAW – MK2300i Series

• 16” and 24” hole centers match wall studs.

• Open arm slots for one man installation.

• Sound isolation gaskets block sound

• transmission through walls.

• Permanent angle set capable.

Specifications:
Material: Structural Steel Alloy
Down Tilt: Up to 60 degrees
Finish: Powder Coat
Color: Black
WLL: 85 lbs/38.6 Kg
Design Factor: 7:1 ratio
Includes an assortment of 1/4”, 5/16” and 3/8” bolts and hardware plus two 1/4” thick sound isolation gaskets.

Adaptive Technologies PM-24-6DOWN-G Standard Outdoor Pole Mounts w/ 20" Band Kit

The UniFrame is a complete mounting solution for outdoor loudspeakers. Its design combines the attributes of the PoleStar® stainless “a-lacarte” version into just two models produced in steel and then galvanized to an outdoor weather rating.

This single speaker pole mount reduces the amount of parts required for the job site and saves installation time by combining the support arm and the pole adapter together into one assembly. In addition, two stainless steel band kits are included, which only require a socket set to assemble.

The support arm is welded together for extra strength and durability. Each arm includes three attach point mounting holes at the end of the arm that allow the installer to select the desired distance between the loudspeaker and the pole.

Features:

• Uni-Frame assembly adds strength and reduces installation time.

• Longer pole interface increases structural capacity.

• Rugged outdoor galvanized finish to ASTM A123 an

• ISO1461 specifications.

• Three arm mounting points to accommodate all speaker models.

• Angled brace increases structural stability during severe

• weather conditions.

• Support arm may be oriented up or down for installation flexibility.

• Dual adapter may be secured to the Uni-Frame for a three-way installation.

Specifications:
Material: Steel Alloy
Finish: Galvanized
Color: Silver
WLL: 190 lb / 86.4 Kg single speaker
Design Factor: 10:1 ratio
*WLL = Working Load Limit

Adaptive Technologies PM-SAFETY-6DOWN Pole Bracket Galvanized Safety Anchor

When the pole or column does not offer an adequate way to attach safety cables, specify the PM-Safety-6Down and corresponding band kit. This mount provides a structural method for anchoring safety cables. It installs above the pole adapter and safety cables are then secured to the safety anchor and each loudspeaker, thus by-passing the pole adapter completely.

Features:

• Mounts to round surfaces including poles and columns

• Galvanized

• Load rated components

• Components use common hole patterns

• Cosmetic trim components included

• Job-site ready

Specifications:
Galvanized Steel Alloy
Galvanized Passivated
WLL: 300lb / 136.078

Adaptive Technologies PM-MOUNT-6UP 6” Marine Grade Pole Adapter Speaker Mount

For 6”/154mm diameter and larger poles and columns, use the PM-Mount-6UP. This all-stainless adapter offers a natural finish and supports up to 300 lb./68 Kg, in a vertical load with a 5:1 design factor. It accommodates the PM Series Support Arm, Dual Adapter and includes hardware for their attachment. There are four standard permanent band kits available in different lengths and are sold separately. Custom lengths are also available

Features:

• Mounts to round surfaces including poles and columns

• All stainless steel construction

• Load rated components

• Components use common hole patterns

• Cosmetic trim components included

• Job-site ready

Specifications:
Stainless Steel
Natural Passivated

Adaptive Technologies BC3-8-0 3" to 8" Open Hang Point Channel Style Beam Clamp

Use the BC3-8 channel style beam clamp to provide a load rated overhead rigging point from structural I-Beams with flange widths ranging between 3” and 8” (76-203 mm). This beam clamp model provides a fast, easy and safe way to rig direct loads from overhead and a hand wrench is all that is required to secure this clamp.

Features:

• Single center hang points for 1/2″ to 5/8″ dia. threaded rod.

• Provides safe load-rated hang points

• Clamps securely to beam flanges ranging from 3″ – 8″

Specifications:
Material: All Steel Components
Width:(BC20-26-2) 20” to 26”
WLL:2100 lbs / 953 Kg.
Finish: Powder Coat
Color: Black
Design Factor: 5:1
Shipping Weight: 3.2 lbs / 1.45 Kg.
1 pc 3”-8” Beam Clamp Channel
2 pcs Locking Angle Plate.
2 pcs Flat Washer, 5/8”
2 pcs Nyloc Nut, 5/8-11

Adaptive Technologies MM-024-BT MultiMount 60lb Pan and Tilt Speaker Wall Mount

The MultiMount MM-024 Indoor Speaker Wall Mount supports loudspeakers weighing up to 60 lbs. in a vertical orientation, quickly attaching them to walls and other vertical structures. Speakers are independently aimed and locked in almost any direction or angle through the use of independent pan, tilt, and swivel adjustments.

The MultiMount MM-024 Indoor Speaker Wall Mount s unique telescoping arm acts as a convenient carrying handle to lift speakers into place then inserts into the wall mounting plate. Once inserted, the mounting plate supports the weight of the speaker leaving the installers hands free to complete the wiring and positioning process.

Tilt adjustments are made at the side of the speaker adapter plate. Panning adjustments are made at the mounting plate and a third rotation is available between the speaker and the support arm.

