DAS Audio Q-23-T 1 Way 2 x 3 Full Range Passive Loudspeaker System 40 Watts
DAS Audio Q-23-T 1 Way 2 x 3 Full Range Passive Loudspeaker System 40 Watts
The Q-23 is a highly compact and discrete system ideal for short distances, for creating ambience, and for frontfill and under-balcony sound reinforcement. Like the other systems in the series, the Q-3 has two operating modes (voice and music) that guarantee outstanding speech intelligibility and excellent music reproduction in any acoustic environment.
The aluminum enclosure and the IP-66 kit make this a highly reliable and durable choice, available in any RAL color.
Features-
Passive system
Extruded aluminum enclosure
2 x 3â, 3P16 full-range speaker
Dispersion H x V- 120º x 70º/90º
SPL peak- 112 dB
Multi-tap 100/70V transformer included
Low/high-impedance operation
Available in all RAL colors
Applications-
A/V systems and corporate events
Meeting rooms, classrooms, and exhibit areas
Installations in bars and clubs
Specifications-
Performance
Frequency Range (-10 dB)- 150 Hz â 20 kHz
Horizontal Coverage (-6 dB)- 120º
Vertical Coverage- Switchable- 90º -70º
Nominal Impedance- 8 ohms
Transformer Taps 70 V- 5 W â 10 W â 15 W
Transformer Taps 100 V- 10 W â 20 W â 30 W
RMS Power Handling- 40 W
Peak Power Handling- 160 W
On-axis Sensitivity 1W/1 m- 90 dB SPL
Maximum Peak SPL at 1 m- 112 dB SPL
Recommended Amplifier- INTEGRAL-A402
INTEGRAL-A404
Recommended Processor- DSP-226
Connectors
Audio Input Connector- 4-way Phoenix 2.54 mm
Enclosure
Enclosure Construction- Aluminum
Color- Black
IP Rating- IP66
Depth- 125 mm (4,9 in)
Dimensions ( H x W x D )- 190 x 125 x 125 mm
7,5 x 4,9 x 4,9 in
Net Weight- 2,8 kg ( 6,2 lb )
Components
MF Driver- 3P16
