Sonance PS-P63T-WH High-Performance Hanging Pendant Speaker for Open Ceilings

The Sonance PS-P63T pendant speaker features a sleek, lighting-inspired design with a one-piece grille for seamless aesthetics. Its integrated top cover conceals hardware and wiring. A high-excursion 6.5" woofer and pivoting 1" tweeter ensure accurate sound. UL 1480 and UL 2239 certifications guarantee safety and reliable performance.

Key Features

• Class-leading sensitivity & sonic performance

• Exceptional off-axis response

• Heavy duty voice coil for longevity and reliability

• Full-fidelity transformer for uncompromised tonality

• Consistent voicing across product range

• Clean, elegant design inspired by pendant light fixtures

• Connector and hanger top cover to hide hardware

• Available in black or white (paintable)

• Magnetic grille retention for fast installation and removal

• Front-mounted finger-adjustable selector tap

• Hanging hardware supplied

Specifications

Color

White

HF Driver

1" (25mm) Cloth Dome, Pivoting, Ferrofluid cooled

LF Driver

6.5" (165mm) Polypropylene Cone, Butyl Rubber Surround

Frequency Response (+/- 10db)

49Hz-25kHz

Frequency Response (+/- 3db)

65Hz - 20kHz

Power Handling (RMS)

120 watts program, 60 watts pink noise

Sensitivity

88dB (2.83V/1m)

Rated Maximum SPL

108dB @ 1 meter (3.3 feet), 116dB peak

Nominal Impedance (Ohms)

8 Ohms

Transformer Taps

70 V / 100 V: 60W, 30W and 15W 70 V: 7.5W

Dimensions (Diameter x D)

9.13" x 15.6" (231.9mm x 396.24mm)

Grille

Bezel-less magnetically retained grille

Input Connector

Four pin Euroblock with loop output connections

Certifications

UL 1480, UL 2239, NFPA 70

The Sonance PS-C83RWT in-ceiling woofer features a bezel-less magnetic grille, optional square adapter, and an ultra-high-excursion 8" woofer for powerful bass. Its sealed metal enclosure includes cable clamping, a removable Euroblock connector, and seismic attachment. UL 1480 and UL 2043 certified, it ensures safety and reliable bass augmentation.


Key Features

• Class-leading sensitivity & sonic performance

• Exceptional off-axis response

• Heavy duty voice coil for longevity and reliability

• Full-fidelity transformer for uncompromised tonality

• Consistent voicing across product range

• Bezel-less design for clean and minimalistic aesthetic

• Optional black grilles in round or square

• Magnetic grille retention for fast installation and removal

• Finger-adjustable selector tap

• One-step simplified painting process



  Specifications

  SKU

  40133 (White)

  LF Driver

  8" (203mm) Polypropylene Cone, Butyl Rubber Surround

  Frequency Response (+/- 10db)

  32Hz – 300Hz

  Frequency Response (+/- 3db)

  50Hz – 150Hz

  Power Handling (RMS)

  200W program, 125W pink noise

  Sensitivity

  89dB (2.83V/1m)

  Rated Maximum SPL

  110dB @ 1 meter (3.3 feet, 116dB peak

  Nominal Impedance (Ohms)

  8 ohms

  Transformer Taps

  70 V / 100 V: 120W, 60W and 30W 70 V: 15W

  Dimensions (Diameter x D)

  11.06" x 9.84" (280.92mm x 249.94mm)

  Cut-Out Dimensions (Diameter)

  10.125" (257.18mm)

  Knockout

  One, Side mounted 0.75" (19mm)

  Weight

  14.95 lbs. (6.78kg)

  Grille

  One Piece Paintable Grille with Magnetic Retention

  Input Connector

  Four pin, Euroblock with loop output connections

  Certifications

  UL 1480; UL 2043; NFPA 90A; NFPA 70

  Suspension Points

  One, on top surface

  Maximum SPL (Peak)

  116dB peak

  Architectural Specifications

  The loudspeaker shall be of the woofer-type comprising a single flush mount enclosure containing

The Sonance PS-P83WT pendant woofer features a minimalistic design with a one-piece grille for consistent aesthetics. Its integrated top cover hides hardware and wiring. An ultra-high-excursion 8" polypropylene woofer provides powerful low bass. Certified for UL 1480 and UL 2239, ensuring safety and reliable performance.

Key Features

• Class-leading sensitivity & sonic performance

• Exceptional off-axis response

• Heavy duty voice coil for longevity and reliability

• Full-fidelity transformer for uncompromised tonality

• Consistent voicing across product range

• Clean, elegant design inspired by pendant light fixtures

• Connector and hanger top cover to hide hardware

• Available in black or white (paintable)

• Magnetic grille retention for fast installation and removal

• Front-mounted finger-adjustable selector tap

• Hanging hardware supplied

Specifications

SKU | Color

40141 (Black), 40137 (White)

LF Driver

8" (203mm) Polypropylene Cone, Butyl Rubber Surround

Frequency Response (+/- 10db)

32Hz – 300Hz

Frequency Response (+/- 3db)

50Hz - 150Hz

Power Handling (RMS)

300 watts program, 150 watts pink noise

Sensitivity

89dB (2.83V/1m)

Rated Maximum SPL

110dB @ 1 meter (3.3 feet), 116dB peak

Nominal Impedance (Ohms)

8 Ohms

Transformer Taps

70 V / 100 V: 120W, 60W and 30W 70 V: 15W

Dimensions (Diameter x D)

11.06" x 19.7" (280.92mm x 500.38mm)

Grille

Bezel-less magnetically retained grille

Input Connector

Four pin Euroblock with loop output connections

Certifications

UL 1480, UL 2239, NFPA 70

The PS-S85T is a high-output surface-mount loudspeaker built for commercial environments. Its UL94V-0 polypropylene enclosure and IPX4 ingress protection support both indoor and outdoor deployment, while the 8" aluminum woofer and neodymium compression driver deliver 93dB sensitivity and selectable dispersion patterns.


Key Features

• Field-selectable 120° or 80° dispersion coverage

• Horn and collar assembly ships in-box; field-adjustable

• 1.4" compression driver engineered for high-SPL commercial environments

• Extended low-frequency response

• Integrated 70V/100V transformer, 120W max tap

• Part of a complete High Output form factor family




  Specifications

  SKU

  40236 (Black - RAL 7021), 40235 (White - RAL 9003)

  HF Driver

  1.4" (36mm) aluminum dome compression driver, 36mm Voice Coil Size, 1" (25mm) Exit Size, Neodymiu...

  LF Driver

  8" (203mm) aluminum cone, Santoprene surround, 60.55mm Voice Coil Size, Ferrite Magnet

  Frequency Response (+/- 10db)

  36.6Hz - 25kHz

  Frequency Response (+/- 3db)

  41.4Hz - 20kHz

  Power Handling (RMS)

  150 watts (600 watts peak), 100 hours

  Sensitivity

  93dB SPL

  Enclosure

  Polypropylene plastic (UL94V-0)

  Rated Maximum SPL

  114dB, 120dB peak

  Nominal Impedance (Ohms)

  8 ohms

  Transformer Taps

  70 V / 100 V: 120W, 60W and 30W 70 V: 15W

  Coverage Pattern 1kHz to 10kHz

  120 or 80 Degree Axis Symmetric

  Dimensions (WxHxD)

  11.57" x 19.47" x 10.25" (293.88mm x 494.54mm x 260.35mm)

  Weight

  29.3 lbs. (13.29kg)

  Grille

  Steel

  Input Connector

  Four pin, Euroblock with loop output connections

  Certifications

  UL 1480A;CSA-C22.2 No.205;NFPA70;NFPA 90A

  Suspension Points

  Top, Bottom and Back

  Maximum SPL (Peak)

  120dB peak

  Architectural Specifications

  The loudspeaker shall be of the two-way type comprising a single surface mount enclosure

The Sonance PS-C83RT in ceiling speaker features a bezel-less magnetic grille, optional square adapter, high-excursion 8" woofer, and pivoting tweeter for precise sound. Its sealed metal enclosure includes cable clamping, a removable Euro block connector, and seismic attachment. UL 1480 and UL 2043 certifications ensure safety and reliable performance.