Features:

• Weather resistant for covered outdoor and indoor use

• Independent, no drift, pan and tilt controls

• Infinite locking adjustments

• No lock memory – no drift

• Single man speaker installations

• Optional safety cables available

• Conforms to multiple mounting hole patterns

• Including 2 x 4-1/4 and 2-3/4 x 5

Material: Structural Steel Alloy
Finish:Powder Coat
Color: Black
Tilt Rotation: 180° max.
Swivel Rotation: 140° max.
WLL: 60 lbs. (27.2 Kg) max.
Design Factor: 10:1 ratio
Net WGT: 4 lbs. (1.8 Kg) each
Shipping WGT: 5 lbs. (2.3 Kg) each
1 pc Hardware Kit
1 pc Support Arm Assy
1 pc Speaker Adapter
1 pc Mounting Plate

Adaptive Technologies MM-3RDX-18 60lb Adjustable Ceiling Speaker Mount

The MM-3RDX-18 is an adjustable ceiling speaker mount that provides pan, tilt & roll adjustments. It supports and aims speakers that are equipped with either the 2 X4-1/4 or the 2-3/4” X 5” 4-point mounting pattern.

This model aims speakers from overhead by way of a variety of tube extensions and ceiling attachments. Ceiling speakers achieve up to 360 degrees of horizontal pan angle, up to 180 degrees of tilt angle and 180 degrees of roll adjustment.

Tilt adjustments are made at the side of the speaker adapter plate, Pan-adjustments are made at the tube extension coupler and the roll feature is adjusted between the mount and the tube extension. The MM-3RDX-18 tube coupler provides a pathway for signal wire and a safety cable to pass through the tube extension to the terminal block. This makes for a clean, safe and predictable method for installing and aiming ceiling speakers.

Features:

• Weather resistant for covered outdoor and indoor use

• Indicators let installers set angles accurately

• Independent pan, tilt & roll aiming gets

• perfect sound coverage

• Adapts to standard schedule-40 ½” pipe

• Independent No drift, No memory Locking

• Works for speakers with 2 X 4-1/4 and

• 2-3/4X 5 Hole Patterns

Specifications:
Material: Structural Steel Alloy
Finish: Powder Coat
Tilt Rotation: +/-90 degrees max
Pan Rotation: 360 degrees
Color: Black
WLL: 60 lbs. (27.2 Kg) max.
Design Factor: 7:1 ratio
Net WGT: 5 lbs. (2.3 Kg.) each
Shipping WGT: 6 lbs. (2.7 Kg.) each
Pack Count: 1 unit/carton
1 pc 3-axis mount

Adaptive Technologies AJ-1524-BT 60lb Adjustable Wall & Ceiling Speaker Mount

**Sold in pairs only so you must order in quantities of 2 only **

Adjustable Loudspeaker Mounting Kits support most of the mountable loudspeakers in the 60 lbs./22 kg. range, or less and its open side arm slots allow a single installer to easily mount loudspeakers in this weight range. Loudspeakers can be rotated within the arms to acquire the desired tilt angle. Separate side holes permit the angle of the speaker to be locked permanently using lag bolts. Since there are only two sizes, inventory requirements are minimal.

Fully captive arm holes permit safe, secure mounting of loudspeakers under balconies, overhangs and from ceilings. The brackets’ base gives installers multiple options for placing speakers over irregular and unpredictable mounting surfaces because of its unique mounting slot pattern.

Features:

• Two models support most loudspeakers, weighs 60 lbs/27 kg. or less

• 16” and 24” hole centers match wall studs

• Open arm slots for one man installation

• Sound isolation gaskets block sound transmission through walls

• Permanent angle set capable.

Specifications:
Material: Structural Steel Alloy
Down Tilt: Up to 60 degrees
Finish: Powder Coat
Color: Black
WLL: 60 lbs/27 Kg
Design Factor: 7:1 ratio
Includes an assortment of 1/4”, 5/16” and 3/8” bolts and hardware plus two 1/4” thick sound isolation gaskets.

Adaptive Technologies PM-DA-48 48" Marine Grade Dual Speaker Adapter Pole Mount

The Dual Adapter is an innovative way to mount and aim two loudspeakers and other objects (of equal weight and mass) from the same Pole or column. A variety of available mounting holes permit speakers to be installed closer or further from the pole to provide clearance for different down tilt angles. The Dual Adapter is produced from stainless steel in a natural finish and supports up to the stated maximum working load of the pole adapter . Decorative end caps provide a finished look and hardware is included to secure it to the pole adapter and/or support arm. Yokes and U-Brackets are not included.

Features:

• Mounts to round surfaces including poles and columns

• All stainless steel construction

• Load rated components

• Components use common hole patterns

• Cosmetic trim components included

• Job-site ready

• Stainless Steel

• Natural Passivated

Adaptive Technologies Group CC-096 Wire Rope Tilt Cable Coupler Kit for Speaker

The Steerables® Pull back and coupler cable kit serves as a pullback and coupling device for flyable loudspeakers and can be used in a wide range of rigging applications. It provides an easy and infinitely adjustable feature for loudspeakers and other objects weighing up to 220 lbs/134 kg.

SPECIFICATIONS
• Material: Stainless Steel
• 1 pc. 8 foot stainless wire rope
• Color: Black
• 2 pc. 4 inch tie wrap
• WLL: 220 lbs./99.8 kg.
• 2 pc. 1/4 inch shackles
• Length: 8inch/99mm
• 1 pc. Clutch lock mechanism
• 1 pc. 3/8 inch eyenut
