RODE NTG1 Shotgun Microphone

RODE NTG1 Shotgun Microphone

The NTG1 is a lightweight condenser shotgun microphone, designed for professional applications in film, video, television and broadcast. Its full frequency response, low noise and transparency make it ideal in a range of applications, including filmmaking, voice-over and streaming, while its low weight (105 grams) makes it an ideal boom microphone. It also features a switchable high-pass filter for added flexibility.

Key Features

• Premium shotgun microphone

• Low noise and full frequency response

• Highly directional supercardioid polar pattern

• High-pass filter (80Hz)

• Lightweight (105 grams) and easy to use

Specifications

• Acoustic Principle: Line Gradient

• Active Electronics: JFET impedance convertor with bipolar output buffer

• Capsule: 0.50"

• Polar Pattern: Supercardioid

• Address Type: End

• Frequency Range: 20Hz - 20kHz

• Output Impedance: 50Ω

• Maximum SPL: 139dB SPL

• Maximum Output Level: 6.9mV (@ 1kHz, 1% THD into 1KΩ load)

• Sensitivity: -36.0dB re 1 Volt/Pascal (15.00mV @ 94 dB SPL) +/- 2 dB @ 1kHz

• Equivalent Noise Level (A-Weighted): 18dBA

• Power Requirements: P24 and P48

• Output Connection: XLR

• Weight (g): 105

• Dimensions (mm): 219 (H) x 22 (W) x 22 (D)