Key Features

• Class-leading sensitivity & sonic performance

• Exceptional off-axis response

• Heavy duty voice coil for longevity and reliability

• Full-fidelity transformer for uncompromised tonality

• Consistent voicing across product range

• Bezel-less design for clean and minimalistic aesthetic

• Optional black grilles in round or square

• Magnetic grille retention for fast installation and removal

• Finger-adjustable selector tap

• One-step simplified painting process


  Specifications

  SKU

  45132 (White)

  HF Driver

  1" (25mm) Cloth Dome, Pivoting, Ferrofluid cooled

  LF Driver

  8" (203mm) Polypropylene Cone, Butyl Rubber Surround

  Frequency Response (+/- 10db)

  41Hz-25kHz

  Frequency Response (+/- 3db)

  55Hz - 20kHz

  Power Handling (RMS)

  160W program, 80W pink noise

  Sensitivity

  91dB (2.83V/1m)

  Rated Maximum SPL

  110dB @ 1 meter (3.3 feet), 116dB peak

  Nominal Impedance (Ohms)

  8 ohms

  Transformer Taps

  70 V / 100 V: 60W, 30W and 15W 70 V: 7.5W

  Dimensions (Diameter x D)

  11.06" x 9.84" (280.92mm x 249.94mm)

  Cut-Out Dimensions (Diameter)

  10.125" (257.18mm)

  Knockout

  One, Side mounted 0.75" (19mm)

  Weight

  13.41 lbs. (6.08kg)

  Grille

  One Piece Paintable Grille with Magnetic Retention

  Input Connector

  Four pin, Euroblock with loop output connections

  Certifications

  UL 1480; UL 2043; NFPA 90A; NFPA 70

  Suspension Points

  One, on top surface

  Maximum SPL (Peak)

  116dB peak

  Architectural Specifications

  The loudspeaker shall be of the two-way type comprising a single flush mount enclosure containing

The PS-P85T is a high-output pendant loudspeaker for professional commercial installations. Sharing the same 8" aluminum cone driver and neodymium compression driver platform as the PS-C85RT, it delivers 88dB sensitivity and selectable 120°/80° dispersion with full 70V/100V transformer compatibility.


Key Features

• Field-selectable 120° or 80° dispersion coverage

• Horn and collar assembly ships in-box; field-adjustable

• 1.4" compression driver engineered for high-SPL commercial environments

• Extended low-frequency response

• Integrated 70V/100V transformer, 120W max tap

• Part of a complete High Output form factor family


  Specifications

  SKU

  40234 (Black - RAL 7021), 40233 (White - RAL 9003)

  HF Driver

  1.4" (36mm) aluminum dome compression driver, 36mm Voice Coil Size, 1" (25mm) Exit Size, Neodymium

  LF Driver

  8" (203mm) aluminum cone, Santoprene surround, 60.55mm Voice Coil Size, Ferrite Magnet

  Frequency Response (+/- 10db)

  36.6Hz - 25kHz

  Frequency Response (+/- 3db)

  41.4Hz - 20kHz

  Power Handling (RMS)

  150 watts (600 watts peak), 100 hours

  Sensitivity

  88dB SPL

  Enclosure

  Polypropylene plastic (UL94V-0)

  Rated Maximum SPL

  109dB, 115dB peak

  Nominal Impedance (Ohms)

  8 ohms

  Transformer Taps

  70 V / 100 V: 120W, 60W and 30W 70 V: 15W

  Coverage Pattern 1kHz to 10kHz

  120 or 80 Degree Axis Symmetric

  Dimensions (Diameter x D)

  11.17" x 24.69" (283.72mm x 627.13mm)

  Weight

  23.55 lbs. (10.68kg)

  Grille

  Steel

  Input Connector

  Four pin, Euro block with loop output connections

  Certifications

  UL 1480A;CSA-C22.2 No.205;NFPA70;NFPA 90A

  Suspension Points

  Back

  Maximum SPL (Peak)

  115dB peak

  Architectural Specifications

  The loudspeaker shall be of the two-way type comprising a single pendant mount enclosure

The PS-P85T is a high-output pendant loudspeaker for professional commercial installations. Sharing the same 8" aluminum cone driver and neodymium compression driver platform as the PS-C85RT, it delivers 88dB sensitivity and selectable 120°/80° dispersion with full 70V/100V transformer compatibility.


Key Features

• Field-selectable 120° or 80° dispersion coverage

• Horn and collar assembly ships in-box; field-adjustable

• 1.4" compression driver engineered for high-SPL commercial environments

• Extended low-frequency response

• Integrated 70V/100V transformer, 120W max tap

• Part of a complete High Output form factor family


  Specifications

  SKU

  40234 (Black - RAL 7021), 40233 (White - RAL 9003)

  HF Driver

  1.4" (36mm) aluminum dome compression driver, 36mm Voice Coil Size, 1" (25mm) Exit Size, Neodymiu...

  LF Driver

  8" (203mm) aluminum cone, Santoprene surround, 60.55mm Voice Coil Size, Ferrite Magnet

  Frequency Response (+/- 10db)

  36.6Hz - 25kHz

  Frequency Response (+/- 3db)

  41.4Hz - 20kHz

  Power Handling (RMS)

  150 watts (600 watts peak), 100 hours

  Sensitivity

  88dB SPL

  Enclosure

  Polypropylene plastic (UL94V-0)

  Rated Maximum SPL

  109dB, 115dB peak

  Nominal Impedance (Ohms)

  8 ohms

  Transformer Taps

  70 V / 100 V: 120W, 60W and 30W 70 V: 15W

  Coverage Pattern 1kHz to 10kHz

  120 or 80 Degree Axis Symmetric

  Dimensions (Diameter x D)

  11.17" x 24.69" (283.72mm x 627.13mm)

  Weight

  23.55 lbs. (10.68kg)

  Grille

  Steel

  Input Connector

  Four pin, Euroblock with loop output connections

  Certifications

  UL 1480A;CSA-C22.2 No.205;NFPA70;NFPA 90A

  Suspension Points

  Back

  Maximum SPL (Peak)

  115dB peak

  Architectural Specifications

  The loudspeaker shall be of the two-way type comprising a single pendant mount enclosure

The Sonance PS-C43RT in-ceiling speaker features a bezel-less magnetic grille, optional square adapter, high-excursion woofer, and pivoting tweeter for precise sound coverage. Its sealed metal enclosure includes cable clamping, a removable Euro block connector, and seismic attachment. UL 1480 and UL 2043 certifications ensure safety and reliability in installations.


