AKG Helical Wireless Microphone Passive circular polarized directional antenna

$630.00

sold out

AKG Helical Wirless Microphone Passive circular polarized directional antenna

Ships Free!

The HELICAL antenna is a passive circular polarized directional wide-band UHF antenna which can be used as a transmitting or receiving antenna for wireless microphones and in-ear monitoring systems. It operates in a frequency range from 470 to 740 MHz and provides an antenna gain of 9dB. This circular polarized HELICAL antenna is specially designed for tour sound, sports and broadcast applications where long range FOH positions of many hundreds of feet often require a high gain. With the included universal thread adapter it can be mounted on floor stands with both 3/8" or 5/8" screws. The HELICAL antenna comes with a durable, water resistant nylon cover which also helps to compress the antenna to easily fit inside a rack drawer.

General Specifications

Switching bandwidth (from/to)470 - 740 MHz

Antenna gain9 dBi

Covering angle63 Grad

Antenna Output

Amount1

TypeN

GenderFemale

Recommended load impedance50 Ohms

Dimensions

Length305 mm

Height355 mm
