Sonance PS-C43RTLP Low Profile In-Ceiling Speaker
The Sonance PS-C43RTLP Low Profile In-Ceiling Speaker is designed for tight spaces, fitting beneath HVAC ducts or in 2'x4' stud bays. Its shallow 3.43" design features a magnetically secured bezel-less grille for easy painting. With a 4" woofer and pivoting 1" tweeter, it delivers exceptional audio performance.
Key Features
Class-leading sensitivity & sonic performance
Exceptional off-axis response
Heavy duty voice coil for longevity and reliability
Full-fidelity transformer for uncompromised tonality
Consistent voicing across product range
Bezel-less design for clean and minimalistic aesthetic
Optional black grilles in round or square
Magnetic grille retention for fast installation and removal
Finger-adjustable selector tap
One-step simplified painting process
Specifications
Color
White
HF Driver
1" (25mm) Cloth Dome, Pivoting, Ferrofluid cooled
LF Driver
4" (100mm) Polypropylene Cone, Butyl Rubber Surround
Frequency Response (+/- 10db)
57Hz - 25kHz
Frequency Response (+/- 3db)
75Hz - 20kHz
Power Handling (RMS)
60W program, 30W pink noise
Sensitivity
87dB (2.83V/1m)
Rated Maximum SPL
105dB @ 1 meter (3.3 feet), 110dB peak
Nominal Impedance (Ohms)
8 Ohms
Transformer Taps
70 V / 100 V: 30W, 15W and 7.5W 70 V: 3.8W
Dimensions (Diameter x D)
9.13" x 3.43" (231.9mm x 87.12mm)
Cut-Out Dimensions (Diameter)
8.25" (209.55mm)
Knockout
One, Side mounted 0.75" (19mm)
Weight
6.00 lbs. (2.72kg)
Grille
One Piece Paintable Grille with Magnetic Retention
Input Connector
Four pin, Euroblock with loop output connections
Certifications
UL 1480; UL 2043; NFPA 90A; NFPA 70
Suspension Points
One, on top surface