Key Features

• Class-leading sensitivity & sonic performance

• Exceptional off-axis response

• Heavy duty voice coil for longevity and reliability

• Full-fidelity transformer for uncompromised tonality

• Consistent voicing across product range

• Bezel-less design for clean and minimalistic aesthetic

• Optional black grilles in round or square

• Magnetic grille retention for fast installation and removal

• Finger-adjustable selector tap

• One-step simplified painting process

  Specifications

  SKU

  45130 (White)

  HF Driver

  1" (25mm) Cloth Dome, Pivoting, Ferrofluid cooled

  LF Driver

  4" (100mm) Polypropylene Cone, Butyl Rubber Surround

  Frequency Response (+/- 10db)

  57Hz - 25kHz

  Frequency Response (+/- 3db)

  75Hz - 20kHz

  Power Handling (RMS)

  60W program, 30W pink noise

  Sensitivity

  87dB (2.83V/1m)

  Rated Maximum SPL

  105dB @ 1 meter (3.3 feet), 110dB peak

  Nominal Impedance (Ohms)

  8 ohms

  Transformer Taps

  70 V / 100 V: 30W, 15W and 7.5W 70 V: 3.8W

  Dimensions (Diameter x D)

  6.3" x 7.01" (160.02mm x 178.05mm)

  Cut-Out Dimensions (Diameter)

  5.875" (149.23mm)

  Knockout

  One, Side mounted 0.75" (19mm)

  Weight

  5.63 lbs. (2.55kg)

  Grille

  One Piece Paintable Grille with Magnetic Retention

  Input Connector

  Four pin, Euroblock with loop output connections

  Certifications

  UL 1480; UL 2043; NFPA 90A; NFPA 70

  Suspension Points

  One, on top surface

  Maximum SPL (Peak)

  110dB peak

  Architectural Specifications

  The loudspeaker shall be of the two-way type comprising a single flush mount enclosure containing

The Sonance PS-C83RT in ceiling speaker features a bezel less magnetic grille, optional square adapter, high excursion 8" woofer, and pivoting tweeter for precise sound. Its sealed metal enclosure includes cable clamping, a removable Euro block connector, and seismic attachment. UL 1480 and UL 2043 certifications ensure safety and reliable performance.

Key Features

• Class leading sensitivity & sonic performance

• Exceptional off axis response

• Heavy duty voice coil for longevity and reliability

• Full-fidelity transformer for uncompromised tonality

• Consistent voicing across product range

• Bezel-less design for clean and minimalistic aesthetic

• Optional black grilles in round or square

• Magnetic grille retention for fast installation and removal

• Finger-adjustable selector tap

• One-step simplified painting process


  Specifications

  SKU

  45132 (White)

  HF Driver

  1" (25mm) Cloth Dome, Pivoting, Ferrofluid cooled

  LF Driver

  8" (203mm) Polypropylene Cone, Butyl Rubber Surround

  Frequency Response (+/- 10db)

  41Hz-25kHz

  Frequency Response (+/- 3db)

  55Hz - 20kHz

  Power Handling (RMS)

  160W program, 80W pink noise

  Sensitivity

  91dB (2.83V/1m)

  Rated Maximum SPL

  110dB @ 1 meter (3.3 feet), 116dB peak

  Nominal Impedance (Ohms)

  8 ohms

  Transformer Taps

  70 V / 100 V: 60W, 30W and 15W 70 V: 7.5W

  Dimensions (Diameter x D)

  11.06" x 9.84" (280.92mm x 249.94mm)

  Cut-Out Dimensions (Diameter)

  10.125" (257.18mm)

  Knockout

  One, Side mounted 0.75" (19mm)

  Weight

  13.41 lbs. (6.08kg)

  Grille

  One Piece Paintable Grille with Magnetic Retention

  Input Connector

  Four pin, Euroblock with loop output connections

  Certifications

  UL 1480; UL 2043; NFPA 90A; NFPA 70

  Suspension Points

  One, on top surface

  Maximum SPL (Peak)

  116dB peak

  Architectural Specifications

  The loudspeaker shall be of the two-way type comprising a single flush mount enclosure containing...

The Sonance PS-C61RT In Ceiling Speaker features a bezel less, magnetically secured grille for easy installation. It includes a 6.5" woofer for deep bass and a .75" tweeter for clear highs. With a UL94V-0 enclosure, integrated cable management, and multiple certifications, it ensures safety and seamless aesthetic integration.


Key Features

• Class-leading sensitivity & sonic performance

• Exceptional off-axis response

• Heavy duty voice coil for longevity and reliability

• Full-fidelity transformer for uncompromised tonality

• Consistent voicing across product range

• Bezel-less design for clean and minimalistic aesthetic

• Optional black grilles in round or square

• Magnetic grille retention for fast installation and removal

• Finger-adjustable selector tap

• One-step simplified painting process


  Specifications

  SKU

  45166 (White)

  HF Driver

  0.75" (19mm) Cloth Dome, Ferrofluid Cooled

  LF Driver

  6.5" (165mm) Polypropylene Cone, Butyl Rubber Surround

  Frequency Response (+/- 10db)

  60Hz-25khz

  Frequency Response (+/- 3db)

  83Hz - 20kHz

  Power Handling (RMS)

  100W program, 50W pink noise

  Sensitivity

  91dB (2.83V/1m)

  Rated Maximum SPL

  108dB @ 1 meter (3.3 feet), 116dB peak

  Nominal Impedance (Ohms)

  8 ohms

  Transformer Taps

  70 V / 100 V: 32W, 16W and 8W 70 V: 4W

  Dimensions (Diameter x D)

  9.13" x 8.86" (231.9mm x 225.04mm)

  Cut-Out Dimensions (Diameter)

  8.25" (209.55mm)

  Knockout

  One, Side mounted 0.75" (19mm)

  Weight

  6.88 lbs. (3.12kg)

  Input Connector

  Four pin, Euro block with loop output connections

  Certifications

  UL1480A; UL2043; EN 54; NFPA90A; NFPA70; CSA-C22.2 No.205; CSA C22.1

  Suspension Points

  One, on top surface

  Maximum SPL (Peak)

  116dB peak

  Architectural Specifications

  The loudspeaker shall be of the two way type comprising a single flush mount enclosure containing...

The Sonance PS-C63RTLP in-ceiling speaker has a shallow 4.37" design for tight spaces, a bezel-less magnetic grille, optional square adapter, high-excursion 6.5" woofer, and pivoting tweeter for precise sound. Its sealed metal enclosure includes knock-outs, a removable Euroblock connector, and seismic attachment. It is UL 1480 and UL 2043 certified.

Key Features

• Class-leading sensitivity & sonic performance

• Exceptional off-axis response

• Heavy duty voice coil for longevity and reliability

• Full-fidelity transformer for uncompromised tonality

• Consistent voicing across product range

• Bezel-less design for clean and minimalistic aesthetic

• Optional black grilles in round or square

• Magnetic grille retention for fast installation and removal

• Finger-adjustable selector tap

• One-step simplified painting process

Specifications

SKU

45182 (White)

HF Driver

1" (25mm) Cloth Dome, Pivoting, Ferrofluid cooled

LF Driver

6.5" (165mm) Polypropylene Cone, Butyl Rubber Surround

Frequency Response (+/- 10db)

49Hz-25kHz

Frequency Response (+/- 3db)

65Hz - 20kHz

Power Handling (RMS)

120W program, 60W pink noise

Sensitivity

91dB (2.83V/1m)

Rated Maximum SPL

108dB @ 1 meter (3.3 feet), 116dB peak

Nominal Impedance (Ohms)

8 ohms

Transformer Taps

70 V / 100 V: 60W, 30W and 15W 70 V: 7.5W

Dimensions (Diameter x D)

11.06" x 4.37" (280.92mm x 111.0mm)

Cut-Out Dimensions (Diameter)

10.125" (257.18mm)

Knockout

One, Side mounted 0.75" (19mm)

Weight

10 lbs. (4.54kg)

Grille

One Piece Paintable Grille with Magnetic Retention

Input Connector

Four pin, Euroblock with loop output connections

Certifications

UL 1480; UL 2043; NFPA 90A; NFPA 70

Suspension Points

One, on top surface

Maximum SPL (Peak)

116dB peak

DesignMax Luna makes it easy to get great sound in open-ceiling spaces. The proprietary Ring Array™ configuration combines eight 2-inch mid-high drivers with an integrated 8-inch woofer, delivering clear, balanced sound down to 40 Hz. With 111 dB max SPL and consistent 140° coverage, Luna reduces the number of speakers needed while preserving clarity, aesthetics, and design flexibility. Single- or two-point suspension allows for fast installs and perfectly balanced hangs — even in challenging ceiling conditions — while concealed wiring keeps everything looking clean.

