Waves AIOCL All-In-One Mic Preamp & Audio Interface

Waves AIOCL All-In-One Mic Preamp & Audio Interface

64 stereo channels and 44 stereo buses of industry-leading sound. Includes 16 inputs powered by Waves Signature Preamps and the live sound industry’s deepest processing, built into the console. Designed for intuitive workflow, easy scalability, and maximum portability.

For the first time, all the advantages of the LV1 live mixing platform are available in a classic hardware form factor. eMotion LV1 Classic builds on the proven LV1 mixer engine, delivering its sonic quality with the tactile control and workflow preferred by live sound engineers worldwide.

With a pristine-sounding mixer engine, quick-access interface combining a 21.5” multi-touch screen with tactile control, and robust physical build, LV1 Classic packs more live mixing power into a compact console than ever before.

Key Highlights

• 64 stereo channels / 44 stereo buses

• Double-precision 32-bit float mix engine (44.1–96 kHz)

• 16 Waves Signature Preamps with 12 line outputs

• 21.5” touch screen and 17 motorized 100 mm faders

• Compact and flyable design (38 lbs / 17.2 kg)

• Built-in processing: compression, EQ, dynamic EQ, vocal tuning, feedback control, FX, and more

• Upgrade with 160+ additional Waves processors, immersive in-ear mixing, and Dugan auto-mixing

• Premium stagebox expansions: IONIC 24 and IONIC 16

• Easy scalability for I/O, DSP, and multi-console networking

• Two-year warranty upon registration

Sound Quality and Performance

eMotion LV1 Classic’s 32-bit float mix engine delivers pristine clarity and maximum headroom, powered by Waves’ award-winning digital signal processing expertise. The 16 original Waves Signature Preamps offer pure, transparent audio or rich harmonic enhancement through HMX mode.

Connectivity and Flexibility

Features 12 line outputs, AES3 I/O, four SoundGrid ports, headphone and monitor outputs, HDMI, USB, network connectivity, and dual power supply for redundancy. Ideal for diverse live sound setups.

Intuitive Control

A large 21.5” multi-touch screen and tactile surface with 17 faders provide quick access to essential mixer functions. Each fader features customizable encoders and LCD metering for efficient, real-time control.

Included Processing

Comes with 16 of Waves’ most popular processors, including F6 Dynamic EQ, Waves Tune Real-Time, X-FDBK, PSE, Magma Tube Channel Strip, R-Comp, H-Delay, R-Verb, Doubler, GTR3, and more. All processors can be flexibly chained across all input and mix channels.

Expandable and Portable

Add more I/O with IONIC stageboxes, expand DSP power, or network multiple consoles for FOH, monitors, or broadcast. Compact and lightweight at just 38 lbs (17.2 kg), LV1 Classic is ideal for touring or permanent installations.

Built for Houses of Worship and Beyond

Designed for both professionals and volunteers, the LV1 Classic offers intuitive control, pristine sound, and tools to manage feedback, EQ, and dynamics in any acoustic environment.

Technical Support

Waves offers 7-day-a-week phone and remote support, including live TeamViewer assistance for your eMotion LV1 Classic console.

Specifications

• 64 input channels and 44 buses (8 groups, 24 auxes, 8 matrices, 3 masters, cue)

• Latency as low as 0.8 ms

• 21.5” touch screen with 1000 Nit brightness

• 16+1 motorized 100 mm faders and precision encoders

• 8-slot plugin rack per channel

• Record 16 tracks locally or up to 128 tracks remotely

• USB stereo playback

• Supports up to 1000 scenes, DCA groups, mute groups, and recall filters

• Size: 22” x 15.8” x 22.1” (560 x 402 x 561 mm)

• Weight: 38 lbs (17.2 kg)
