The Sennheiser SL MCR 4 DW-4 is a 2- or 4-channel multi-receiver designed for SpeechLine Digital Wireless systems. With its sleek, unobtrusive design, it installs easily on walls or ceilings, powered via PoE to eliminate complex cabling. Dual Dante ports provide seamless digital audio integration, while an analog mix output allows all channels to be used as a single summed signal. Automatic frequency and interference management ensure stable performance, and full remote control is supported through Sennheiser Control Cockpit or third-party systems such as AMX, Crestron, or Q-SYS. Integrated antennas remove the need for external antenna setups, making installation clean and simple.
FEATURES
Automatic Gain Control
Automatic Frequency Management
AES-256 Encryption
Dual-Port Dante (Primary & Secondary)
PoE Powered
Analog Mix Output
Status LED per Link
Remote Control via Control Cockpit or Media Control Systems
Wall, Ceiling, or Mic Stand Mounting
Integrated Automixer
DDM Ready
TECHNICAL SPECIFICATIONS
Color: White
Dimensions: 180 × 180 × 45 mm (including wall mount)
Audio Output: 3-pin analog socket (Phoenix Contact MCVW 1.5-3-ST-3.81), Two Dante RJ-45 network ports
Dante: Primary and Secondary
Frequency Range: 1920.000 – 1930.000 MHz
Latency: 23 ms
Power Consumption: < 15 W
Connection Type: Wireless
Connectors: RJ-45 (Ethernet)
Channels: 2 or 4
Automixer: Integrated
The Sennheiser SL MCR 4 DW-4 is a 2- or 4-channel multi-receiver designed for SpeechLine Digital Wireless systems. With its sleek, unobtrusive design, it installs easily on walls or ceilings, powered via PoE to eliminate complex cabling. Dual Dante ports provide seamless digital audio integration, while an analog mix output allows all channels to be used as a single summed signal. Automatic frequency and interference management ensure stable performance, and full remote control is supported through Sennheiser Control Cockpit or third-party systems such as AMX, Crestron, or Q-SYS. Integrated antennas remove the need for external antenna setups, making installation clean and simple.
FEATURES
Automatic Gain Control
Automatic Frequency Management
AES-256 Encryption
Dual-Port Dante (Primary & Secondary)
PoE Powered
Analog Mix Output
Status LED per Link
Remote Control via Control Cockpit or Media Control Systems
Wall, Ceiling, or Mic Stand Mounting
Integrated Automixer
DDM Ready
TECHNICAL SPECIFICATIONS
Color: White
Dimensions: 180 × 180 × 45 mm (including wall mount)
Audio Output: 3-pin analog socket (Phoenix Contact MCVW 1.5-3-ST-3.81), Two Dante RJ-45 network ports
Dante: Primary and Secondary
Frequency Range: 1920.000 – 1930.000 MHz
Latency: 23 ms
Power Consumption: < 15 W
Connection Type: Wireless
Connectors: RJ-45 (Ethernet)
Channels: 2 or 4
Automixer: Integrated