Luna marks a giant leap forward in pendant loudspeakers, raising the bar for what’s sonically possible in retail stores, restaurants, fitness studios, and other design-conscious spaces. Best in show at Infocomm.

Features

Proprietary Ring Array™ configuration delivers precise, balanced sound with no hot spots or dead zones

Integrated 8” woofer extends down to 40 Hz—no subs needed

Wide-throw 140° coverage reduces speaker count and installation costs

Flexible mounting lets you use a single cable—or two-point suspension—for fast installs and perfectly balanced hangs

Streamlined design with concealed wiring and premium finish options

Factory-optimized loudspeaker presets when combined with Bose Professional amplifiers and processors

Compatible accessories include DesignMax Pendant Threaded Rod Adapter and Conduit Adapter

Designed for a wide range of applications, including:

• Retail stores

• Restaurants and breweries

• Fitness clubs and studios

• Amusement and recreation spaces

• Education and gymnasiums

COMPLIANCE

• Safety Agency Ratings

• UL Listed, UL 1480A, NFPA 70 & NFPA 90A, CE-compliant

Product Dimensions (H×W×D)

308 mm × 492 mm (12.1 in × 19.4 in), loudspeaker diameter x depth

Net Weight

10.0 kg (22.0 lb)

PERFORMANCE

Frequency Range (-10 dB)

40 Hz – 20,000 Hz

Coverage, Horizontal

140° conical

Calculated Maximum SPL @ 1 m

107 dB

Nominal Impedance

8 Ω (transformer bypass)

Power Handling, long-term continuous

140 W

Power Handling, Peak

560 W

Recommended Signal Processing

Not required, Bose Professional EQ voicing and SmartBass processing available

Sensitivity (SPL/1 W at 1 m)

85 dB

Transformer Taps, 100V

25 W, 50 W, 100 W, bypass

Transformer Taps, 70V

12 W, 25 W, 50 W, 100 W, bypass

TRANSDUCERS

High-Frequency

8 × 2.0-in (51 mm) drivers in circular array Low-Frequency

Low-Frequency

1 × 8 in (203 mm) woofer

Included in Packaging

(1) DesignMax Luna DML88P

(1) connection panel cover

(1) adjustable suspension cable system

(4) cable ties

(1) installation guide

DesignMax Luna makes it easy to get great sound in open-ceiling spaces. The proprietary Ring Array™ configuration combines eight 2-inch mid-high drivers with an integrated 8-inch woofer, delivering clear, balanced sound down to 40 Hz. With 111 dB max SPL and consistent 140° coverage, Luna reduces the number of speakers needed while preserving clarity, aesthetics, and design flexibility. Single- or two-point suspension allows for fast installs and perfectly balanced hangs — even in challenging ceiling conditions — while concealed wiring keeps everything looking clean.

Luna marks a giant leap forward in pendant loudspeakers, raising the bar for what’s sonically possible in retail stores, restaurants, fitness studios, and other design-conscious spaces. Best in show at Infocomm.

Features

Proprietary Ring Array™ configuration delivers precise, balanced sound with no hot spots or dead zones

Integrated 8” woofer extends down to 40 Hz—no subs needed

Wide-throw 140° coverage reduces speaker count and installation costs

Flexible mounting lets you use a single cable—or two-point suspension—for fast installs and perfectly balanced hangs

Streamlined design with concealed wiring and premium finish options

Factory-optimized loudspeaker presets when combined with Bose Professional amplifiers and processors

Compatible accessories include DesignMax Pendant Threaded Rod Adapter and Conduit Adapter

Designed for a wide range of applications, including:

• Retail stores

• Restaurants and breweries

• Fitness clubs and studios

• Amusement and recreation spaces

• Education and gymnasiums

COMPLIANCE

• Safety Agency Ratings

• UL Listed, UL 1480A, NFPA 70 & NFPA 90A, CE-compliant

Product Dimensions (H×W×D)

308 mm × 492 mm (12.1 in × 19.4 in), loudspeaker diameter x depth

Net Weight

10.0 kg (22.0 lb)

PERFORMANCE

Frequency Range (-10 dB)

40 Hz – 20,000 Hz

Coverage, Horizontal

140° conical

Calculated Maximum SPL @ 1 m

107 dB

Nominal Impedance

8 Ω (transformer bypass)

Power Handling, long-term continuous

140 W

Power Handling, Peak

560 W

Recommended Signal Processing

Not required, Bose Professional EQ voicing and SmartBass processing available

Sensitivity (SPL/1 W at 1 m)

85 dB

Transformer Taps, 100V

25 W, 50 W, 100 W, bypass

Transformer Taps, 70V

12 W, 25 W, 50 W, 100 W, bypass

TRANSDUCERS

High-Frequency

8 × 2.0-in (51 mm) drivers in circular array Low-Frequency

Low-Frequency

1 × 8 in (203 mm) woofer

Included in Packaging

(1) DesignMax Luna DML88P

(1) connection panel cover

(1) adjustable suspension cable system

(4) cable ties

(1) installation guide

48v Phantom Power Supply

Quite a bit of gear relies on Phantom Power to work these days, and the number is always growing. When you need a reliable power source, the M48 Phantom Power Supply is just the tool for the job.

Product features

Power Your Gear

Get All The Voltage

No Nonsense

Power From The Wall or 9v Battery

Stay Informed

Built-Like-A-Tank™

Full features

Perfect for condenser mics and equipment that require 48v Phantom Power

XLR input and output

Transparent, noise-free operation

Powered by the included AC adapter or 9v battery

Power and Low Battery indication

Built-Like-A-Tank™ construction

3.5" POWERED STUDIO MONITORS WITH TONE CONTROL

YOUR WORK + PLAY SPEAKERS

Shape the sound of your Mackie CR3.5 studio monitors on the fly, so you can mix a podcast episode, listen to music and DJ a house party, all with the same set of compact speakers.

Content Creation & Gaming

Add a set of our creative reference monitors to your setup for immersive sound you can tweak to your liking. Just connect your speakers to your gaming PC, audio interface, or Mainstream streaming interface, then adjust the tone knob until you hear the full impact of every footstep, line of dialogue and epic soundtrack moment.

Music Production

CR3.5 studio monitors have the clear, accurate sound you need to produce and record music. With the tone knob turned all the way left, you get a flat frequency response for tracking and mixing. Crank the tone knob to the right to hear more bass and sparkle .

Casual Listening

When your space serves as an office, recording studio, streaming den, living area and more, you need speakers that can do it all. That‘s why CR Series monitors have versatile features like the tone control knob and the location switch to quickly adjust your listening experience to any situation you prefer.

PRODUCT FEATURES

Sound-shaping tone control

Location switch with desktop and bookshelf modes

50 watts RMS of bi-amplified Class A/B amplification

TRS, RCA and 3.5 mm inputs

Built-in headphone output

Silk dome tweeter with protective grille

3.5" woven woofer

Size (H × W × D): 8.1 x 5.5 x 7.1 in / 206 x 140 x 180 mm

Weight: 8.2 lb / 3.7 kg

Mackie MobileMix 8-Channel USB-Powerable Mixer for A/V Production, Live Sound and Streaming

MobileMix is a USB-powerable audio mixer for A/V Production, Live Sound and Streaming. Featuring eight channels, two mic/instrument preamps, Bluetooth® with Mix Minus, stereo line inputs, EQ, effects and more, this mini mixer is the easiest way to get professional sound on the go.

GREAT SOUND, ANYWHERE

MobileMix is the easiest way to get legendary Mackie sound on the go–a fully featured small audio mixer you can power via USB or a rechargeable USB power pack (not included).

Full features

Runs on USB power from rechargeable batteries, adapters and powered USB ports

Dedicated mix output for recording to smartphones, tablets and DSLR cameras

Bluetooth® input/output with Mix Minus technology for recording and streaming at same time, including phone calls without echo

2 mic/instrument inputs with XLR and 1/4" combo connectors, Hi-Z, low cut and 48V phantom power

Stereo input for keyboards and other line-level gear

Two-way TRRS connector for second smart device or camera

3 different Reverb types with level controls per channel

2 mix outputs with separate level controls for PA systems, monitors and more

Headphone output with level control

Compartment for USB battery (sold separately)

YOUR WORK + PLAY SPEAKERS

Shape the sound of your Mackie CR5BT studio monitors on the fly, so you can mix a podcast episode, listen to music and DJ a house party, all with the same set of compact speakers.

Content Creation & Gaming

Add a set of our creative reference monitors to your setup for immersive sound you can tweak to your liking. Just connect your speakers to your gaming PC, audio interface, or Mainstream streaming interface, then adjust the tone knob until you hear the full impact of every footstep, line of dialogue and epic soundtrack moment.

Music Production

CR5BT studio monitors have the clear, accurate sound you need to produce and record music. With the tone knob turned all the way left, you get a flat frequency response for tracking and mixing. Crank the tone knob to the right to hear more bass and sparkle.

Casual Listening

When your space serves as an office, recording studio, streaming den, living area and more, you need speakers that can do it all. That‘s why CR Series monitors have versatile features like the tone control knob and the location switch to quickly adjust your listening experience to any situation you prefer.

BETTER WITH BLUETOOTH

Enjoy true flexibility with wireless Bluetooth® streaming. Press the icon on the front of the powered speaker to pair your favorite devices such as smartphones, laptops, and more for studio-quality sound anywhere.

PRODUCT FEATURES

Sound-shaping tone control

Location switch with desktop and bookshelf modes

100 watts RMS of bi-amplified Class D amplification

TRS, RCA and 3.5 mm inputs

Bluetooth® connectivity

Built-in headphone output

Silk dome tweeter with protective grille

5.25" woven woofer

Size (H × W × D): 10.3 x 6.9 x 9.3 in / 262 x 175 x 236 mm

Weight: 15.3 lb / 6.9 kg

5" Powered Studio Monitor

Whether you’re a musician, engineer or content creator, we know how much you rely on your studio gear for expressing creativity. Now you can get even closer to your sound. Mackie MR524 powered 5-inch studio monitors clearly reproduce audio across the entire frequency spectrum, so you can create professional mixes in your home studio.

UNMATCHED ACCURACY AND CLARITY

Designing and building professional monitors for home studios and working musicians is kind of our thing. That’s why the Mackie MR524 powered studio monitors are a top choice for anyone looking for high-quality studio monitors for professional recording. Equipped with our proven logarithmic waveguide and Acoustic Space Control, these 5” studio monitors provide an enhanced stereo image for accurate mixing in any room. From podcast dialogue and DJ mixes to your next studio album, you can mix with confidence knowing it will sound great anywhere.

Full features

Designed for superior mix translation and accuracy for professional results in any studio

Equipped with Mackie’s proven logarithmic waveguide design

Ultra-wide dispersion for enhanced stereo imaging and listening sweet spot

Precise acoustic alignment offers incredibly balanced sound across the entire frequency spectrum

1” silk dome tweeter provides fast transient response for detailed high end and vocal clarity

5” polypropylene woofer delivers responsive, dynamic low-frequency response

50 watts of bi-amplified Class A/B amplification

Frequency response: 45 Hz – 20 kHz

Optimize MR monitors for your mixing environment

Adjustable acoustic space filters maintain flat response in typical placement configurations

HF filter applies boost or cut to compensate for particularly dull or bright sounding rooms

Professional all-wood cabinet design built to last and look great in any studio

Custom designed internal bracing adds stiffness for reduced distortion and enhanced low-frequency response

Flexible inputs for simple connection to almost any audio source

Acoustically optimized with sound-tightening acoustic absorption material

Add the companion MRS10 studio subwoofer for powerful, deep low-frequency extension perfect for electronic music, hip-hop and more

4.5" POWERED STUDIO MONITORS WITH TONE CONTROL AND BLUETOOTH®

YOUR WORK + PLAY SPEAKERS

Shape the sound of your Mackie CR4.5BT studio monitors on the fly, so you can mix a podcast episode, listen to music and DJ a house party, all with the same set of compact speakers.

Content Creation & Gaming

Add a set of our creative reference monitors to your setup for immersive sound you can tweak to your liking. Just connect your speakers to your gaming PC, audio interface, or Mainstream streaming interface, then adjust the tone knob until you hear the full impact of every footstep, line of dialogue and epic soundtrack moment.

Music Production

CR4.5BT studio monitors have the clear, accurate sound you need to produce and record music. With the tone knob turned all the way left, you get a flat frequency response for tracking and mixing. Crank the tone knob to the right to hear more bass and sparkle.

Casual Listening

When your space serves as an office, recording studio, streaming den, living area and more, you need speakers that can do it all. That‘s why CR Series monitors have versatile features like the tone control knob and the location switch to quickly adjust your listening experience to any situation you prefer.

BETTER WITH BLUETOOTH

Enjoy true flexibility with wireless Bluetooth® streaming. Press the icon on the front of the powered speaker to pair your favorite devices such as smartphones, laptops, and more for studio-quality sound anywhere.

PRODUCT FEATURES

Sound-shaping tone control

Location switch with desktop and bookshelf modes

50 watts RMS of bi-amplified Class A/B amplification

TRS, RCA and 3.5 mm inputs

Bluetooth® connectivity

Built-in headphone output

Silk dome tweeter with protective grille

4.5" woven woofer

Size (H × W × D): 8.9 × 6.1 × 8.3 in / 226 × 155 × 211 mm

Weight: 9.9 lb / 4.5 kg

12” 1400W Enhanced Powered Loudspeaker

Enhance your next set with Thump212XT, the next evolution of our full-featured Thump Series powered loudspeakers. Packed with more time-saving features than ever, tons of power, and an all-new cabinet, Thump212XT is the ultimate loudspeaker for DJs, bands, and clubs that need pro sound without the insane price tag.

SHAKE THE WALLS, NOT YOUR HEAD

Tired of your PA system not cutting it? We get it, and Thump212XT is here to make life easier for you. With wireless control from your phone, its incredibly easy to dial in the sound just right. Application-specific voicing modes, indoor/outdoor modes, and more make it simple to optimize the loudspeaker to wheverer you put them. What about power? Well with 1400W of muscle, Thump212XT will keep the music going all night without a sweat. From DJs to bands to clubs and practice spaces, the lightweight Thump212XT is ready to enhance your performance.

Product features

1400W ultra-efficient Class-D amplifier

Built-Like-A-Tank™ to conquer every gig while lightweight for easy loading

12” high-performance woofer

1” compression driver

Wireless streaming and control

Application-specific voicing modes plus Indoor/Outdoor modes

Feedback Eliminator

Music Ducking

Standard Pole Mount / Monitor Wedge / M10 Flypoints

Full features

1400W ultra-efficient Class-D amplifier

Built-Like-A-Tank™ to conquer every gig while lightweight for easy loading

Frequency response: 47 Hz – 23kHz

Max SPL: 128 dB

12” high-performance woofer

1” compression driver

4 Application-specific voicing modes

Music

Live

Club

Monitor

Outdoor mode optimizes voicing for open air venues

Bluetooth® connectivity for streaming, speaker linking, and control

Download the Thump Connect 2 app for complete wireless control

Link 2 ThumpXT loudspeakers for a powerful, wireless, music playback system in both stereo and dual-zone configuration

Flexible I/O

1 features an XLR/TRS input that accepts mic or line signals

2 features an XLR/TRS line input plus stereo 1/8” input

Thru output contains audio from both input channels

Built-in Feedback Eliminator reduces squeals and out of control rumble

Music Ducking mode automatically reduces the level of Ch.2 when Ch.1 receives signal

Front LED On/Off switch

Universal Power Supply (100-240VAC)

Standard pole mount

M10 flypoints for permanent install

Monitor wedge provides optimal angle for use as a floor monitor

Weight: 29.3 lb / 13.3 kg

Dimensions: 24.2 x 14.1 x 14 in / 615 x 358 x 356 mm (HxWxD)

8" POWERED STUDIO MONITORS WITH TONE CONTROL AND BLUETOOTH®

YOUR WORK + PLAY SPEAKERS

Shape the sound of your Mackie CR3.5BT studio monitors on the fly, so you can mix a podcast episode, listen to music and DJ a house party, all with the same set of compact speakers.

BETTER WITH BLUETOOTH

Enjoy true flexibility with wireless Bluetooth® streaming. Press the icon on the front of the powered speaker to pair your favorite devices such as smartphones, laptops, and more for studio-quality sound anywhere.

PRODUCT FEATURES

Mackie CR8BT 8" Powered Studio Monitors With Adjustable Tone Knob and Bluetooth®

Sound-shaping tone control

Location switch with desktop and bookshelf modes

140 watts RMS of bi-amplified Class D amplification

TRS, RCA and 3.5 mm inputs

Bluetooth® connectivity

Built-in headphone output

Silk dome tweeter with protective grille

8" woven woofer

Size (H × W × D): 14.8 x 9.9 x 13.6 in / 376 x 251 x 345 mm

Weight: 35.3 lb / 16.0 kg

8" Powered Studio Monitor

Your studio is your creative haven—so make sure you’re using reliable monitors that help you create recordings and finish mixes you’re proud of. Mackie MR824 powered 8" studio monitors provide a clean stereo image in any room, allowing you to create professional mixes that sound great anywhere.

UNMATCHED ACCURACY AND CLARITY

We know a thing or two about designing and building studio monitors that deliver professional results for any studio. The Mackie MR824 studio monitors have all of the performance traits that have made the Mackie MR series a studio staple. These 8-inch Mackie monitors provide an enhanced stereo image, thanks to our proven logarithmic waveguide and Acoustic Space Control feature. Whether you’re working with podcast dialogue or an entire album, you can mix confidently knowing it’ll sound great anywhere.

Full features

Designed for superior mix translation and accuracy for professional results in any studio

Equipped with Mackie’s proven logarithmic waveguide design

Ultra-wide dispersion for enhanced stereo imaging and listening sweet spot

Precise acoustic alignment offers incredibly balanced sound across the entire frequency spectrum

1” silk dome tweeter provides fast transient response for detailed high end and vocal clarity

8” polypropylene woofer delivers responsive, dynamic low-frequency response

85 watts of bi-amplified Class A/B amplification

Frequency response: 35 Hz – 20 kHz

Optimize MR monitors for your mixing environment

Adjustable acoustic space filters maintain flat response in typical placement configurations

HF filter applies boost or cut to compensate for particularly dull or bright sounding rooms

Professional all-wood cabinet design built to last and look great in any studio

Custom designed internal bracing adds stiffness for reduced distortion and enhanced low-frequency response

Flexible inputs for simple connection to almost any audio source

Acoustically optimized with sound-tightening acoustic absorption material

Add the companion MRS10 studio subwoofer for powerful, deep low-frequency extension perfect for electronic music, hip-hop and more

10" 1400W Powered Loudspeaker

Mackie Thump210 is a compact 10” 1400W powered loudspeaker featuring proven sound quality with built-in Feedback Eliminator and Music Ducking mode. Lightweight and Built-Like-A-Tank™, Thump210 is the ultimate compact loudspeaker for mobile PA systems, DJs, bars, and more.

GIVE YOUR GIG A LITTLE THUMP

Thump210 gives you powerful 1400W Class-D amplification in a compact loudspeaker that’s perfect for gigging DJs and bands, venues and more. Packed with incredibly useful features, Thump210 makes gigs run smoother with feedback elimination and music ducking built right in. And with dual TRS / XLR inputs plus a stereo 1/8” aux input, you can plug in all of your gear without odd cables and adapters.

Product features

1400W ultra-efficient Class-D amplifier

Built-Like-A-Tank™ to conquer every gig while lightweight for easy loading

10” high-performance woofer

1” compression driver

Feedback Eliminator

Music Ducking

Standard Pole Mount + Wedge Design for Floor Monitor Use

Full features

1400W ultra-efficient Class-D amplifier

Built-Like-A-Tank™ to conquer every gig while lightweight for easy loading

Frequency Range (–10 dB): 52 Hz – 23 kHz

Maximum SPL Peak: 127 dB

Flexible I/O

1 features an XLR/TRS input that accepts mic or line signals

2 features an XLR/TRS line input plus stereo 1/8” input

Thru output contains audio from both input channels

10” high-performance woofer

1” compression driver

Built-in Feedback Eliminator reduces squeals and out of control rumble

Music Ducking mode automatically reduces the level of Ch.2 when Ch.1 receives signal

Standard pole mount

Monitor wedge provides optimal angle for use as a floor monitor

Universal Power Supply (100-240VAC)

Size (H x W x D): 22.4 x 13.0 x 12.8 in / 569 x 330 x 325 mm

Weight: 25.4 lb / 11.5 kg

Battery-Powered All-in-One Live Performance Rig with Breakaway Mix Control

Great live production. Total control.

It’s all in the box.

Every Gig. One Box.

Mackie ShowBox is a battery-powered live performance rig that makes it easy to get great live sound anywhere. It’s a portable PA, acoustic guitar amp, 6-channel mixer, effects rack and USB-C interface, all in a single device.

Interactive Performance Tools

ShowBox streamlines your guitar setup with a built-in tuner and looper you can access from the breakaway controller, plus user snapshots that let you recall your favorite settings in seconds.

Tech Specs

Feedback Eliminator

Indoor & Outdoor Voicing Modes

Amp & PA Voicing Modes

USB-C Interface for Live Streaming/Recording; Micro SD Recording

2× XLR Mic Inputs

2× 1/4" Instrument Inputs

Stereo 1/4" Line Input

External FX Loop Send & Return

Bluetooth Streaming

3.5 mm Aux Input

2-Button Footswitch Port

1/4" Headphone Output

XLR Mix Output

18” 2000W Professional Powered Subwoofer

The Mackie DRM18S 18" 2000 Watt Powered Subwoofer delivers deep low-end response and cutting-edge DSP for DJs, musicians, and venues that need reliable professional loudspeaker systems for both mobile and install applications.

No Compromises

If you want to complete your PA with serious low-end, the Mackie DRM18S powered subwoofer is the ultimate solution. Decades of innovation in DSP technology and amplifier design allowed us to optimize the DRM18S to its fullest potential. With ultra-efficient power, an over-engineered cabinet, and Advanced Impulse DSP tuning, the Mackie DRM18S has everything you need to shake the room.

Product features

2000W Class-D amplifier

Advanced Impulse™ DSP Module

DRM Control Dashboard™

Robust cabinet design with increased internal volume for maximum output

Rugged design with premium components

Versatile configuration options including directional cardioid array

Full features

High-efficiency 2000W Class-D amplifier offers ample headroom for professional applications

Universal power supply (100-240 VAC) with Power Factor Correction technology ensures consistent performance even with unstable AC power

Next-gen protection circuitry keeps transducers safe and ensures peak performance in all applications

Advanced Impulse™ DSP Module

Precision acoustic correction delivers reference quality sound that is consistent even at high SPL

DRM Control Dashboard™ features a high-resolution full color display for easy single-knob access to configuration, processing, and more

View current crossover setting, high-resolution metering, and more from a single overview window

User adjustable variable crossover point allows for matching to any speaker system plus a DRM specific mode tailors DRM18S for full-range DRM loudspeakers

Save and recall up to 6 user presets for various applications and venues

Cardioid mode allows for easy setup of a directional subwoofer array

Screensaver plus dimmer and contrast control

Polarity Invert

Alignment Delay control for delay stacks

System lock with 4-digit passcode

Dual independent input channels with Full-Range Direct and High-Pass outputs

Premium components

Road-worthy 18mm plywood construction and internal bracing offers optimal acoustic performance with a touring-grade textured coating and powder-coated heavy gauge steel grille

18” High-excursion woofer offers increased bass response, low distortion, and professional reliability to withstand the most demanding applications

Acoustic design with no compromises

Ample internal volume and precision tuned ports naturally deliver the bass you need with minimal distortion

Versatile configuration options

Flyable via optional FB100 Fly Bar and FKDRM18S Flyware Kit

M20 threaded pole attachment for use with DRM Series loudspeakers and other pole mountable speakers

Max SPL: 135 dB

90 lb / 40.8 kg

12" 2000W Powered Subwoofer

Incredibly powerful, Mackie DLM Series loudspeakers deliver premium sound in the most compact, professional portable loudspeaker series ever. Perfect for bands, venues and installs, the powerful, compact DLM series is the new shape of sound.

Shake the walls

Delivering 2000 watts of chest-pounding power, the DLM12S also features a ton of amazing system processing perfect for your professional application. The precision crossover includes presets for your Mackie system plus variable control for simple system integration. The innovative ultra-compact DLM12S delivers the powerful, deep low end your audience demands.

Full features

2000W power via ultra-efficient Class-D amplification

High-power 12″, heat-treated woofer with 3″ voice coil

Ultra-low frequency extension hits hard down to 35 Hz

DLP Digital Processor

Powerful, one-touch digital processor with bright OLED screen

Precision digital crossover

Presets for use with DLM and SRM Series full-range loudspeakers

Variable crossover control for optimization with any loudspeaker

Six total XLR connects for flexible I/O control

Two line level inputs

Two full-range outputs for side fills, etc.

Two high-pass outputs for direct connection to DLM loudspeakers

Unmatched system control for professional applications

Alignment delay up to 300ms for delay stack, balcony, etc.

Three memory locations for instant venue setting recall

Smart Protect DSP dynamically protects amp/driver

Innovative ultra-compact design

Highest-output compact subwoofer on the market

Fit an entire DLM system in nearly any car

Stack them up for storage

Pole mount a DLM8 or DLM12

Extremely durable 15mm poplar cabinet

Rugged, powder-coated 20 gauge steel grille

12" 2000W High-Performance Powered Loudspeaker

New industry standard for portable loudspeakers

Mackie SRM212 V-Class sets a new industry standard for portable loudspeakers, bringing the best-in-class performance, clarity and technology you need when compromise isn’t an option.

STAGE MEETS STUDIO

Every song deserves to be heard the way it was intended. Upgrade to Mackie SRM V-Class, the high-performance loudspeaker that is as clear and articulate as a professional studio monitor.

Tech Specs

2000W Class-D Amplifier

Our most advanced amplifier platform ever, delivering incredible stability, headroom and audio fidelity

Highest SPL in its class

Unrivaled reliability and rock-solid operation can withstand the most demanding applications

Universal power supply (100-240 VAC) with Power Factor Correction for stable operation even with unstable AC power

Custom Transducers

Large, powerful magnets partner with robust motors, specially designed voice coils and spiders to provide the highest possible efficiency and transient accuracy

12” low-frequency driver designed for powerful yet balanced low end

Additional cooling vents surrounding the voice coil plus directional cabinet porting ensures maximum heat dispersion and reliability

Premium polymer high-frequency driver provides the flattest possible response for incredibly smooth highs that sound natural and balanced

Custom Sym-X™ Horn

Allows for total efficiency from the HF transducer, minimizing distortion and increasing output

Creates a perfectly symmetrical, flat response at the crossover point for exceptionally smooth midrange

The horn-loading frequency is set below the LF capability of the driver for maximum efficiency and optimal performance at the crossover point

Advanced Impulse™ DSP

Crystal-clear sound across the entire dispersion zone means the whole room is the sweet spot

Precision crossover and transducer time-alignment ensures balanced and accurate sound

Transparent System Protection

Dedicated processing module monitors and protects the amplifier in real time

Sound quality and tonal balance is maintained even under heavy limiting—no “pumping” when you crank the speaker

Utilizing powerful multi-band compression, the amplifier can target specific frequency ranges to prevent the system from being overloaded rather than turn everything down at the expense of overall output

Input limiting keeps your source signal in check so if you’re sending audio that’s a bit too hot, the speaker will cool it down

Intelligent Bass Management™

Proprietary LF management technology maintains tonal balance and output level when operating at very high volumes

Keeps the bass tight, punchy and articulate—essential for DJs and electronic musicians

SRM Mix Control™

Dual independent channels that support mic, line and instrument signals with XLR/TRS combo inputs

Dedicated 1/8” stereo aux channel

Direct outputs on channels 1 and 2 plus mix output

High-contrast full color display for easy single-knob access to mixer and processing

Adjust channel levels and EQ

Application and venue-specific voicing modes

Variable crossover point

Alignment delay—up to 100 ms

Save and recall up to 10 user presets

Screensaver plus dimmer and contrast control

System lock with 4-digit passcode

Change front LED function: Green, white, off, signal present, multi (cycle through colors)

SRM Connect™ App

The SRM Connect™ app gives you access to all adjustments and settings including EQ, levels and presets

Control two speakers at once, wirelessly

DJs can dial in the right mix from the dance floor with their phone

Bluetooth® Streaming and Linking

Wirelessly link two SRM V-Class speakers for music streaming applications plus complete control over both speakers

Bluetooth® technology allows up to 100 meters of range between linked speakers

Stereo or dual zone linking modes allows discrete control over the inputs and outputs of the entire system across two rooms or zones

Creates an incredibly clean setup in minutes

Versatile Configuration Options

Dual-angled cabinet design allows for use as a PA speaker or high-performance floor monitor

Pole mount provides optimal coverage and minimal reflections in most venues, with optional 7-degree downward tilt for elevated stages

M10 fly points are ideal for permanent overhead installations

T100 tripod stand for elevating speaker (sold separately)

SPM400 speaker pole for mounting over subwoofer (sold separately)

PA-A3 eyebolt kit for suspending speaker (sold separately)

Physical Specifications

Maximum SPL Peak: 135 dB

Frequency Response: 42 Hz - 20 kHz

Horizontal Coverage Angle: 90°

Vertical Coverage Angle: 60°

Height: 25.9 in / 658 mm

Width: 15.2 in / 386 mm

Depth: 14.2 in / 361 mm

Weight: 40.6 lb / 18.4 kg

8" 2 Way Active Studio Monitor

Modern studios demand precision and accuracy from their monitors. Since the 90's, the HR Series has been a go-to reference in the most critical mixing and mastering setups. The same innovation that launched our pioneering HR Series has led to the birth of just such a monitor as well as a new studio standard. Meet the HRmk2.

Accuracy. Clarity. Precision.

The largest of the two models, HR824mkII is an excellent choice for any pro studio that demands serious precision and excellent low frequency reproduction. Whether you need an ultra-accurate monitoring setup or you want to add premium sound to your home theatre or gaming system, this THX pm3 approved monitor delivers ultimate performance and sound quality that’s ideal for just about any room or setup. In addition to the capabilities of the 8" woofer, you will hear and feel massive low end thanks to it's innovative passive radiator design. Because the HR624mk2 and it's larger sibling HR824mk2 share the same design, they function great together, making them optimal for surround systems.

Full features

Ultra-linear frequency response for accurate mix translation

8.75-inch high-precision, low-distortion LF transducer

1-inch titanium dome,ferro-fluid cooled tweeter

Optimized waveguide for wide, even sweet zone

Twin FR Series amps: 150W for LF / 100W for HF

Full internal damping eliminates midrange artifacts

Passive radiator provides tight, articulate bass extension down to 35Hz

Acoustic space, LF roll-off and HF controls

Balanced XLR, TRS and unbalanced RCA inputs

THX pm3 Certified for surround sound applications

15" 1600W Professional Powered Loudspeaker

The Mackie SRT215 Professional Powered Bluetooth Loudspeaker is built for bands, DJs, singer/songwriters and venues who need clear, powerful sound with minimal setup time.

Full Throttle Performance

Sometimes soundcheck is the first song. Mackie SRT215 Professional Powered Loudspeakers help you dial in great sound in a hurry with time-saving features like the built-in SRT Mix Control™ 4-channel digital mixer with Bluetooth® and Advanced Impulse™ DSP tuning for consistent, accurate and reliable sound at every gig. Plus, its transparent system protection defends against power surges and loud pops—because everybody forgets a mute button now and then.

Product features

The ultimate workhorse loudspeaker

Industry-leading 1600W Class-D amplifier with transparent system limiting and protection

Superior sound with Advanced Impulse™ DSP tuning

Custom transducers and SymX™ Horn for unmatched clarity and accuracy

SRT Mix Control™ built-in 4-channel digital mixer with Bluetooth®

Complete wireless control via the SRT Connect™ app

Wirelessly link 2 SRT speakers together for music streaming applications plus control

Dual-angle pole mount plus angled design for use as a floor monitor

Full features

A True Workhorse for Gigging Professionals

1600W Class-D amplifier is designed for ultra-reliable, consistent performance

Custom high-efficiency transducers ensure maximum clarity and accuracy

Built-Like-A-Tank™ to conquer every gig while lightweight for easy loading

Frequency response: 42Hz – 20kHz

Max SPL: 133 dB

Advanced Impulse™ DSP – Proprietary Acoustic Tuning

Crystal clear sound across the entire dispersion zone means the whole room is the sweet spot

Precision crossover and transducer time-alignment ensures balanced and accurate sound

Custom Sym-X™ Horn

Allows for total efficiency from the HF transducer minimizing distortion and increasing output

Creates a perfectly symmetrical, flat response at the crossover point for exceptionally smooth midrange

The horn-loading frequency is set below the HF drivers’ LF capability allowing for maximum efficiency and optimal performance at the crossover point

Coverage: 90 ̊ horizontal x 60 ̊ vertical

Transparent System Limiting and Protection

Dedicated processing module monitors and protects the amplifier in real time

Sound quality and tonal balance is maintained even under heavy limiting

Utilizing powerful multi-band compression, the amplifier can target specific frequency ranges to prevent the system from being overloaded rather than turn everything down at the expense of overall output

Input limiting keeps your source signal in check so if you’re sending audio that’s a bit too hot, the speaker will cool it down

Universal Power Supply (100-240VAC) with Power Factor Correction for stable operation even with unstable AC power

SRT Mix Control™ Built-in 4-Channel Digital Mixer with Bluetooth®

Dual independent channels that support mic, line, and instrument signals

Dedicated 1/8” stereo aux channel

Stream music from any Bluetooth® enabled device

High-contrast full color display for easy single-knob access to mixer and processing

Adjust channel levels and EQ

Application and venue specific voicing modes

Alignment delay – up to 100 feet

Save and recall up to 10 user presets

Screensaver plus dimmer and contrast control

System lock with 4-digit passcode

Front LED on, off and signal present modes

Complete Wireless Control via the SRT Connect™ App

The SRT Connect™ app gives you access to all adjustments and settings including EQ, levels, and presets

Wirelessly link SRT speakers together for music streaming applications plus complete control over both speakers

The latest Bluetooth technology allows up to 100 meters of range between linked speakers

Stereo or dual zone linking modes allows discrete control over the inputs and outputs of the entire system across two rooms or zones

Creates an incredibly clean setup in minutes

Versatile configuration options

Dual-angled cabinet design allows for use as a high-performance floor monitor

Dual angle pole-mount provides optimal coverage and minimal reflections in most venues; 7-degree downward tilt is perfect for when the speakers are on elevated stages

M10 flypoints for professional installation

Weight: 37.1 lb / 16.8 kg

Dimensions: 28.8 x 17.6 x 15.4 in / 732 x 447 x 391 mm

18” 1400W Powered Subwoofer

The flagship subwoofer of the Thump Series, the 1400W Thump118S delivers maximum performance for modern DJs, bands, and clubs. An all-new design features selectable voicing modes that make it easy to tailor the bass to your needs and style.

The Best Got Better

Welcome to the world of Thump, where rumble rules and the music doesn't stop till you say so. Before you get the party started, equip your system with a subwoofer that can keep up. Thump118S brings 1400W of raw wall-shaking power to your system with selectable voicing modes and a variable crossover to make optimization easy. Stereo inputs plus High-Pass and Full-Range outputs offer plenty of configuration flexibility and integrated top corner handles are our most ergonomic design yet. So grab one (or two, or three) and take your PA system to the next level, the Thump level. Thump118S is a seriously great choice for DJs, Bands, Clubs, Houses of Worship, and more.

Product features

1400W Ultra-Efficient Class-D Amplifier

Voicing Modes Optimize Thump118S to Your Needs

Variable Crossover and Level

Stereo XLR Inputs and Stereo High-Pass + Full-Range Outputs

Frequency Response: 30Hz – 200Hz

Max SPL: 132 dB

BASS HAS FEELINGS TOO

Voicing modes are quite common on full-range loudspeakers, but why not on a subwoofer? We decided it was time to change that. With three unique voicing modes, you can tailor the bass in your system to better match your application or what feels good. Go with what your heart tells you.

Flat – Natural balance between deep bass and overall output

Deep – Emphasizes ultra-low frequencies. Great for dance, rap, and electronic music

Punch – Prioritizes highest possible output level. Great for bands and rock music

Variable – Set the crossover to the perfect spot for your system

Full features

A True Workhorse for Gigging Professionals

1400W Class-D amplifier is designed for ultra-reliable, consistent performance

18” High-performance woofer

Built-Like-A-Tank™ to conquer every gig while lightweight for easy loading

Frequency response: 30Hz - 200Hz

Max SPL: 132 dB

Voicing Modes

Flat – Natural balance between deep bass and overall output

Deep – Emphasizes ultra-low frequencies. Great for dance, rap, and electronic music

Punch – Prioritizes highest possible output level. Great for bands and rock music

Variable

Optimize for Your System

Variable crossover frequency

Polarity invert switch

Defeatable front LED

Stereo or mono summing for single or dual subwoofer deployment

Variable level control (-6dBU to +6dBU)

Front LED On/Off

Versatile I/O

Stereo XLR inputs

Stereo full-range XLR outputs

Stereo high-pass XLR outputs

Versatile configuration options

Integrated M20-threaded pole mount

Weight: 65.5 lb / 29.71 kg

Dimensions: 21.3 x 20.9 x 23.9 in / 541 x 531 x 607 mm (HxWxD)
